ADF Web HD67595 Bedienungsanleitung
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 1 of 27
User Manual
Revision 1.
English
EtherNet/IP Master / CAN - Converter
(Order Code: HD67645-A1 )
For Website information:
www.adfweb.com?Product=HD67645
For Price information:
www.adfweb.com?Price=HD67645-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -4 °C/+85°C (-4 °F/+185°F)
For other EtherNet/IP Master products see also the following link:
Converter EtherNet/IP Master to
www.adfweb.com?Product=HD67B38 (OPC UA Server)
www.adfweb.com?Product=HD67D24 ( oRaWAN)
www.adfweb.com?Product=HD67E26 (EtherCAT)
www.adfweb.com?Product=HD67158 (SNMP Agent)
www.adfweb.com?Product=HD67643 (PROFIBUS Slave)
www.adfweb.com?Product=HD67645 (CAN)
www.adfweb.com?Product=HD67646 (CANopen)
www.adfweb.com?Product=HD67647 (DeviceNet Slave)
www.adfweb.com?Product=HD67661 (PROFINET)
www.adfweb.com?Product=HD67665 (Modbus TCP Slave)
www.adfweb.com?Product=HD67667 (Serial)
www.adfweb.com?Product=HD67668 (Ethernet)
www.adfweb.com?Product=HD67669 (Modbus Slave)
www.adfweb.com?Product=HD67689 (BACnet Slave)
www.adfweb.com?Product=HD67743 (IEC 61850 Server)
www.adfweb.com?Product=HD678 6 (KNX)
www.adfweb.com?Product=HD67955 (MQTT)
www.adfweb.com?Product=HD67973 (IO- ink Slave)
User Manual
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 2 of 27
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
CAN 1
ETHERNET 11
USE OF COMPOSITOR SW67645 12
NEW CONFIGURATION / OPEN CONFIGURATION 13
SOFTWARE OPTIONS 14
SET COMMUNICATION 16
ETHERNET/IP ACCESS 17
RECEIVE FRAMES 18
SEND FRAMES 2
UPDATE DEVICE 22
MECHANICAL DIMENSIONS 24
ORDERING INFORMATIONS 25
ACCESSORIES 25
DISCLAIMER 26
OTHER REGULATIONS AND STANDARDS 26
WARRANTIES AND TECHNICAL SUPPORT 27
RETURN POLICY 27
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION IST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision
Date Author Chapter
Description
1. 18/ 9/2 2
Ff All First Release
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 3 of 27
SECURITY A ERT:
G
ENERA
I
NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I
NTENDED
U
SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q
UA IFIED
P
ERSONNE
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R
ESIDUA
R
ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE
CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 4 of 27
EXAMP E OF CONNECTION:
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 5 of 27
CONNECTION SCHEME:
Figure 1: Connection scheme for HD67645-A1
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 6 of 27
CHARACTERISTICS:
The HD67645-A1 are EtherNet/IP / CAN - Converters.
It allows for the following characteristics:
Isolation between EtherNet/IP – CAN – Power Supply;
Two-directional information between EtherNet/IP bus and CAN bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CONFIGURATION:
You need Compositor SW67645 software on your PC in order to perform the following:
Define the parameters of EtherNet/IP line;
Define the parameters of CAN line;
Define the list of EtherNet/IP slaves connected to the converter;
Define CAN messages in rx and tx;
Update the device.
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 7 of 27
POWER SUPP Y:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67645-A1 3.5
HD67645-A1
Caution:
Do n
ot reverse the polarity power
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 8 of 27
FUNCTION MODES:
The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 9 of 27
EDS:
The device has got seven LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
ED Normal Mode Boot Mode
1: ON (green) ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: CAN comm. (green) It blinks when a CAN message is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Ethernet comm. (green) It blinks when EtherNet/IP communication is running Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Ethernet1 link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected
6: Ethernet2 link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
Ether
Net/IP Master
/
CAN
Document code: MN67645_ENG Revision 1. Page 1 of 27
CAN:
For terminating the CAN line with a 12 Ω resistor it is necessary that the Dip1 of ‘Dip-Switch C’ is at ON position.
Cable characteristics:
DC parameter: Impedance 7 Ohm/m
AC parameters: Impedance 12 Ohm/m
Delay 5 ns/m
ength Baud Rate [bps] ength MAX [m]
1 K 5
2 K 25
5 K 1
1 K 65
125 K 5
25 K 25
5 K 1
8 K 5
1 K 25
