HARDWARE MANUAL

8:20 AM 04-10-00

QZ. ABC

DEF

GHI

JKL MNO

TUV WXY

- P

IN OUT

CLEAR

ALPHA

ENTER

BACK

PACE

Data Collection Terminal

FCC Warning:

Note: This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 1 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. The equipment

generates, uses, and can radiate radio frequency energy. If not installed and

used in accordance with the instruction manual, it may cause interference with

the radio and television reception in a residential area, in which case the user

will be required to correct the interference at his or her own expense.

If this equipment causes interference, try to correct the problem by:

 Reorienting the receiving antenna.

 Relocating the terminal with respect to the receiver with which it inter-

feres.

 Plugging the terminal into a different AC outlet, and putting the terminal

and receiver on different branch circuits.

FCC Compliance: (on hardware equipped with modem)

This equipment complies with Part 68 of FCC Rules. Upon request, furnish the

following information to the telephone company (telco).

 Manufacturer: Acroprint Time Recorder Co., Inc.

 Model: Badger II Terminal

 FCC registration number: 4G3USA-21602-DT-E

 Ringer equivalence: 0.7B

 USOC modular telephone jack: R-J11

Lithium Battery Caution:

This circuit board on this terminal is populated with a lithium battery to protect

data or programs stored in the Random Access Memory (RAM). Do not, under

any circumstances, attempt to replace the lithium battery in the terminal.

Failure to comply may invalidate your warranty. Battery replacement should be

done by qualified personnel wearing the proper eye protection.

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace

only with the same or equivalent type recommended by the manufacturer.

Discard used batteries according to the manufacturers instruction.

Declaration Of Conformity According To EMC Directive 89/336/EEC

We declare under our sole responsibility that the magnetic stripe and/or bar

code reading and/or data recording equipment Badger II 01-0119-000/003/

00 /007 to which this declaration relates are in conformity with the following

standards: EN 022:1987, EN 0082-1, IEC 801-2, IEC 801-3, IEC 801-4,

IEC 801- . I, the undersigned, hereby declare that the equipment specified

above conforms to the above directive and standards.

Raleigh, North Carolina USA

October 7, 2002 W. Glenn Robbins

Acroprint Time Recorder Company

Table of Contents

1. Introduction ................................................................. 4

Basic hardware and variations ................................................ 4

General specifications............................................................. 5

2. Setup ............................................................................ 6

Site requirements .................................................................... 6

Unpackin and inspection ...................................................... 6

Mountin ................................................................................ 7

Power up ................................................................................. 7

3. Operator interface ....................................................... 8

ADCT Keypad ........................................................................ 8

DataLo Keypad ..................................................................... 8

Card reader ............................................................................. 9

4. Ports and connections ............................................. 10

Acroprint Data Collection Terminal setup instructions ........ 10

Ethernet port ......................................................................... 13

RS-232 Serial port ................................................................ 14

RS-232 Serial printer cables ................................................... 15

Local Area Network: RS-485 serial port .............................. 16

RS-485 Serial cables............................................................. 17

Modem port .......................................................................... 18

Modem cables ....................................................................... 19

Wand port ............................................................................. 20

Wand and Y-Cable ................................................................ 21

Parallel port........................................................................... 22

Parallel cable......................................................................... 23

5. Companion products ................................................ 24

Printer ................................................................................... 24

Readers ................................................................................. 24

Power Supplies ..................................................................... 25

External Relay Box, External Buzzer ................................... 25

Cables ................................................................................... 26

Cables, Converter, Bad e Racks........................................... 27

Table of Contents

Basic hardware and variations

The electronic hardware is a new, versatile platform desi ned for

use with various applications. This manual describes, in detail, the

electronic hardware aspects of the terminal you have purchased.

The details concernin terminal firmware and host software are

addressed in the manual which comes with the software.

All terminals are equipped with:

1) a ma netic stripe readin head

2) a 2 row x 20 character per row display

3) a 16-key full travel keypad

4) an RS-232 serial port

5) a wand port for optional bar code wand

6) two control lines for external relay control (door access,

and bell rin er are typical applications)

7) a 25-pin parallel port

The terminal is offered in different hardware variations. Listed

below are the variations by part number and description:

Part # Description

C - Programmable e-prom (DataLog)

01-0120-000 DataLog with LAN (RS-485)

01-0120-002 DataLog with Modem (no LAN)

01-0120-003 DataLog with LAN & Inte nal Visible Ba Code Reade

01-0120-004 DataLog with Modem & Inte nal Visible Ba Code Reade

01-0120-005 DataLog with LAN & Inte nal Inf a ed Ba Code Reade

01-0120-006 DataLog with Modem & Inte nal Inf a ed Ba Code Reade

01-0120-008 DataLog with Ethe net

01-0120-010 DataLog with Ethe net & Inte nal Visible Ba Code Reade

01-0120-012 DataLog with Ethe net & Inf a ed Ba Code Reade

Acrocomm e-prom (Acroprint Data Collection Terminal  ADCT)

01-0147-000 Ac op int with LAN (RS-485)

01-0147-002 Ac op int with Modem (no LAN)

01-0147-003 Ac op int with LAN & Inte nal Visible Ba Code Reade

01-0147-004 Ac op int with Modem & Inte nal Visible Ba Code Reade

01-0147-005 Ac op int with LAN & Inte nal Inf a ed Ba Code Reade

01-0147-006 Ac op int with Modem & Inte nal Inf a ed Ba Code Reade

01-0147-008 Ac op int with Ethe net

01-0147-010 Ac op int with Ethe net & Inte nal Visible Ba Code Reade

01-0147-012 Ac op int with Ethe net & Inf a ed Ba Code Reade

Note: The part number of your unit can be found on the serial

number label on the back of the terminal.

1. Introduction

Introduction

General specifications

A. Enclosure: 8.7 in. (23 cm) wide x 6.1 in. (16 cm) tall x 2.3

in. (6 cm) deep. Clamshell construction of 0.125 in. (3

mm) thick Polycarbonate/ABS injection molded flame

retardant plastic. Includes reversible mountin bracket and

access door which protects I/O ports.

B. Multilayer main lo ic board with internal round and power

planes.

C. Z-180 Microprocessor.

D. Up to 512 Kbyte confi urable memory. Most common

confi uration is 64K ROM and 128K RAM.

E. Lithium battery backed RAM.

F. Real Time Clock Chip on-board.

G. Ma netic card reader: Track 2 ABA recordin head for readin

standard Credit Card format throu h the slot.

. Display: 2 lines with 20 characters on each line. ADCT is backlit.

I. Keypad: Full travel keys with elastomeric contact pad, 4 rows x

4 columns.

J. Serial Port: RS-232 usin 6 position (4 contact) RJ-11 modular

connection.

K. Serial Port: RS-485 (Local Area Network) usin RJ-11 modular

connection.

L. Parallel port: 25-pin DB connection.

M. Internal Modem: Bell 212A (1200bps) and 103 (300bps) ,

CCITT V.22 bis (2400 bps) and V.22 (1200 bps), asynchro-

nous, licensed for use over public telephone lines.

N. Internal Multi-Frequency Piezo Electric Buzzer.

O. Internal Bar Code Reader: Visible or Infrared Bar Code

readin throu h the slot.

P. Control lines: Two pins of the 6-pin circular DIN connector

can be used with external relay box to control devices such

as door locks and bells.

Q. External Bar Code port: 6-pin DIN connection for external

Bar Code Wand or Bar Code Gun.

R. Power: Wall mount transformer, 9 Volts AC/DC 800 mA

minimum or 10 Volts AC/DC 700 mA minimum, with

female secondary plu size 2.1 x 5.5 mm.

Introduction

2. Setup

Site requirements

The terminal can be installed in any normal office or controlled

factory environment. However, do not use the terminal under the

followin conditions:

 extremely hi h or low temperature

[operating temperature range: 0° to 50° C (32° to 122° F ]

[storage temperature range: -20° to 60° C (-4° to 140° F ]

 extremely hi h or low humidity

[operating humidity range : 0 to 90% RH non-condensing]

 areas of hi h dust concentration

 areas with chemical fume concentration

 areas with extreme vibration or when placed on an unstable or

unlevel surface

Unpacking and inspection

Havin opened the shippin carton, carefully remove the con-

tents. Inspect the terminal and accessories for dama e. Report

dama e or shorta es to the company from which the unit was

purchased. Complete the re istration card with all important

information.

(1) Terminal

(1) Power Supply

(4) Mounting Screws (1) Manual

8:20 AM 04-10-00

QZ. ABC

DEF

GHI

JKL MNO

TUV WXY

- P

IN OUT

CLEAR

ALPHA

ENTER

BACK

PACE

Setup

HARDWARE MANUAL

8:20 AM 04-10-00

QZ.ABC

DEF

GHI

JKLMNO

TUVWXY

-P

IN OUT

CLEAR

ALPHA

ENTER

BACK

PACE

Data Collection Terminal

Mounting

Unscrew the access door. With the door off, the main unit can be

slid upward and removed from the mountin bracket. The bracket

can be used for wall mountin , or it can be reversed to tilt the unit

on a desktop.

Power up

Plu in the power cord comin from the wall mount transformer into

the terminal. Reattach the access door and secure the unit to the

reversible bracket. Replace screw on the access door.

NOTE: Other connections are made in the same fashion. Notice

the channels in the bracket available for cable routin . Also, the

bracket has throu h-holes for further securin of cables usin

ties.

Setup

3. Operator interface

ADCT Keypad

The terminal has 16 keys for enterin alphabetical and numeric

data as illustrated below.

QZ.

ABC

DEF

GHI

4JKL

MNO

PRS

TUV

WXY

-SP

CLEAR

ENTER

BACK

SPACE

ALPHA

IN OUT

Operator interface

DataLog Keypad

The terminal has 16 keys for enterin data as illustrated below.

123

456

789

CLEAR

ENTER

Optionally, the terminal can also have an internal bar code reader.

The card is swiped throu h in the same fashion, but the Bar Code

should be on the left side of the card when swiped.

NOTE: For throu h-the-slot readin , Bar Code should be located

on card as shown.

Magnetic stripe -

right side

Bar Code - left side

1.00" Min.

0.25" Nominal

Operator interface

Card reader

The terminal has an internal ma netic stripe card reader. The

ma netic stripe on the card should be on the ri ht side when the

card is swiped as shown below.

4. Ports and connections

Acroprint Data Collection Terminal setup instructions

Configuring procedure for entering the DATE & TIME:

Swipe the Confi uration Bad e 000000000

(This bad e is provided with each terminal)

Select option 1 for DATE <Press ENTER>

Select the Day, Month, Year DDMMYYYY <Press ENTER>

Select the Time HH:MM <Press ENTER>

(Time is entered in military time, 2:00 pm = 14:00)

Configuring procedure for selecting PORTS:

Swipe the Confi uration Bad e 000000000

(This bad e is provided with each terminal.)

Select option 2 for Ports <press ENTER>

Select option 0 for RS232 <press ENTER>

Select the baud rate 0 for 1200, 1 for 2400, 2 for 4800, 3 for 9600

and 4 for 19,200 baud. <press ENTER>

(For modem terminal only)

Select option 1 for Modem <press ENTER>

Select the Modem baud rate 0 for 1200 and 1 for 2400 baud

Select the Answer Window HHMMHHMM for startin and

endin times <press ENTER> (time is in military format, Example:

Clock will not answer durin business hours and only answer between

the hours of 8:00 pm and 6:00 am, then select 20000600.)

Ports and connections

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Acroprint IP-Zugriffskontrollsysteme Handbücher

Acroprint

Acroprint Time Q Bedienungsanleitung

Beliebte IP-Zugriffskontrollsysteme Handbücher anderer Marken

ZKTeco

ZKTeco SpeedFace-V5L Bedienungsanleitung

Jantar

Jantar REX A-1-9 Bedienungsanleitung

2N Access Unit Merkblatt

Kedacom

Kedacom KSCA120 Series Bedienungsanleitung

H3C

H3C WX2880X Bedienungsanleitung

G4S

G4S S870-EX Leitfaden

PRASTEL

PRASTEL M2000PE Bedienungsanleitung

Allegion

Allegion interflex IF-281 Cylinder Bedienungsanleitung

TECOM

TECOM TS1067E Bedienungsanleitung

Fermax

Fermax Memokey 100C Benutzerhandbuch

Fermax

Fermax CITYLINE MEMOKEY Bedienungsanleitung

Software House

Software House iSTAR Pro 2U RM Bedienungsanleitung

AKCP

AKCP SP+ Bedienungsanleitung

Bpt

Bpt HNA/102 Bedienungsanleitung

Civintec

Civintec CV9601T-T-1F Bedienungsanleitung

BioMax

BioMax N-X90W Bedienungsanleitung

ZKTeco

ZKTeco OP-200 Bedienungsanleitung

FingerTec

FingerTec s-Kadex Bedienungsanleitung
