Advantech CPC-2520 Bedienungsanleitung

CPC-2520

VGA/LCD module for Mini Biscuit PC

User’s Manual

This document is copyrighted, October 1999. All rights are

reserved. The original manufacturer reserves the right to make

improvements to the products described in this manual at any time

without notice.

No part of this manual may be reproduced, copied, translated or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in

this manual is intended to be accurate and reliable. However, the

original manufacturer assumes no responsibility for its use, nor for

any infringements upon the rights of third parties which may result

from its use.

Acknowledgements

AMI is a trademark of American Megatrends, Inc.

Cyrix is a trademark of Cyrix Corporation.

IBM, PC/AT, PS/2 and VGA are trademarks of International

Business Machines Corporation.

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of

Microsoft Corp.

C&T is a trademark of Chips and Technologies, Inc.

All other product names or trademarks are properties of their

respective owners.

Part No. 2006252000

1st Edition Printed in Taiwan October 1999

Product warranty

Advantech warrants to you, the original purchaser, that each of its

products will be free from defects in materials and workmanship

for one year from the date of purchase.

This warranty does not apply to any products that have been

repaired or altered by persons other than repair personnel autho-

rized by Advantech, or which have been subject to misuse, abuse,

accident or improper installation. Advantech assumes no liability

under the terms of this warranty as a consequence of such events.

Because of Advantech high quality-control standards and rigorous

testing, most of our customers never need to use our repair service.

If an Advantech product is defective, it will be repaired or re-

placed at no charge during the warranty period. For out-of-

warranty repairs, you will be billed according to the cost of

replacement materials, service time and freight. Please consult

your dealer for more details. If you think you have a defective

product, follow these steps:

1. Collect all the information about the problem encountered.

(For example, CPU speed, Advantech products used, other

hardware and software used, etc.) Note anything abnormal and

list any on- screen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your

manual, product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA

(return merchandize authorization) number from your dealer.

This allows us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair

and Replacement Order Card and a photocopy proof of

purchase date (such as your sales receipt) in a shippable

container. A product returned without proof of the purchase

date is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package

and ship it prepaid to your dealer.

Packing list

Before installing your board, make sure that the following materi-

als have been received:

• 1 CPC-2520 VGA/LCD module for mini biscuit PC

• 2 floppy disks (or one CD-ROM) including SVGA utility

programs and drivers for Windows 95/98/NT

• 1 warranty certificate

• This user's manual

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

Technical support and sales assistance

If you have any technical questions about the CPC-2520 or any

other Advantech products, please visit our support website at:

http://support.advantech.com.tw

For more information about Advantech's products and sales

information, please visit:

http://www.advantech.com

Contents

Chapter 1 General Information.................................1

1.1 Introduction.................................................................. 2

1.2 Specifications ................................................................ 3

General ........................................................................... 3

Mechanical and environmental ...................................... 3

1.3 Board layout: dimensions............................................ 4

Chapter 2 Installation................................................5

2.1 Jumpers and connectors.............................................. 6

2.2 Board layout: jumper/connector locations ................ 7

2.3 Safety precautions ........................................................ 8

2.4 Jumper settings ............................................................ 9

2.5 LCD Panel select (SW1) ............................................ 10

2.6 Display connectors (CN2, CN3) ................................ 10

2.7 LCD display connector (CN2)................................... 11

2.8 VGA display connector (CN3) .................................. 12

2.9 FPC cable installation................................................ 14

Chapter 3 Software Configuration .........................15

3.1 Introduction................................................................ 16

3.2 Connections for five standard LCDs........................ 16

Connections to Sharp LM64183P, LM64P89

(640 x 480 DSTN MONO LCD) ............................... 16

Connections to Toshiba LTM10C042

(640 x 480 TFT color LCD)....................................... 18

Connections to Sharp LM64C142

(640 x 480 DSTN color LCD) ................................... 19

Connections to Toshiba LTM12C275A

(800 x 600 TFT color LCD)....................................... 20

Chapter 4 PCI SVGA Setup.....................................21

4.1 Introduction................................................................ 22

4.1.1 Chipset ................................................................ 22

4.1.2 Display memory.................................................. 22

4.1.3 Display types....................................................... 22

4.2 Installation of SVGA driver...................................... 23

4.2.1 Installation for Windows 3.1 .............................. 24

4.2.2 Installation for Windows 95 ............................... 26

4.2.3 Installation for Windows NT .............................. 29

4.3 Further information................................................... 32

Chapter 5 Board Diagrams .....................................33

5.1 PCB layout: SODIMM/screw hole locations ........... 34

5.2 Board layout: connectors (top view) ........................ 35

5.3 FPC/FFC layout: CN2: 50-pin FPC connector ....... 36

5.4 FPC/FFC cable layout:

CN3: 12-pin FPC connector ...................................... 36

5.5 Height limitations: side view..................................... 37

5.6 Component suppliers ................................................. 37

Tables

Table 2-1: Jumpers and connectors .......................................................... 6

Table 2-2: LCD display connector (CN2)................................................. 11

Table 2-3: VGA display connector (CN3) ................................................ 12

Table 2-4: VGA display connector (CN3) ................................................ 13

Table 3-1: Connections to Sharp LM64183P, LM64P89 ......................... 16

Table 3-2: Connections to PLANAR EL................................................... 17

Table 3-3: Connections to Toshiba LTM10C042..................................... 18

Table 3-4: Connections to Sharp LM64C142 .......................................... 19

Table 3-5: Connections to Toshiba LTM12C275A .................................. 20

Table 5-1: Component suppliers.............................................................. 37

CHAPTER

General Information

This chapter provides background

information for the CPC-2520. Sections

include:

•Card specifications

•Board layout

2CPC-2520 User's Manual

1.1 Introduction

The CPC-2520 is an extension VGA/LCD module for the

CPC-2245 mini biscuit PC. The CPC-2520 uses a C&T 69000

chipset for its PCI/SVGA controller. It supports many popular

LCD, EL, and gas plasma flat panel displays and conventional

analog CRT monitors. The 69000 VGA BIOS supports mono-

chrome LCD, EL, color TFT and STN LCD flat panel displays. In

addition, it also supports interlaced and non-interlaced analog

monitors (color and mono-chrome VGA) in high-resolution modes

while maintaining complete IBM VGA compatibility. Digital

monitors (i.e. MDA, CGA, and EGA) are NOT supported.

Multiple frequency (multi-sync) monitors are handled as if they

were analog monitors.

With on-board 2 MB display memory, the VGA controller can

drive CRT displays or color panel displays with resolutions up to

1024 x 768 at 64 K colors.

CRT and panel displays can be used simultaneously. The

CPC-2520 can be set in one of three configurations: on a CRT, on

a flat panel display, or on both simultaneously. The system is

initially set to simultaneous display mode.

Chapter 1 General Information 3

1.2 Specifications

General

•Flat panel VGA interface

•Chipset: C&T 69000 VGA controller with Windows accelerator

•Display memory: 2 MB SDRAM in built-in chip

•Display output:

50-pin FPC connector for flat panel interface

12-pin FPC connector for VGA interface

•Display type: Supports CRT and flat panel (TFT, DSTN, and

mono) displays. Can display both CRT and flat panel simulta-

neously

•Resolution: 640 x 480 @ 16 M colors

800 x 600 @ 16 M colors

1024 x 768 @ 64 K colors

Mechanical and environmental

•Power supply voltage: +5 V (4.75 V ~ 5.25 V)

•Max. power requirements: +5 V @ 0.8 A

•Operating temperature: 0 ~ 60°C (32 ~ 140°F)

•Board size: 68 x 100 mm (2.7" x 3.9")

•Weight: 0.05 kg (0.11 lb)
