Adam Equipment MIW-20 Bedienungsanleitung

Adam Equipment

MIW-20

BABY SCALE

ADAM EQUIPMENT CO. LTD.

p.n. 4295, Rev. B, March 2004

CONTENTS

1.0 INTRODUCTION .........................................................................................................2

2.0 TECHNICAL SPECIFICATIONS..................................................................................3

3.0 LOCATING THE SCALE..............................................................................................4

4.0 SETTING UP THE SCALE ..........................................................................................4

5.0 KEY DESCRIPTIONS..................................................................................................5

6.0 OPERATIONS.............................................................................................................5

7.0 SELECTION OF UNITS...............................................................................................6

8.0 HOLD FUNCTION .......................................................................................................7

9.0 AUTOMATIC POWER SWITCH OFF..........................................................................7

10.0 CALIBRATION.............................................................................................................8

11.0 ERROR MESSAGES...................................................................................................8

1.0 INTRODUCTION

•The MIW-20 scales are precision medical scales specially designed to

weigh babies on a cradle.

•The scale has a capacity of 20 kg and readability of 0.01 kg.

•The scale displays the weight in kilograms or pounds.

•The scale is fast, accurate and simple to use.

•It operates using an internal alkaline battery (PP3, 9V) supplied as

standard with the scale.

•It has HOLD function to lock the display until the operator releases it.

•Automatic turn off feature after 30 seconds is available to maximise the

battery life.

•Filters are optimised for weighing active babies.

2.0 TECHNICAL SPECIFICATIONS

Specifications

MIW-20

Maximum Capacity, max

20 Kg (44.4 lbs.)

Readability, d

10 g (1/2 oz.)

Tare range, -T

-20 kg (44.4 lbs.)

Battery

One, PP3, 9V

Operating temperature

+5° C / + 35° C

Net weight

2.15 kg (4.73 lbs.)

3.0 LOCATING THE SCALE

•Place the scale on a stable surface. A soft and uneven floor (e.g. carpet,

linoleum) could cause an erroneous weight reading.

•The ambient temperature of the scale should be kept as constant as possible. Do

not place the scale where it may be subjected to draughts or heater and direct

sunlight. It is advisable not to place the scale near windows, air conditioning vents

or radiators.

•The scale should be placed in a location where it is not likely to be damaged by

accidentally dropping heavy weights or moisture on to the scale. The weighing

area should be kept clean.

•Clean the scale with a damp cloth whenever necessary. The bottom of the scale

should be cleaned with a dry cloth only. Never use chemical or abrasive products.

•It is a precision scale and all care should be taken to protect the scale from

vibration, humidity, temperature variations and dust.

4.0 SETTING UP THE SCALE

•The MIW-20 comes with an internal alkaline battery supplied as standard with the

scale.

•Install the battery by removing the battery cover located at the bottom of the main

unit. After connecting the battery, it is to be inserted in the socket provided at the

back of the battery cover and then place the cover back in its original position.

•There is no assembly necessary, simply press the [ON/OFF/TARE] key.

5.0 KEY DESCRIPTIONS

[ON / OFF/TARE]

Turns the scale on or off (keep it pressed for 3 seconds).

Sets a zero condition when the platform is empty.

Sets the display to zero by storing the current weight in the

memory to tare the scale.

[UNIT]

Sets the Units.

[HOLD]

Holds the average display value.

6.0OPERATIONS

•To start weighing, turn the scale on using the [ON/OFF/TARE] key.

•It displays “

0000

” first. If the chosen unit of weight is Kilogram, next it

displays “

0.00

” with a triangle at the top left of the display.

•If the display shows “

0: 0

” with a triangle at the bottom left of the display,

the unit is in pounds and ounces.

•To zero the display, press the [ON/OFF/TARE] key.

•In practice when the scale is turned on, the [ON/OFF/TARE] key is

pressed to zero the display, if necessary.

•After the display is at zero, place the baby to be weighed on the cradle of

the scale.

•The display will show the weight in the chosen unit.

•If necessary the weight of blankets or pillows can be accounted for, by

placing those on the cradle first and pressing the [ON/OFF/TARE] key to

zero the display. Then the baby to be weighed can be placed on the

cradle. The display will show the weight of the baby without the added

weight of the blankets or pillows.

7.0 SELECTION OF UNITS

•Turn the scale on by pressing [ON/OFF/TARE].

•Press the [UNIT] key to toggle between Kilograms and Pounds.

•If the chosen unit of weight is Kilogram, next it displays “

0.00

” with a

triangle at the left top of the display.

•If the display shows “

0: 0

” with a triangle at the left bottom of the display,

the unit is in pounds and ounces.

8.0

HOLD FUNCTION

•Due to the baby’s movement, the weight shown on the display will change

all the time. After the baby is placed on the scale, press [HOLD] to hold

the weight value. The display shows ‘hold’. The scale will calculate the

average of the former weight values taken automatically.

•The display will be locked when the [HOLD] key is pressed. The display

will show a flashing ‘’ ” symbol at the top of the display indicating the

baby’s weight is held.

•The scale will return to normal weighing when the [HOLD] key is pressed

a second time or when the display is zeroed or tared with no weight on the

scale.

9.0 AUTOMATIC POWER SWITCH OFF

•The scale is operated using one PP3 9V alkaline battery in the internal

battery chamber.

•The typical battery life is 12 hours.

•The scale includes the feature to turn the power off after 30 seconds if it is

not being used. This helps to maximise the battery life.

•If the battery is low on charge, “LO”will be displayed. The scale will be

automatically switched off after 5 minutes.

•The battery should be replaced by new ones.

•Do not throw away the discharged battery together with the domestic

rubbish. For disposal, take those to the junk battery collector.

•Contact your supplier for more information.

10.0 CALIBRATION

PROCEDURE

•Place the scale on a flat platform after inserting a PP3, 9V alkaline battery.

•Press the [ON/OFF/TARE] key to turn the power ON.

•Display will show "

0000

” initially, 3 seconds later it will show ”

0.00

”

•Create a short circuit by plugging a screw driver into the test pin hole

which is on the head of the scale base. Display will show the zero count

between 1000 and 2500.

•Press the [ON/OFF/TARE] key. Display will show ”

xxx 0

”.

•Load 20 kg weight onto the scale. Display will show a span count between

1500 to 3500.

•Press the [ON/OFF/TARE] key again. Display will show ‘CAL’. After 3

seconds the display will show ”20.0”.

•Remove the weight and keep the [ON/OFF/TARE] key pressed for 2

seconds.

•The calbration is complete and the scale will be turned off.

11.0 ERROR MESSAGES

Error Messages Possible causes Suggestions

“

If the batteries are low on charge,

“

“ will be displayed. The

scale will be automatically

switched off after 5 minutes.

The batteries should be

replaced by new ones.

“

ERR

”

Displayed when the total weight

exceeds the capacity of the scale. The scale should be

emptied.
