KD8121

1U Rackmount LCD Console Drawer

21.5" 1920 x 1080 Full HD Industrial Monitor

Pull Out Drawer with Slide Access Design

User Manual

Legal Information

First English printing, November 2020

Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness

of the contents. The information in this document is subject to change without notice. We are not liable for any injury or

loss that results from the use of this equipment.

Safety Instructions

Please read all of these instructions carefully before you use the device. Save this manual for

future reference.

■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.

■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with

temperatures not exceeding 40º Celsius (104º Fahrenheit).

■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing

damage to other equipment or injury to persons nearby.

■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the

power supply. Proper air convection is necessary to keep it from overheating.

■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.

■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current

labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed

on the equipment’s ratings label.

■Observe all precautions and warnings attached to the equipment.

■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being

damaged by transient over-voltage.

■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power

supply or on other hardware may cause damage, ﬁre or electrical shock.

■Only qualiﬁed service personnel should open the chassis. Opening it yourself could damage the equipment and

invalidate its warranty.

■If any part of the equipment becomes damaged or stops functioning, have it checked by qualiﬁed service personnel.

What the warranty does not cover

■Any product, on which the serial number has been defaced, modiﬁed or removed.

■Damage, deterioration or malfunction resulting from:

□Accident, misuse, neglect, ﬁre, water, lightning, or other acts of nature, unauthorized product modiﬁcation, or

failure to follow instructions supplied with the product.

□Repair or attempted repair by anyone not authorized by us.

□Any damage of the product due to shipment.

□Removal or installation of the product.

□Causes external to the product, such as electric power ﬂuctuation or failure.

□Use of supplies or parts not meeting our speciﬁcations.

□Normal wear and tear.

□Any other causes which does not relate to a product defect.

■Removal, installation, and set-up service charges.

Regulatory Notices Federal Communications Commission (FCC)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of

the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation.

Any changes or modiﬁcations made to this equipment may void the user’s authority to operate this equipment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment oﬀand on, the

user is encouraged to try to correct the interference by one or more of the following measures:

■Re-position or relocate the receiving antenna.

■Increase the separation between the equipment and receiver.

■Connect the equipment into an outlet on a circuit diﬀerent from that to which the receiver is connected.

Contents

< Part. 1 > KD8121

1.1 Package Content P.1

1.2 Structure Diagram & Dimension P.1

1.3 Installation P.3

1.4 Connection P.5

< Part. 2 > Speciﬁcations / OSD

2.1 Product Speciﬁcations P.6

2.2 Keyboard / Mouse Speciﬁcations P.8

2.3 On-screen Display Operation ( OSD ) P.11

< Part. 3 > Options

3.1 P.14

3.2 P.15

3.3

3G / HD / SD-SDI Broadcast-grade input

HDMI

DC Power : 12V / 24V / 48V / 125V P.16

■It is very important to mount the equipment in a suitable cabinet or on a stable surface.

■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive

dust, dirt, heat, water, moisture and vibration.

The equipment comes with the standard parts shown in package content. Check and make sure they are

included and in good condition. If anything is missing, or damaged, contact the supplier immediately.

Unpacking

Before Installation

How To Clean Your LCD Monitor

Caution :

■To avoid the risk of electric shock, make sure your hands are dry before unplugging your monitor from or

plugging your monitor into an electrical outlet.

■When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen can

scratch or damage your display. Pressure damage is not covered under warranty.

■Use only cleansers made speciﬁcally for cleaning monitors and monitor screens. Cleansers not made to

clean monitors and monitor screens can scratch the LCD display or strip oﬀthe ﬁnish.

■Do not spray any kind of liquid directly onto the screen or case of your monitor. Spraying liquids directly

onto the screen or case can cause damage which is not covered under warranty.

■Do not use paper towels or abrasive pads to clean your monitor. Using an abrasive pad or any wood based

paper product such as paper towels can scratch your LCD screen.

Cleaning Your Monitor

To clean your LCD safely, please follow these steps :

Disconnect the power cord.

Gently wipe the surface using a clean, dry microﬁber cloth. Use as little pressure as possible.

Cleaning Tough Marks and Smudges

To remove tough marks and smudges, please follow these steps :

Disconnect the power cord.

Spray a small amount of non-abrasive cleanser on a microﬁber cloth.

Gently wipe the surface. Use as little pressure as possible.

Wait until your monitor is completely dry before plugging it in and powering it up.

Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your

microﬁber cloth ﬁrst, not directly on the parts you are cleaning.

LCD interchangeable module kit

LCD membrane

Micro switch for screen auto power oﬀ

Installation Slides

Keyboard interchangeable module kit

Mouse interchangeable module kit

Carry handle to release the 2-pt lock

Membrane switch (KVM option)

Audio speaker ( for SDI or HDMI option )

Front USB port for device access ( USB Hub KVM only )

< 1.1 > Package Content

< Part 1 >

KD8121 unit X 1

- 6ft DVI-D console cable X 1

-Power cord X 1

-M6 screw, cage nut & cup washer X 8

< 1.2 > Structure Diagram

The above package content is only for the single console models.

It varies with options such as KVM, SDI, HDMI & DC power.

P.1

< 1.2 > Dimension

Side View

Top View

Front View

The weight is only for the single console models. It varies with accessories & options

such as KVM, SDI, HDMI & DC power.

UNIT : mm

1mm = 0.03937 inch

Model Product Dimension

(W x D x H) Packing Dimension

(W x D x H) Net Weight Gross

Weight

KD8121 441.6 x 670 x 44 mm

17.4 x 26.4 x 1.73 inch 595 x 910 x 140 mm

23.4 x 35.8 x 5.5 inch 14.7 kg

32.3 lb 18.9 kg

41.6 lb

Power VGA DVI-DUSB

Rear View

AC Input

100~240V

P.2

< 1.3 > Installation - How to install Installation Slides

■Fix the LCD console drawer into the rack.

Complete the installation

Step 3

■Insert the left and right rear mounting brackets into

the LCD console drawer.

Step 1

Step 2

■Measure the depth of the front and rear mounting rails.

■Align each rear mounting bracket to a suitable length.

M6 screw, cage nut & cup washer x 8 are provided.

P.3

■Operate the LCD console drawer.

< 1.3 > Installation- How to use the drawer

■Hold the handle and slide out the drawer.

■Flip up the LCD to a suitable angle.

Flip up LCD from the side

Left Right

Front Side

LCD

Panel

Option - Right Side Open

P.4

Caution : The LCD console drawer is hot-pluggable, but components of connected devices, such

as the servers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables while

servers and KVM are powered on may cause irreversible damage to the servers, KVM and LCD

console drawer. Before attempting to connect anything to the LCD console drawer, we suggest

turning oﬀthe power to all devices. Apply power to connected devices again only after the LCD

console drawer is receiving power. The company is not responsible for damage caused in this way.

< 1.4 > Connection to USB Server via DVI-D console cable

< 1.4 > Connection to external KVM via DVI-D console cable

AC Input

100~240V

LCD Console Drawer

USB server

DVI-D

console cable

DVI-DUSB

POWER

DVI-D

USB

POWER

DVI console KVM

LCD Console Drawer

DVI-D

console cable

DVI-D

USB

AC Input

100~240V

P.5

Environmental

Conditions Operating Temperature 0 to 55°C degree

Humidity 20~90%, non-condensing

Altitude 16,000 ft

Storage /

Non-operating Temperature -20 to 60°C degree

Humidity 5~90%, non-condensing

Altitude 40,000 ft

Shock 10G acceleration (11ms duration)

Vibration 10~300Hz 0.5G RMS random

Power Power Supply Range Auto-sensing 100 to 240VAC,

50 / 60Hz

Power Consumption

for Single Console Screen ON Max. 28W

Power saving mode Max. 2W

Power button OFF Max. 1W

Power Consumption

with KVM integration Screen ON Max. 62W

Power saving mode Max. 34W

* For details, please refer to our KVM rear kit user manuals

Regulatory Safety FCC & CE certiﬁed

Environmental RoHS3 & REACH compliant

LCD

Panel Manufacturer

Panel Size ( diagonal ) 21.5-inch Widescreen TFT color LCD

Display pixel ( dots x lines ) 1920 x 1080

Brightness ( typ. ) 250

Contrast Ratio ( typ. ) 1000:1

Color 16.7 M

ViewingAngle ( L/R/U/D ) 85/85/80/80

Response Time ( ms ) 5

Dot pitch ( mm ) 0.248

Display Area ( mm ) 476.64H x 268.11V

Surface treatment Haze 25%, Hard-coating

Surface hardness 3H

Backlight Type LED

MTBF ( hrs ) 30,000

< Part 2 >

< 2.1 > Product Speciﬁcations

Video

Connectivity Digital HDMI HDMI 1.4, HDCP 1.4

DVI DVI-D, TMDS single link

Analog VGA Analog 0.7Vp-p

Plug & Play DVI / VGA VESA EDID structure 1.3

Synchronization VGA Separate, Composite & SOG

P.6
