ACTi ACM-8511 Bedienungsanleitung

IP PTZ

Camera

ACM-8511

Ver. 080912

Quick Installation Guide

0-1

0Getting Started

1.1 PACKAGE CONTENTS

ACM-8511 Power Adaptor (Option)

Product CD Terminal Blocks & Screw

Warranty Card Accessory

0-2

1.2 PHYSICAL DESCRIPTION

1. Power Input

If your power input is DC12V.

2. Ethernet Port

The IP device connects to the Ethernet via a standard RJ45

connector. Supporting NWAY, this IP device can auto detect the

speed of local network segment (10Base-T/100Base-TX

Ethernet).

3. Reset Button

Step 1: Switch off IP device by disconnecting the power cable

Step 2: Press and continue to hold the Reset Button. Reconnect the

power cable while continuing to hold the reset button.

Step 3: Keep holding the reset button depressed around 6 seconds,

release the reset button. The unit will start up with factory default

settings.

4. Audio Input

The IP device supports audio input with earphone jack

5. Audio Output

The IP device supports audio output with earphone jack

6. The I/O Terminal Connector

Used in applications for e.g. motion detection, event triggering,

time lapse recording, alarm notifications, etc., the I/O terminal

connector provides the interface to:

0-3

•1 transistor output - For connecting external devices such as relays

and LED’s. Connected devices can be activated by Output buttons on

the Live View page or by an Event Type. The output will show as

active (in Event Configuration > Port Status) if the alarm device is

activated.

•1 digital input - An alarm input for connecting devices that can toggle

between an open and closed circuit, for example: PIRs, door/window

contacts, glass break detectors, etc. When a signal is received the state

changes and the input becomes active (shown under Event

Configuration > Port Status).

•Auxiliary power and GND

GND Pin 1 Ground Description

Auxiliary

Power

input

(not to

power

this

camera)

Pin 2 Electrically connected in parallel with the con-

nector for the power supply, this pin provides an

auxiliary connector for mains power to the unit.

This pin can also be used to power auxiliary

equipment, with a maximum current of 100mA.

Voltage: 12V DC,

Max: 1.2W

Digital

Input

Pin 3 Connect to GND to activate, or leave floating (or

unconnected) to deactivate.

Must not be exposed to

voltages greater than 30V

DC.

Transistor

Output

Pin 4 Uses an open-collector NPN transistor with the

emitter connected to the GND pin. If used with an

external relay, a diode must be connected in

parallel with the load, for protection against

voltage transients.

Max load = <100mA

Max voltage = 24V DC

(to the transistor)

The I/O terminal pins are numbered left to right, as shown below.

Connect input/output devices to the camera as follows:

1. Attach the cables for the device securely to the supplied green connector

block.

2. Once the cables are connected, push the connector block into the terminal

0-4

connector (also green) on the camera.

FUSE 1A

NPN

DC TO DC

3.3V

DC POWER

GND

CONVERTER

EARTH GND

RELAY

DIODE

DEVICE

POWER INPUT

CAMERA

0-1

1.3 BASIC CONNECTIONS

Follow the procedures below to connect the IP device to the respective

apparatuses.

1. Connect the power adaptor to IP device

2. Connect IP device’s ethernet port to an Ethernet (RJ45 connectors). If your

IP device has PoE built-in, you can regard it as a PD and connect it

directly to a PSE device like PoE switch.

3. Connect a PC to the Ethernet hub (RJ45 connectors)

NOTE: You may find a support package for help you getting familiar

with PoE. Please visit our web site, and get the support document

TS-00040.

1-2

1Quick Tour

This section guides you with a quick tour on this IP device.

2.1 Configure this IP Device

2.1.1 Make sure network environment

Default IP of this IP device is 192.168.0.100. Please make sure this IP device and

your PC are on the same network segment before running the installation.

Please set the settings as below.

IP address: 192.168. 0.xxx

Subnet mask: 255.255.255. 0

(NOTE: xxx should be a number

from 1 to 254, but 100 is

excepted.)

1-3

2.1.2 Open Internal Explorer with IP address

NOTE: If your web browser is earlier than IE6, then download IE6 is

recommended.

NOTE: This IP device default IP address is set to 192.168.0.100

2.1.3 Login with default administrator’s account & password

NOTE: Default administrator account is set to Admin, password is set to

123456, and click button.

1-4

2.1.4 Preview the video

2.1.5 Set the new IP address

1-5

*IP Address : The default IP address is 192.168.0.100.

*Subnet Mask : The default subnet mask is 255.255.255.0

*Click button

NOTE: In your Client PC, please make sure the setting of Network

Connections Type is set to Auto Negotiation, since this IP device follows

MII standard. Otherwise, you might not see the live image.

IMPORTANT: After the IP address is changed, please record this IP

address. There’s no way to connect to the IP device if user forgets the

new IP address.

2.1.6 Check Default Video Setting

NOTE: Please make sure the TV Input (NTSC / PAL) is meet your

requirement, and click button.

2.1.7 Click Save Reboot to restore all settings and please wait about 30 seconds

for system reboot.
