Advantech TPC-651T-E Series Bedienungsanleitung

User Manual

TPC-651T-Exxx

TPC-651H-Exxx

Industrial Touch Panel Computers with

Intel®Atom™ Processors

TPC-651T/TPC-651H User Manual ii

The documentation and the software included with this product are copyrighted 2014

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. How-

ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties, which may result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

This Manual Covers the Following Models:

TPC-651T (5.7" & 6.5")

TPC-651H (5.7")

Part No. xxxxxxxxxxxxx Edition 1

Printed in Taiwan February 2015

iii TPC-651T/TPC-651H User Manual

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for two years from the date of pur-

chase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is defec-

tive, it will be repaired or replaced at no charge during the warranty period. For out-

of-warranty repairs, you will be billed according to the cost of replacement materials,

service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages you get when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

TPC-651T/TPC-651H User Manual iv

Declaration of Conformity

This product has passed the CE test for environmental specifications when shielded

cables are used for external wiring. We recommend the use of shielded cables. This

kind of cable is available from Advantech. Please contact your local supplier for

ordering information.

FCC Class A

Note: This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful interference in

which case the user will be required to correct the interference at his own expense.

Technical Support and Assistance

1. Visit the Advantech web site at http://support.advantech.com where you can find

the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–A complete description of the problem

–The exact wording of any error messages

v TPC-651T/TPC-651H User Manual

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equip-

ment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting

it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

The power cord or plug is damaged.

Liquid has penetrated into the equipment.

The equipment has been exposed to moisture.

The equipment does not work well, or you cannot get it to work according to

the user's manual.

The equipment has been dropped and damaged.

The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE

STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C

(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT

SHOULD BE IN A CONTROLLED ENVIRONMENT.

16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES

ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

The sound pressure level at the operator's position according to IEC 704-1:1982 is

no more than 70 dB (A).

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

TPC-651T/TPC-651H User Manual vi

Caution! Danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer. Dis-

pose of used batteries according to the manufacturer's instructions.

Attention! Danger d'explosion si la pile est remplacée de façon incor-

recte. Remplacez seulement avec le même type ou équivalent recom-

mandé par le fabricant. disposer des piles usagées selon les

instructions du fabricant.

vii TPC-651T/TPC-651H User Manual

Chapter 1 General Information ............................1

1.1 Introduction ............................................................................................... 2

1.2 Specifications ............................................................................................ 2

1.2.1 System Kernel............................................................................... 2

1.2.2 I/O Ports........................................................................................ 2

1.2.3 O/S support................................................................................... 2

1.2.4 Safety and Environment................................................................ 3

1.3 LCD Specifications.................................................................................... 3

1.4 Touchscreen Specifications ...................................................................... 4

1.5 Power ........................................................................................................ 4

1.6 I/O Ports Arrangement .............................................................................. 4

Figure 1.1 I/O Port Arrangement ................................................. 4

1.7 Panel Mounting ......................................................................................... 5

1.8 Dimensions and Cutout............................................................................. 5

Figure 1.2 TPC-651T Dimensions .............................................. 6

Figure 1.3 TPC-651H Dimensions............................................... 7

Chapter 2 System Setup.......................................9

2.1 System Setup.......................................................................................... 10

Figure 2.1 Unpack the Package ................................................ 10

Figure 2.2 Install CFast Memory Card

(Mylar in accessory box can be attached to CFast card

for easy extraction) ................................................... 11

Figure 2.3 Power Connector and Power Lines .......................... 11

Figure 2.4 Power Receptor & Button Pin Assignment ............... 12

2.1.1 Installing the Drivers ................................................................... 12

2.2 Transport and Unpacking........................................................................ 13

2.3 Panel Mounting ....................................................................................... 13

2.4 Cabinet Installation and Earth Grounding setup ..................................... 15

2.5 Power/Digital Ground and Earth Ground ................................................ 17

Appendix A Serial Port Settings ...........................19

A.1 Jumper, Dip switch and Connector location............................................ 20

A.1.1 Top.............................................................................................. 20

A.1.2 Bottom......................................................................................... 20

A.2 Switch Setting ......................................................................................... 21

A.2.1 Termination Resistor Select (SW3)............................................. 22

A.3 Connector Pin Definition ......................................................................... 22

A.3.1 SATA connector (CN12) ............................................................. 22

A.3.2 SATA Power connector (CN13) .................................................. 22

A.3.3 Mini PCIE slot (MINIPCIE) .......................................................... 23

A.3.4 CFast slot (CN14) ....................................................................... 24

A.3.5 Power in connector (CN18)......................................................... 24

A.3.6 LAN RJ45 connector (CN7,CN8) ................................................ 25

A.3.7 USB connector (CN10) ............................................................... 26

A.3.8 COM1 RS232 connector (CN15) ................................................ 26

A.3.9 COM2 RS232/422/485 connector (CN16) .................................. 27

Appendix B Driver Installation and Configuration ..

B.1 EC Driver Installation .............................................................................. 30

B.2 EC Brightness Control Tool Installation .................................................. 32

TPC-651T/TPC-651H User Manual viii

B.3 EC Watchdog Timer Driver Installation................................................... 34

B.4 Intel Graphics Driver Installation ............................................................. 38

B.5 Intel Chipset Software Installation Utility Installation............................... 41

B.6 Intel® Trusted Execution Engine Driver Installation................................ 43

B.7 LAN Driver Installation ............................................................................ 46

B.8 Windows 7 USB 3.0 Driver Installation ................................................... 49

B.9 Touchscreen Driver Installation .............................................................. 51

B.10 Touchscreen Calibration ......................................................................... 54

B.11 LMsensor Driver Installation ................................................................... 56

Appendix C Windows 8.X BIOS Setup ................. 57

C.1 Windows 8.X BIOS Setup ....................................................................... 58

Chapter 1

1General Information

TPC-651T/TPC-651H User Manual 2

1.1 Introduction

The TPC-651T/TPC-651H Touch Panel Computer is a state-of-the-art Human

Machine Interface featuring a 5.7”/6.5” display and Intel Atom™ E3827 1.75 GHz

Processor

The key features are as follows:

True-flat touch screen

TPC-651T is a true-flat touch screen designed with IP66 front protection. (TPC-

651H is with traditional TPC bezel for IP65 front protection)

Fanless

By using a low-power processor, the system does not have to rely on fans,

which often are unreliable and causes dust to circulate inside the equipment.

Wide operating temperature

TPC-651T supports -20 ~ 60°C wide operating temperature solution to provide

flexibility in harsh environments.

Bright Display

The TFT LED LCD display suits industrial demands for clear interfaces. Wide

Operating Temperature & Isolation Protection.

1.2 Specifications

1.2.1 System Kernel

CPU: Intel® Atom™ E3827 1.75 GHz Processor

BIOS: AMI UEFI BIOS

VGA: Integrated in Intel® Atom™ E3827

Ethernet: 10/100/1000Base-T x 2

Watchdog Timer: EC watchdog timer; 1.0 second timeout period

Storage:

CFast slot x 1

2.5" SATA HDD/SSD slot x 1 (optional, accessory TPC-1251T-EHKE required)

1.2.2 I/O Ports

RS-232 x 1, RS-232/422/485 x 1

USB 3.0 x 1

USB 2.0 x 1

Full-size Mini PCIe Card x1

1.2.3 O/S support

Microsoft® Windows

–WES7 64bit

–WE8S 64bit

–Windows 7 32bit/64bit

–Windows 8 64bit

(see Appendix B, Chapter C for BIOS set up before installing Windows 8.X)

Linux Kernel

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Advantech Bedienfeld Handbücher

Advantech

Advantech FPM-3220 Bedienungsanleitung

Advantech

Advantech FPM-3220 Bedienungsanleitung

Advantech

Advantech UbiQ Bedienungsanleitung

Beliebte Bedienfeld Handbücher anderer Marken

RDZ

RDZ PC-HRX Bedienungsanleitung

STG-BEIKIRCH

STG-BEIKIRCH MZ3 Technisches Handbuch

Efka

Efka Variocontrol V810 Bedienungsanleitung

Cebora

Cebora 208-10 Bedienungsanleitung

AMX

AMX AutoPatch CP-15 Bedienungsanleitung

Satel

Satel CA-6 KLED-S Bedienungsanleitung

Evolution

Evolution IQ plus 800 Bedienungsanleitung

Fagor

Fagor 8040 TCO CNC Bedienungsanleitung

Trane

Trane ComfortLink II XL950 Control Bedienungsanleitung

AKO

AKO PROCool AKO-17635-2 Bedienungsanleitung

ABB

ABB 6136/30M-101 Bedienungsanleitung

Telikou

Telikou BK-603 Belt Pack Bedienungsanleitung

Mapei

Mapei Mapeheat Thermo Touch Bedienungsanleitung

Bosch

Bosch D9412GV4 Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries SC-SL4-AE2/1 Bedienungsanleitung

Sminn

Sminn BOX L VF1L EI Bedienungsanleitung

Balboa

Balboa TP600 Bedienungsanleitung

Nice

Nice HSCU1 Technische Daten
