INSTALLATION AND OPERATING MANUAL
50W Ku-BAND HUB-MOUNT
SOLID STATE POWER AMPLIFIER
AWSA-K50-CHE
PM 100-432350-530, REV. 1
AWSA-K50-CHE
Page 1
WARRANTY
This ADVANTECH Advanced Microwave Technologies, Inc. product is warranted against
defects in material and workmanship for a period of 2 years from date of shipment. During the
warranty period, ADVANTECH Advanced Microwave Technologies, Inc. will, at its option,
either repair or replace products that will prove to be defective.
To return a product for warranty or repair service, you must first request a Return Material
Authorization (RMA) number by contacting ADVANTECH at:
Phone: (514) 420-0045 or Fax: (514) 420-0073
Website: www.AdvantechAMT.com or e-mail: sales@AdvantechAMT.com
The unit should be shipped to the following address, in original shipping container (box), with
shipping charges prepaid.
ADVANTECH Advanced Microwave Technologies, Inc.
657 Orly Avenue
Dorval, Quebec
H9P 1G1
CANADA
Please indicate the RMA number on all shipping documentation.
Units shipped without prior issued RMA, or shipped not in original packing, may be subject of
rejection and returned at sender’s own expense.
LIMITATIONS OF WARRANTY
ADVANTECH Advanced Microwave Technologies, Inc. warrants this product to be free of
materials and workmanship defects.
The foregoing warranty shall not apply to defects resulting from improper handling or abuse by
the Buyer, unauthorized modification, operation outside of the environmental specifications for
the product, or improper installation or maintenance.
ADVANTECH Advanced Microwave Technologies, Inc. shall not be liable for any direct,
indirect, special, incidental or consequential damages.
AWSA-K50-CHE
Page 2
CONTENTS
1. PACKING LIST..................................................................................................................................................5
2. SAFETY ...............................................................................................................................................................6
3. GENERAL INFORMATION.............................................................................................................................8
3.1 ELECTRICAL SPECIFICATIONS.........................................................................................................................9
4. MAJOR SUBSYSTEMS AND THEIR FUNCTIONS ...................................................................................12
4.1 RF SUBSYSTEM............................................................................................................................................12
4.2 POWER SUPPLY SUBSYSTEM.........................................................................................................................15
4.3 ALARM/INDICATE BOARD ............................................................................................................................15
5. UNPACKING AND INSTALLATION............................................................................................................16
5.1 INITIAL INSPECTION......................................................................................................................................16
5.2 UNPACKING..................................................................................................................................................16
5.3 INSTALLATION..............................................................................................................................................16
5.3.1 Mechanical Installation.......................................................................................................................16
5.3.2 Electrical Connections.........................................................................................................................17
5.3.3 RF Connections ...................................................................................................................................18
5.3.4 Cooling Considerations.......................................................................................................................19
6. INTERFACES ...................................................................................................................................................20
6.1 DISCRETE INTERFACE...................................................................................................................................20
6.1.1 Functional Description........................................................................................................................21
6.2 RF OUTPUT MONITOR PORT ........................................................................................................................21
7. INITIAL POWER ON AND CHECKOUT.....................................................................................................22
7.1 PRE-POWER PROCEDURES ............................................................................................................................22
8. OPERATION.....................................................................................................................................................23
8.1 ESSENTIAL OPERATING PROCEDURES ..........................................................................................................23
9. MAINTENANCE...............................................................................................................................................24
9.1 PREVENTIVE MAINTENANCE ........................................................................................................................24
9.1.1 Mechanical Preventive Maintenance...................................................................................................24
9.1.2 Checking the Cooling Fan...................................................................................................................24
10. APPENDIX A: SAFETY AND EMC COMPLIANCE..............................................................................25
AWSA-K50-CHE
Page 3
FIGURES
FIGURE 1: PRODUCT OUTLINE ...................................................................................................... 11
FIGURE 2: BLOCK DIAGRAM......................................................................................................... 13
FIGURE 3: CONNECTORS ............................................................................................................... 14
AWSA-K50-CHE
Page 4
TABLES
TABLE 1: CONNECTORS......................................................................................................... 14
TABLE 2: AC LINE (J5) – PINS ASSIGNMENTS ................................................................... 15
TABLE 3: MECHANICAL SPECIFICATIONS ........................................................................ 17
TABLE 4: POWER REQUIREMENTS...................................................................................... 17
TABLE 5: ENVIRONMENTAL CONDITIONS........................................................................ 19
TABLE 6: DISCRETE INTERFACE (J3) – PINS ASSIGNMENTS......................................... 20
AWSA-K50-CHE
Page 5
1. PACKING LIST
PACKING LIST
Item Quantity Description Part #
1. 1 Installation and Operating Manual PM100-432350-530, Rev. 1
2. 1 50 Watt Ku-Band power amplifier,
model AWSA-K50-CHE 100-432350-530
3. 4 #6 - 32 x 1/2” hex head screw 802-632090-001
4. 4 #6 lock washer 803-600100-001
5. 1 MS3116F16-26S (Conn. for J3) 631-311626-001
6. 1 AC Cable Assembly (10m long, with
MS3106F16-10S connector for J5) 260-330918-001
7. 1 O ring gasket for WR-75G 820-075000-001
8. 1 roll Mastic Tape 709-224200-001
AWSA-K50-CHE
Page 6
2. SAFETY
In addition to this section, included by reference are the following pertinent sections of the
International Standard IEC-215, ‘Safety requirements for radio transmitting equipment’:
- Appendix D, ‘GUIDANCE ON ASSESSING THE COMPETENCE OF PERSONNEL
FOR DESIGNATION AS SKILLED’ and also Sub-clause 3.1 of the Standard.
- Appendix E, ‘GUIDANCE ON SAFETY PRECAUTIONS TO BE OBSERVED BY
PERSONNEL WORKING ON RADIO TRANSMITTING EQUIPMENT’, and also
Sub-clauses 3.2, 3.7 and 22.1 of the Standard.
To prevent the risk of personal injury or loss related to equipment malfunction the following
symbols are used to indicate safety related information. For your own safety, please read the
information carefully BEFORE operating the equipment.
Symbols used in manual:
WARNING: This indicates a hazardous procedure that could result in serious injury or death
if not performed properly.
CAUTION: This indicates a hazardous and dangerous procedure that could result in
light-to-severe injury or loss related to equipment, if proper precautions are not
taken.
AWSA-K50-CHE
Page 7
---------------------------------------------- WARNING -----------------------------------------------------
When supplying power to this equipment, connect the accessory 3-pin power connector (with
extension cable) to a 3-pin grounded power outlet. If power is supplied without grounding the
equipment, there is a risk of receiving a severe or fatal electric shock.
In the context of this document any voltage that is lethal is viewed as ‘High Voltage’. Therefore,
even prime power (90 to 265 VAC) is dangerous because prime power potentials have been
known to cause death or injury.
----------------------------------------------- WARNING ----------------------------------------------------
This equipment can not be repaired by the operator. DO NOT attempt to remove the
equipment cover or to disassemble internal components. Only qualified service technicians
should service this equipment. There are high-voltage parts in this equipment presenting a risk of
severe injury to untrained personnel. In addition, there is a risk of damage to precision
components.
----------------------------------------------- WARNING ----------------------------------------------------
ALWAYS TERMINATE THE OUTPUT WAVEGUIDE OF THE POWER AMPLIFIER
WITH AN RF LOAD CAPABLE OF DISSIPATING FULL CW RF POWER. Incorporate
the termination prior to applying prime power to the power amplifier. This procedure prevents
self oscillation and irradiation of the local environment. Even if a source is not connected to the
power amplifier you are working with, there are situations where the power amplifier can go into
a self induced mode and generate high levels of RF energy. Destruction caused under excessive
load voltage standing wave ratio (VSWR) will void the warranty. Although the equipment has
internal protection for VSWR higher than 3:1 and will automatically go in shutdown (with a
delay of 1 second), still it is a safe procedure to avoid unwanted effects.
----------------------------------------------- WARNING ----------------------------------------------------
DO NOT LOOK INTO THE RF OUTPUT PORT OF THE POWERED POWER
AMPLIFIER. Treat the powered amplifier with extreme care. Your eyes are particularly
vulnerable parts of your body.
AWSA-K50-CHE
Page 8
3. GENERALINFORMATION
This manual contains information that describes installation, operation and maintenance
procedures for the 50W Ku-band hub-mount (Outdoor) Solid State Power Amplifier Model #
AWSA-K50-CHE. Because specialized training is required for some phases of installation and
operation, certain parts of this manual are directed only to trained personnel. Warnings appear at
the appropriate points to caution all users of potential RF and high-voltage hazards.
For a safe and versatile operation, please read the information carefully BEFORE using the
equipment.
ADVANTECH Advanced Microwave Technologies, Inc. has prepared this manual for use as a
guide for the proper installation, operation and maintenance of ADVANTECH equipment and
computer programs. The drawings, specifications and information contained herein are property
of ADVANTECH Advanced Microwave Technologies, Inc. Any unauthorized use or disclosure of
these drawings, specifications and information is prohibited; they shall not be reproduced,
copied or used in whole or in part as the basis for manufacturing or sale of the equipment or
software programs without the prior written consent of ADVANTECH Advanced Microwave
Technologies, Inc.
AWSA-K50-CHE
Page 9
3.1 ELECTRICAL SPECIFICATIONS
The SSPA specified herein is capable of meeting or exceeding the performance specifications
listed in the following table over frequency range, operating temperature and line voltage variation
unless otherwise specified. The SSPA will meet all RF performance specifications within thirty
minutes of application of prime power.
ELECTRICAL SPECIFICATIONS
Frequency Range 14.000 - 14.500 GHz
3 dB Bandwidth > 575 MHz, min
Linear Amplitude Response (at 10 dB back-off from 1 dB CP),
over the operating temperature range 2 dB, max over 500 MHz
0.6 dB, max over 40 MHz
Power Amplitude Response at 1 dB CP < 2.0 dB p-p/500 MHz, max
Gain Stability with temperature ( –30 °C to + 55 °C) 3 dB p-p, max
Small signal gain 70-75 dB
Gain Out of Band 10.950 to 12.750 GHz and at 16.0 GHz < -40 dB
1 dB Compression Point (P1dB CP) 46 dBm, min
Third order Intermodulation (IMD).
Two equal carriers at 5 MHz apart (SCL at 6 dB back off from
rated power) over ambient temperature range.
-23 dBc, typ; -20 dBc, max
(at 3 dB back off total power)
Intercept Point 3rd Order (IP3)
IP3 = Pscl + (IMD3/2), measured at 10 dB back off, over the
operating temperature range
P1dB CP + 8 dB, min
AM/PM Conversion at 1dB CP
. at 6 dB below 1dB CP < 3.0 °/dB, max
< 1.0 °/dB, max
Noise Figure < 32 dB, nominal
Group Delay (over any 40 MHz) Linear
. Parabolic
. Ripple
0.05 nsec/MHz, max
0.003 nsec/ MHz2 , max
2.0 nsec. p–p, max.
Impedance Input/Output 50 Ωnominal
