Advantech PCL-812PG Bedienungsanleitung

PCL-812PG

Enhanced Multi-Lab Card

User's Manual for PCL-812PG

This documentation and the software routines contained in the

PCL-812PG software diskette are copyrighted, 1993, by Advan-

tech Co. Ltd. All rights are reserved. Advantec reserves the right

to make improvements to the products described in this manual at

any time without notice.

No part of this manual may be reproduced, copied, translated or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in

this manual is intended to be accurate and reliable. However, the

original manufacturer assumes no responsibility for its use, nor

for any infringements upon the rights of third parties which may

result from its use.

Acknowledgements

PC-LabCard is a trademark of Advantech Co., Ltd.

IBM and PC are trademarks of International Business Machines

Corporation.

MS-DOS is a trade mark of Microsoft Corporation.

BASIC is a trademark of Dartmouth College. Intel is a trademark

of Intel Corporation.

Part No. XXX Rev. B1

Printed in Taiwan November 1996

Packing List

Before installing your board, insure that the following materials

have been received:

•

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

Chapter 1 General Information

General Information

This chapter gives background

information on the PCL-812PG.

Sections include:

• Key Features

• Expansion Capabilities

• Product Specifications

CHAPTER

1010

10 PCL-812PG User's Manual

1.1 Introduction

The PCL-812PG is a high performance, high speed, multi-function

data acquisition card for IBM PC/XT/AT and compatible

computers. The high-end specifications fo this full-sized card, and

complete software support from third-party vendors makes it ideal

for a wide range of applications in industrial and laboratory

environments. These applications include data acquisition, process

control, automatic testing and factory automation.

1.2 Key Features

• 16 single-ended analog input channels

• An industrial standard 12-bit successive approximation converter

(HADC574Z) to convert analog inputs. The maximum A/D

sampling rate is 30 KHz in DMA mode.

• Software programmable analog input ranges.

• Bipolar: +/- 5V, +/- 2.5 V, +/- 1.25V +/- 0.625 V +/- 0.3125 V

• Three A/D trigger modes:

• Software trigger

• Programmable pacer trigger

• External pulse trigger

• The ability to transfer A/D converted data by program control,

interrupt handler routine or DMA transfer.

• An Intel 8253-5 Programmable Timer/Counter provides pacer

output (trigger pulse) at the rate of 0.5 MHz to 35 minutes/pulse.

The timer increment is 2 MHz. One 16-bit counter channel is

reserved for user configuration applications.

• Two 12-bit monolithic multiplying D/A output channels. An

output range from 0 to +5V or 0 to +10V can be created by using

the on-board -5V or -10V reference. This precision reference is

derived from the A/D converter reference. External AC or DC

references can also be used to generate other D/A output ranges.

Chapter 1 General Information

1111

• 16 TTL/DTL compatible digital inputs, and 16 digital output

channels.

1.3 Expansion Capabilities

To complement the powerful features of the PCL-812PG, the

versatility of the card can be enhanced by using the following

optional daughter boards:

PCLD-789 Amplifier/Multiplier Board

This powerful front end analog input signal conditioning card can

multiplex 16 differential inputs to one A/D input channel. A high

grade instrumentation amplifier provides switch selectible gains of

0.5, 1, 2, 10, 50, 100, 200, 1000 or any user-definable gain.

PCLD-787 Eight Channel Simultaneous Sample and Hold

Front-End Board

The board allows up to eight analog inputs to be acquired

simultaneously with less than 30 ns of channel-to-channel sample

time uncertainty.

PCLD-786 AC/DC Power SSR and Relay Driver Board

This board provides 8 channels of photo-couple isolated solid-state

relay modules, plus an additonal 8 external relay driver outputs.

PCLD-785/885 Relay Output Board

This board provides 16 SPDT relays driven by the 16-bit digital

output channels of the PCL-812PG.

PCLD-782 Isolated D/I Board

This 16-channel opto-isolated digital input board provides an easy

way to input digital signals to the PCL-812PG.

PCLD-780 Wiring Terminal

Wiring terminal board for easy analog and/or digital I/O

connections

PCLD-779 Eight Channel Isolated Multiplexer and

Amplifier Board

Offers multi-channel temperature measurements when connected

1212

12 PCL-812PG User's Manual

with a PC-LabCard.

PCLD-770/7701/7702 Signal Conditioning Modules

PCLD-770 Signal Conditioning Module Carrier Board.

With the PCLD-770 board, you can configure your requirements

with a signal conditioning module such as the PCLD-7701 or

PCLD-7702.

PCLD-7701 Isolated Amplifier

PCLD-7702 Amplifier with I/V Source

PCLD-5B16 Module Carrier Board

This module carrier board is equipped with 16 channels of 5B

series input and/or output modules which provide a complete

solution for signal conditioning applications.

1.4 Software Support

The PCL-812PG also provides powerful and easy to use software

driver functions which can be accessed by referring a user-defined

parameter table. These driver functions simplify programming,

especially when you want to use some of the sophisticated features

available with the PCL-812PG, for example, interrupt or DMA

data transfer.

To provide PCL-812PG users with more application support, a

variety of excellent third-party application software packages have

been integrated with the PCL-812PG. At present, the PCL-812PG

is supported by the following software:

PC-LabsDAS

Turnkey, menu-driven, general purpose data acquisition package

from Advantech

Labtech Notebook, PC-Scope, PC-Streamer, SNAPSHOT,

etc.

A complete software product catalog is available free from your

local PC-LabCard representative.

1.5 Product Specifications

Chapter 1 General Information

1313

1.5.1 Analog Input (A/D Converter)

Channels: 16 single-ended

Resolution: 12 bits

Input Range: Bipolar +/- 10V, +/- 5V, +/- 2.5 V, +/- 1.25 V,

+/- 0.625 V, +/- 0.3125 V. All input ranges are

software programmable.

Overvoltage: Continuous +/- 30V max.

Conversion type: Successive approximation

Converter: HADC574Z (built-in sample and hold)

Conversion speed: 30 KHz max.

Accuracy: 0.015 % of reading +/- 1 bit

Linearity: +/- 1 bit

Trigger mode: Software trigger, on-board programmable timer

or external trigger.

Data transfer: Program control, Interrupt control or DMA

External trigger TTL or compatible, load 0.4 mA max. at 0.5V

(low) or 0.05 mA max. at 2.7V (high).

1.5.2 Analog Output (D/A Converter)

Channels: 2

Resolution: 12 bits

Output range: 0 to + 5V or 0 to +10V with fixed -5V or -10V

reference. Max. +10V or -10V with external

DC or AC reference.

Reference voltage

Internal: -5V (+/- 0.1V), -10V (+/- 0.2 V)

External: DC or AC, +/- 10 V max

Conversion type: 12-bit monolithic multiplying

Analog devices: AD7541AKN or equivalent

Linearity: +/- 0.5 bit

Output drive: +/- 5 mA max

Settling time: 30 microseconds

1.5.3 Digital Input

1414

14 PCL-812PG User's Manual

Channel: 16 bits

Level: TTL compatible

Input voltage

Low: 0.8 V max

High: 2.0V min.

Input load

Low: 0.4 mA max. at 0.5 V

High: 0.05 mA max. at 2.7 V

1.5.4 Digital Output

Channel: 16 bits

Level: TTL compatible

Output voltage

Low: Sink 8 mA at 0.5 V max.

High: Source -0.4 mA at 2.4V min.

1.5.5 Programmable Timer/Counter

Device: Intel 8253

Counters: 3 channels, 16-bit, 2 channels permanently

connected to 2 MHz clock as programmable

pacer, 1 channel free for user application

Input, gate: TTL/DTL/CMOS compatible

Time base: 2 MHz

Pacer output: 35 minutes/pulse to 0.5 MHz

1.5.6 Interrupt Channel

Level: IRQ 2 to 7, 10, 11, 12, 14, 15 jumper

selectable

Enable: VIA S0, S1 and S2 of CONTROL register

1.5.7 DMA Channel

Level: 1 or 3, jumper selectable

Enable: Via S0, S1 and S2 of CONTROL register

1.5.8 General Specifications

Chapter 1 General Information

1515

Power consumption: +5V: typ. 500 mA, max 1A

+12 V: typ. 50 mA, max 100 mA

-12V: typ. 14 mA, max 20 mA

I/O connector: 20 pin post header for I/O connection. Adapter

available to convert to 37 pin D-type connector

I/O base address: Requires 16 consecutive address locations.

Base address definable by the Dip switches for

address line A8 - A4. (Factory setting is Hex

220).

Operating temperature: 0 to + 50 deg C

Storage temperature: -20 to +65 deg C

Weight: 8.6 oz (243 g)
