Active Audio StepArray+ Bedienungsanleitung

L'acoustique active

User Manual

StepArray+

Self-powered digitally steerable column loudspeakers

2/24 3/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

Table of contents

1. Introduction...............................................................................4

2. System components ...................................................................5

3. Assembling ................................................................................6

4. Wiring .......................................................................................7

4.1. Example setup using Dante® ................................................7

5. StepArray+ control software........................................................8

5.1. System requirements.............................................................8

5.2. Installation on Windows ........................................................8

5.3. Installation on OS X ..............................................................9

5.4. Using the StepArray+ software ............................................10

6. Installation of the columns........................................................ 12

6.1. Dimensions of the brackets.................................................. 13

7.Specications ...........................................................................14

8. Acoustical data.........................................................................16

8.1. Common data ..................................................................... 16

8.2. SA100P / SA150P+ acoustical data1.................................................................... 17

8.3. SA180P / SA230P+ acoustical data1.................................................................... 18

8.4. SA250P / SA300P+ acoustical data1.................................................................... 19

8.5. SA400P / SA450P+ acoustical data1.................................................................... 20

8.6. SA180S / SA230S+ acoustical data1.................................................................... 21

8.7..SA250S / SA300S+ acoustical data1.................................................................... 22

9. Declaration of conformity..........................................................23

4/24 5/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

1. Introduction

StepArray+ column speakers ensure perfect speech intelligibility and optimal

acoustic comfort, even in noisy and reverberant venues. They are based on

the DGRC (Digital & Geometric Radiation Control) principle patented by Active

Audio.

Compared with a classic sound system in which each loudspeaker is controlled

independently, the DGRC method makes it possible to decrease the number of

channelstobecontrolled,therebyenhancingeconomicefciency.

StepArray+ also allows the use of existing network cables and helps to achieve

signicantsavingsinwiring,withupto64channelsonasingleEthernetcable.

StepArray+ combines the features of DanteTM and StepArray to achieve ever

higherlevelsofefciencyandexibility.

The StepArray+ range includes 6 models of column speakers, from 1.50m to

4.50m high.

SA150P+

1.50m high

at area, 21m

3 channels

8Ω min.

SA230P+

2.30m high

at area, 40m

3 channels

8Ω min.

SA230S+

2.30m high

10° area, 29m

3 channels

8Ω min.

SA300P+

3.00m high

at area, 45m

6 channels

4Ω min.

SA300S+

3.00m high

12° area, 36m

6 channels

4Ω min.

SA450P+

4.50m high

at area, 90m

6 channels

8Ω min.

2. System components

StepArray+ columns are made of two parts: a standard StepArray passive co-

lumn,anditscompanionStepArray+ampliermodule.

StepArray+

amplifier module

StepArray

passive column

Figure 1 :

System components

6/24 7/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

3. Assembling

1. Remove the back

plate of the amplifier

module.

2. Place the amplifier

module at the top of

the passive column.

3. Secure the amplifier

module using the

supplied M8 nut.

4. After wiring, close

the connection box by

mounting the back

plate.

Figure 2 :

Assembling StepArray+ columns

4. Wiring

INPUT

OUTPUTS

LINK/

ACT

SP EED

4 -6

1 -3

StepArray series - patent FR-0403052 EU-05736-560.3 US-10-593.821 CN-7965608A

123

100-240V ~ 50-60Hz

Made in France

Ethernet

for Dante

and tuning

Power cord

Analog

input

Output to passive column module

(using supplied cable)

Figure 3 :

Wiring StepArray+ columns

4.1. Example setup using Dante®

E t h er n et s wi t c h

E t h er n et Controller

A u d io so u rc e

M i c ro p h o n e r e c ei ver

M ic ro p h on e s

M at r i x

E t h er n et sw it c h C o n f e r e n c e r o o m

SA300P+ SA300P+

Figure 4 :

StepArray+ setup using Dante network

8/24 9/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

5. StepArray+ control software

The StepArray+ control software is available for Windows and OSX operating

systems. Installers can be found on the supplied USB key or on Active Audio’s

website by following this link: http://www.activeaudio.fr/ downloads.

5.1. System requirements

Processor 1Ghz or better

Memory 512Mbyte of RAM

Network Standard wired Ethernet network interface (100Mbps or Gigabit).

Wireless LAN (Wi-Fi) Ethernet interfaces are not supported

Operating System Windows 7 SP1 or newer Mac OS X 10.7.5 or newer

5.2. Installation on Windows

Start the installer package by double-clicking on it, then follow the instructions.

Figure 5 :

StepArray+ Software installation on Windows

5.3. Installation on OS X

Start the installer package by double-clicking on it, then follow the instructions.

Figure 6 :

StepArray+ Software installation on OS X

Group gain

Group ID

10/24 11/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

5.4. Using the StepArray+ software

The StepArray+ control software gives access to the following functions:

• input selection: Dante or analog input

• general output volume

• steering parameters for directivity control

The StepArray+ control software does not include

Dante routing functionality. When using Dante to

transmit audio, you will need the Dante Controller

software to assign Dante channels to StepArray+ co-

lumns.

Dante Controller is available free of charge from the

Audinate website: https://www.audinate.com/pro-

ducts/software/dante-controller.

WhenlaunchingtheStepArray+controlsoftware,therstscreenlistsallthe

StepArray+columnsitcanndonthenetwork.TherstconnectiontoaSte-

pArray+ column can take up to 1 minute: this is the time needed to initiate the

communication.

Figure 7 :

StepArray+ control software: main screen

AclickonaStepArray+boxleadstothesettingsscreenofthatspeciccolumn.

All the parameters of the column can be changed within that screen.

Figure 8 :

StepArray+ control software: column settings screen

12/24 13/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

6. Installation of the columns

StepArray+ columns are mounted vertically, usually on a wall, using the sup-

plied brackets. Figure 9 illustrates the steps to follow for column mounting. See

alsogure10onthenextpagefortechnicaldrawingsofthebrackets.

Place

the 2 brackets

on the wall

using 8mm

diameter screws

Column height

+ 5mm

Ensure

verticality

Mount the column

using the supplied

nut and screw

Figure 9 :

Column mounting on a wall

It is important to ensure verticality when mounting

StepArray+ columns.

6.1. Dimensions of the brackets

121.51

ϕ11

2 52 5

96.51

35.65

82.89

34.42

ϕ8.5

11 11

71.22

Red is bottom bracket only

Figure 10 :

Fixing brackets for wall mounting of StepArray columns

14/24 15/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

7. Specications

Electrical data

max output power 450W

max continuous output power (25°) 300W

power consumption Idle 22W

Typ. 80W

Max 500W

number of Channels 3

power supply 85-264VAC

45-65Hz

Inputs

1x balanced analog 3-pin input

1x DanteTM input

Network

1x RJ45 connector, DanteTM

max. operating ambient temperature 60°C

SA150P+

Acoustical data

range ±3dB 30m

range ±5dB 40m

max SPL 95dBSPL at 15m

angle of audience 0°-5°

frequency bandwidth (-10dB) 110Hz-19kHz

horizontal opening angle 180°

Mechanical data

net weight 22 kg

shipping weight 24 kg

height 2340mm

width 124mm

depth 135mm

standard colors white RAL 9016

black RAL 9005

SA150P+

1.50m high

at area, 21m

3 channels

8Ω min.

SA230P+

2.30m high

at area, 40m

3 channels

8Ω min.

SA230S+

2.30m high

10° area, 29m

3 channels

8Ω min.

SA300P+

3.00m high

at area, 45m

6 channels

4Ω min.

SA300S+

3.00m high

12° area, 36m

6 channels

4Ω min.

SA450P+

4.50m high

at area, 90m

6 channels

8Ω min.

Attention: police Trade Gothic

SA230P+

Acoustical data

range ±3dB 22m

range ±5dB 29m

max SPL 95dBSPL at 15m

angle of audience 5°-20°

frequency bandwidth (-10dB) 110Hz-19kHz

horizontal opening angle 180°

Mechanical data

net weight 22 kg

shipping weight 24 kg

height 2340mm

width 124mm

depth 135mm

standard colors white RAL 9016

black RAL 9005

SA150P+

1.50m high

at area, 21m

3 channels

8Ω min.

SA230P+

2.30m high

at area, 40m

3 channels

8Ω min.

SA230S+

2.30m high

10° area, 29m

3 channels

8Ω min.

SA300P+

3.00m high

at area, 45m

6 channels

4Ω min.

SA300S+

3.00m high

12° area, 36m

6 channels

4Ω min.

SA450P+

4.50m high

at area, 90m

6 channels

8Ω min.

Attention: police Trade Gothic

SA230P+

Electrical data

max output power 450W

max continuous output power (25°) 300W

power consumption Idle 22W

Typ. 80W

Max 500W

number of Channels 3

power supply 85-264VAC

45-65Hz

Inputs

1x balanced analog 3-pin input

1x DanteTM input

Network

1x RJ45 connector, DanteTM

max. operating ambient temperature 60°C

Electrical data

max output power 450W

max continuous output power (25°) 300W

power consumption Idle 22W

Typ. 80W

Max 500W

number of Channels 3

power supply 85-264VAC

45-65Hz

Inputs

1x balanced analog 3-pin input

1x DanteTM input

Network

1x RJ45 connector, DanteTM

max. operating ambient temperature 60°C

Acoustical data

range ±3dB 15m

range ±5dB 21m

max SPL 95dBSPL at 10m

angle of audience 0°-5°

frequency bandwidth (-10dB) 110Hz-19kHz

horizontal opening angle 180°

Mechanical data

net weight 14 kg

shipping weight 17 kg

height 1524mm

width 124mm

depth 131mm

standard colors white RAL 9016

black RAL 9005

Acoustical data

range ±3dB 35m

range ±5dB 45m

max SPL 95dBSPL at 20m

angle of audience 0°-5°

frequency bandwidth (-10dB) 110Hz-19kHz

horizontal opening angle 180°

Mechanical data

net weight 29 kg

shipping weight 33 kg

height 3005mm

width 124mm

depth 159mm

standard colors white RAL 9016

black RAL 9005

SA300P+

Electrical data

max output power 900W

max continuous output power (25°) 600W

power consumption Idle 41W

Typ. 150W

Max 1000W

number of Channels 6

power supply 85-264VAC

45-65Hz

Inputs

1x balanced analog 3-pin input

1x DanteTM input

Network

1x RJ45 connector, DanteTM

max. operating ambient temperature 60°C

SA150P+

1.50m high

at area, 21m

3 channels

8Ω min.

SA230P+

2.30m high

at area, 40m

3 channels

8Ω min.

SA230S+

2.30m high

10° area, 29m

3 channels

8Ω min.

SA300P+

3.00m high

at area, 45m

6 channels

4Ω min.

SA300S+

3.00m high

12° area, 36m

6 channels

4Ω min.

SA450P+

4.50m high

at area, 90m

6 channels

8Ω min.

Attention: police Trade Gothic

Acoustical data

range ±3dB 28m

range ±5dB 36m

max SPL 95dBSPL at 20m

angle of audience 5°-20°

frequency bandwidth (-10dB) 110Hz-19kHz

horizontal opening angle 180°

Mechanical data

net weight 29 kg

shipping weight 33 kg

height 3005mm

width 124mm

depth 159mm

standard colors white RAL 9016

black RAL 9005

SA150P+

1.50m high

at area, 21m

3 channels

8Ω min.

SA230P+

2.30m high

at area, 40m

3 channels

8Ω min.

SA230S+

2.30m high

10° area, 29m

3 channels

8Ω min.

SA300P+

3.00m high

at area, 45m

6 channels

4Ω min.

SA300S+

3.00m high

12° area, 36m

6 channels

4Ω min.

SA450P+

4.50m high

at area, 90m

6 channels

8Ω min.

Attention: police Trade Gothic

SA300S+

Acoustical data

range ±3dB 68m

range ±5dB 90m

max SPL 95dBSPL at 30m

angle of audience 0°-3°

frequency bandwidth (-10dB) 110Hz-19kHz

horizontal opening angle 180°

Mechanical data

net weight 44 kg

shipping weight 47 kg

height 4596mm

width 124mm

depth 135mm

standard colors white RAL 9016

black RAL 9005

SA150P+

1.50m high

at area, 21m

3 channels

8Ω min.

SA230P+

2.30m high

at area, 40m

3 channels

8Ω min.

SA230S+

2.30m high

10° area, 29m

3 channels

8Ω min.

SA300P+

3.00m high

at area, 45m

6 channels

4Ω min.

SA300S+

3.00m high

12° area, 36m

6 channels

4Ω min.

SA450P+

4.50m high

at area, 90m

6 channels

8Ω min.

Attention: police Trade Gothic

SA450P+

Electrical data

max output power 900W

max continuous output power (25°) 600W

power consumption Idle 41W

Typ. 150W

Max 1000W

number of Channels 6

power supply 85-264VAC

45-65Hz

Inputs

1x balanced analog 3-pin input

1x DanteTM input

Network

1x RJ45 connector, DanteTM

max. operating ambient temperature 60°C

Electrical data

max output power 900W

max continuous output power (25°) 600W

power consumption Idle 41W

Typ. 150W

Max 1000W

number of Channels 6

power supply 85-264VAC

45-65Hz

Inputs

1x balanced analog 3-pin input

1x DanteTM input

Network

1x RJ45 connector, DanteTM

max. operating ambient temperature 60°C

16/24 17/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

8.2. SA100P / SA150P+ acoustical data1

20m10m0m

10m

h=2,55m

10dB

5dB

0dB

-5dB

-10d

-15d

-20dB

Figure 13 :

SA100P / SA150P+ vertical directivity: sound level for the voice

octaves (500Hz,1kHz,2kHz) in the vertical median plane

0m 10m 20m

10m

10dB

5dB

0dB

-5dB

-10d

-15d

-20d

Figure 14 :

SA100P / SA150P+ horizontal directivity: sound level for the voice

octaves (500Hz,1kHz,2kHz) on the listening plane

0 2 4 6 8 10 12 14 16 18 20

−15

−10

−5

SPL(dist) SA100P

250Hz

500Hz

1000Hz

2000Hz

4000Hz

8000Hz

Figure 15 :

Sound level by octave in the axis of the listening plane in front of

the column with respect to the distance from the column

8. Acoustical data

All data presented below is obtained with columns in their nominal position and

usingnominalDSPlteringparam-eters(atEQ,etc).

8.1. Common data

102103104

−30

−25

−20

−15

−10

−5

frequency (Hz)

amplitude (dB)

Figure 11 :

Frequency response (column SA250P / SA300P+). Average of the

mesurements at 7, 10, 15, 20, 25, and 30m. In red: with bass high-pass on

position «100Hz», in blue: with bass high-pass on position «200Hz».

330

300

270

-20dB

-10dB

500Hz

1kHz

2kHz

4kHz

8kHz

Figure 12 :

Horizontal directivity (column SA250P/SA300P+)

18/24 19/24ver. 2021/20/02

DOP_1112_A

ver. 2021/20/02

User Manual - StepArray+ series User Manual - StepArray+ series

8.4. SA250P / SA300P+ acoustical data1

20m10m0m 40m30m

10m

50m

h=2,55m

10dB

5dB

0dB

-5dB

-10d

-15d

-20dB

Figure 19 :

SA250P / SA300P+ vertical directivity: sound level for the voice

octaves (500Hz,1kHz,2kHz) in the vertical median plane

0m 10m 20m 30m 40m

10m

20m

50m

10dB

5dB

0dB

-5dB

-10d

-15d

-20d

Figure 20 :

SA250P / SA300P+ horizontal directivity: sound level for the voice

octaves (500Hz,1kHz,2kHz) on the listening plane

0510 15 20 25 30 35 40 45

−15

−10

−5

SPL(dist) SA250P

250Hz

500Hz

1000Hz

2000Hz

4000Hz

8000Hz

Figure 21 :

Sound level by octave in the axis of the listening plane in front of

the column with respect to the distance from the column

8.3. SA180P / SA230P+ acoustical data1

20m10m0m 40m30m

10m

h=2,55m

10dB

5dB

0dB

-5dB

-10d

-15d

-20dB

Figure 16 :

SA180P / SA230P+ vertical directivity: sound level for the voice

octaves (500Hz,1kHz,2kHz) in the vertical median plane

0m 10m 20m 30m 40m

10m

20m

10dB

5dB

0dB

-5dB

-10d

-15d

-20d

Figure 17 :

SA180P / SA230P+ horizontal directivity: sound level for the voice

octaves (500Hz,1kHz,2kHz) on the listening plane

0510 15 20 25 30 35

−15

−10

−5

SPL(dist) SA180P

250Hz

500Hz

1000Hz

2000Hz

4000Hz

8000Hz

Figure 18 :

Sound level by octave in the axis of the listening plane in front of

the column with respect to the distance from the column

Inhaltsverzeichnis

Andere Active Audio Sprecher Handbücher

Active Audio

Active Audio R100SM Bedienungsanleitung

Active Audio

Active Audio CL62 Bedienungsanleitung

Active Audio

Active Audio Vendome Bedienungsanleitung

Active Audio

Active Audio R60 Bedienungsanleitung

Active Audio

Active Audio Ray-On Mini Bedienungsanleitung

Active Audio

Active Audio R80+ Bedienungsanleitung

Active Audio

Active Audio StepArray+ Series Bedienungsanleitung

Active Audio

Active Audio Ray-On B70 PoE Bedienungsanleitung

Active Audio

Active Audio StepArray Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung
