ActionTec GT701 Bedienungsanleitung

Solutions for the Digital Life™

User Manual

USB/Ethernet

DSL Modem

Model #: GT701

Firmware #: GT3.0.1.0.5.1

Table of Contents

1 Introduction 1

Package Contents 1

Minimum System Requirements 2

Features 2

Getting to Know the Modem 3

2 Setting Up the Modem 7

Connecting a Computer to the Modem 7

Installing Phone Filters 21

Setting Up the DSL Connection 26

3 Performing a Basic Setup 29

Basic Setup 29

Changing the Admin User Name and Password 32

4 Using Advanced Setup 33

Accessing Advanced Setup 33

WAN IP Address 34

LAN IP Address 39

DHCP Server 40

Services Blocking 42

Website Blocking 43

Remote Management 44

Port Forwarding 44

DMZ Hosting 46

Firewall 46

Dynamic Routing 47

NAT (Network Address Translation) 47

Static Routing 48

5 Viewing the Modem’s Settings 49

Status 49

Routing Table 51

WAN Status 51

LAN Status 52

Active User List 52

6 Using Utilities 53

Web Activity Log 53

DSL Settings 54

Restore Default Settings 54

Upgrade Firmware 55

7 Troubleshooting 57

Troubleshooting 57

Frequently Asked Questions 58

Actiontec USB/Ethernet DSL Modem User Manual

A Reference 63

Locating Computer Information 63

Locating Windows Operating System Files 64

B Setting Up Static IP on the Computer 67

Windows 98 SE 67

Windows Me 70

Windows 2000 73

Windows XP 77

C Computer Security 81

Comparing DSL Service with a Dial-Up Modem 81

Modem Security 82

Computer Security 82

Electronic Security 83

D Specifications 85

General 85

LED Indicators 86

Environmental 86

E Glossary 87

F Firewall Security Level Services Table 91

High Security Level 91

Medium Security Level 92

Low Security Level 92

Basic Security Level 93

Service Acronym Definitions 93

G Non-Windows System Setup 95

Classic 95

OS X 97

H Installation Buddy Settings 99

Notices 101

Regulatory Compliance Notices 101

Modifications 101

Miscellaneous Legal Notices 102

Limited Warranty 103

Index 107

Introduction

Thank you for purchasing the Actiontec USB/Ethernet DSL Modem. The Modem

is the simplest way to connect computers to a high-speed broadband connection.

This easy-to-use product is perfect for the home office or small business. If you

want to take your computing to the next level, the Actiontec USB/Ethernet DSL

Modem is sure to be one of the keys to your success.

Package Contents

s Actiontec USB/Ethernet DSL Modem

s Black bag (includes Power cord and gray DSL cable)

s Phone filters

s Yellow (Ethernet) cable

s Blue (USB) cable

s Installation CD

s Quick start guide

Actiontec USB/Ethernet DSL Modem User Manual

Chapter 1 Introduction

Minimum System Requirements

s Active DSL service

s Computer with a 10/100 Mbps Ethernet connection, or USB connection

☞ Note: USB LAN port is not supported with Microsoft Windows

95, Windows NT 4.0, and Mac OS.

s Microsoft Windows 98 Second Edition (SE), Windows Millennium Edition

(Me), Windows NT 4.0, Windows 2000, Windows XP, Mac OS 7.1 and above

s Internet Explorer 4.0 or higher (5.x recommended) or Netscape Navigator

4.0 or higher (4.7 recommended)

s TCP/IP network protocol installed on each computer

Features

s Plug-and-Play installation support for systems with Windows operating

systems (98, 98SE, Me, 2000, and XP)

s ADSL WAN port (RJ-11)

s Compliant with full-rate ANSI T1.413 Issue 2, ITU G.992.1 (G.dmt) and

G.992.2 (G.lite) standard

s Auto-handshake for different ADSL flavors

s USB 1.1 device specification compliance

s 11 Mbps USB data rate (full speed)

s Bridged Ethernet over ATM, PPP over ATM, PPP over Ethernet

s Precise ATM traffic shaping

s IP packet routing and transparent bridge

s Routing protocol supports RIP-1, RIP-2, static routing

s Built-in NAT, DHCP server

s DNS relay support

s PAP/CHAP authentication, administrative passwords through Telnet

Actiontec USB/Ethernet DSL Modem User Manual

Chapter 1 Introduction

s Compliant with IEEE 802.3 Ethernet standard

s 10/100 Base-T Ethernet port

s Flow control support for Fast Ethernet

s Web-based configuration setup

s Default configuration backup restore

s FTP firmware upgradeable

s Web download support

Getting to Know the Modem

This section contains a quick description of the Modem’s lights, ports, etc.

The Modem contains several indicator lights (LEDs) on its front panel and a series

of ports on its rear panel.

Front Panel

The front panel of the Modem features five lights (or LEDs): Power, DSL, Internet,

Ethernet, and USB.

Power

DSL

Internet

Ethernet

USB

Power

DSL InternetEthernetUSB

USB/Ethernet

DSL Modem

Actiontec USB/Ethernet DSL Modem User Manual

Chapter 1 Introduction

Power Light

The Power light displays the Modem’s current status. If the Power light glows

steadily green, the Modem is receiving power and fully operational. When the

Power light flashes rapidly, the Modem is initializing. If the Power light is not

illuminated when the Power cord is plugged in, the Modem has suffered a criti-

cal error and technical support should be contacted.

DSL Light

The DSL light illuminates when the Modem is connected to a DSL line.

Internet Light

When the Internet light glows steadily, the Modem is connected to the DSL

provider. When it flashes, the Modem’s built-in DSL modem is training for

DSL service. When it glows red, the Modem failed to connect to the Internet.

Ethernet Light

The Ethernet light illuminates when the Modem is connected via its

Ethernet port.

USB Light

The USB light illuminates when the Modem is connected via its USB port.

Actiontec USB/Ethernet DSL Modem User Manual

Chapter 1 Introduction

Rear Panel

The rear panel of the Modem contains four ports (Phone, USB, Ethernet, and

Power), as well as an On/Off switch and Reset button.

Power

Reset

Phone

USB

Ethernet

Black Power Cord

(from black Power

port to Power Outlet)

Yellow Ethernet Cable

(from yellow Ethernet

port to Computer)

Blue USB Cable

(from blue USB

port to Computer)

Gray DSL Cable

(from gray Phone

port to Phone Jack)

Phone Port

The Phone port is used to connect the Modem to a phone jack.

USB Port

The USB port is used to connect a computer to the Modem via USB cable.

Ethernet Port

The Ethernet port is used to connect a computer to the Modem via Ethernet

cable. The Ethernet port is a 10/100 Mbps auto-sensing port, and either a straight-

through or crossover Ethernet cable can be used when connecting to the port.

Actiontec USB/Ethernet DSL Modem User Manual

On/Off Switch

The On/Off switch controls power to the Modem. When the top of the switch is

depressed, the Modem is powered off. When the bottom of the switch is depressed,

the Modem is powered on (assuming the Power cord is correctly connected).

N Warning: Do not power down the Modem using the On/Off

switch during the reset process. Doing so may result in perma-

nent damage to the Modem.

Reset Button

Depressing the Reset button for one or two seconds will power cycle the Modem

(similar to unplugging and then plugging in the Modem’s Power cord). To

restore the Modem’s factory default settings, depress and hold the Reset button

for approximately 15 seconds. The reset process will start about 10 seconds after

releasing the switch.

Power Port

The Power port is used to connect the Power cord to the Modem.

N Warning: Do not unplug the Power cord from the Modem’s

Power port during the reset process. Doing so may result in per-

manent damage to the Modem.

Setting Up

the Modem

The instructions that follow in this chapter parallel the steps contained in the

Actiontec Installation Buddy®, which provides a visual, step-by-step guide to setting

up the Modem. It is recommended the user run the Installation Buddy first, before

attempting any other procedures.

If your Internet Service Provider (ISP) provided a welcome letter or worksheet

containing information needed to complete the installation, have it available. If this

document was not received, contact the ISP to get the needed information.

☞ Note: The following procedures are for US installations. If you

live in the UK or another country, the procedures will be slightly

different.

Connecting a Computer to the Modem

Connecting a computer to the Modem involves three steps: initial setup, plugging

in the power cord, and connecting the Modem to the computer and phone jack.

Connecting Via Ethernet

1. Insert the Installation CD in the CD-ROM drive of the computer. The

Installation Buddy starts automatically. Wait until the following screen

appears, read the on-screen instructions, select the country in which you live

by clicking in the appropriate check box, then click Next.
