Aewin Technologies SCB-6980 Bedienungsanleitung
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
1
Networking Appliance
Desktop Intel® Cedarview D2550/N2600 Network System, 6
Copper GbE, CF, SATA, PCI-E, Bypass
User’s Manual
Version 1.0a
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
2
© Copyright 2013. All Rights Reserved
Manual Edition 1.0a, Jul, 2013
This document contains proprietary information protected by copyright. All rights are reserved; no
part of this manual may be reproduced, copied, translated or transmitted in any form or by any means
without prior written permission of the manufacturer.
The content of this document is intended to be accurate and reliable; the original manufacturer assumes
no responsibility for any inaccuracies that may be contained in this manual. The original
manufacturer reserves the right to make improvements to the products described in this manual at any
time without prior notice.
Trademarks
IBM, EGA, VGA, XT/AT, OS/2 and PS/2 are registered trademarks of International business Machine
Corporation
Award is a trademark ofAward Software International, Inc
Intel is a trademark of Intel
RTL is a trademark of Realtek
VIA is a trademark of VIATechnologies, Inc
Microsoft, Windows, Windows NT and MS-DOS are either trademarks or registered trademarks of
Microsoft Corporation
All other product names mentioned herein are used for identification purpose only and may be
trademarks and/or registered trademarks of their respective companies
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this document, the manufacturer
and distributor assume no liability resulting from errors or omissions in this document, or from the use
of the information contained herein.
For more information on SCB-6980 or otherAEWIN products, please visit our website
http://www.aewin.com.tw.
For technical supports or free catalog, please send your inquiry to
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
3
Table of Contents
Chapter 1. General Information ..........................................................................4
1.1 Introducing.........................................................................................................4
1.3 Order Information..............................................................................................6
1.4 Packaging...........................................................................................................6
1.5 Precautions.........................................................................................................7
1.6 System Layout ...................................................................................................8
1.7 Board Dimension...............................................................................................9
Chapter 2. Connector/Jumper Configuration..................................................10
2.1 Connector/Jumper Location and Definition.....................................................10
2.2 Connector and Jumper Setting.........................................................................12
2.3 CompactFlashTM Card Socket Pin Define........................................................22
Chapter 3. Utility & Driver Installation..............................................................23
3.1 Operation System Supporting..........................................................................23
3.2 System Driver Installation ...............................................................................24
3.3 LAN Driver Installation...................................................................................24
Appendix C: System Resources.............................................................................25
Appendix D: Cable Development Kit....................................................................28
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
4
Chapter 1. General Information
1.1 Introducing
The SCB-6980 is a desktop hardware platform designed for network service
applications. Built with Intel® Embedded IA components with warranty of
longevity, the SCB-6980 supports Intel® Atom™ D2550, N2600 low-voltage
processor with Intel® ICH10R I/O controller.
The platform supports high bandwidth DDR3 SODIMM slot with memory up to
4GB. In order to provide the best network performance and best utilization, the
powerful storage interfaces include one 2.5” SATA HDD and
CompactFlash™.SCB-6980 affords sixcopper GbE with bypass function on
front-panel. The front panel also has two USB 2.0 port, one RJ-45 console port
and LED indicators that monitor power and storage device activities for local
system management, maintenance and diagnostics. In addition, the SCB-6980
supports one mini-card socket and is RoHS, FCC and CE compliant.
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
5
1.2 Specification
Processor System CPU Intel® Cedarview-D D2550, N2600 Processors
Chipset Intel® ICH10R
BIOS AMIBIOS
Memory Technology Un-buffered and Non-ECC DDR3 800/1066MHz
memory
Capacity Up to 4GB with one SO-DIMM socket
Expansion Expansion Slots One mini-card slot (Support USB bus only via
mini-PCIe slot) (Option)
Ethernet GbE Ethernet Six RJ45 GbE ports, Intel® 82583V, PCI-E x1 (one
pair bypass between LAN1 and LAN2)
LAN bypass One ports bypass (Optional)
Storage SATA HDD One internal 2.5” SATA HDD bay
Compact Flash
Socket
One CompactFlashTM Type II
I/O USB Two external USB2.0
Serial One RJ45 Console port (COM1)
One internal 5x2 pin header (COM2)
Power Supply Watt 60W power supply, AC to DC 12V
Mechanical and
Environment
Form Factor Desktop
LED 1 x Power LED (Green)
1 x HDD LED (Red)
1 x Bypass LED (Yellow)
6 pairs LEDs for 6 Ethernet ports Active/Link
status (Green)
Dimension（W x D
x H）
232mm (W) x 153mm (D) x 44mm (H)
(9.1W x 6” D x 1.7” H)
Operating
Temperature
Operating: 0 ~ 40°C ( 32 ~ 104°F )
Storage
Temperature
-20 ~ 75°C (-4 ~ 167°F)
Humidity 10 ~ 85% relative humidity, non-operating,
non-condensing
Weight 1pc/Box, 4kgs, 14cm(W) x 38cm(D) x 23.2cm(H)
5Boxes/CTN, 20kgs, 40cm(W) x 72.4cm(D) x 26.4cm(H)
Certification CE/FCC
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
6
1.3 Order Information
We offer some accessories for SCB-6980 appliance for customer need.
SCB-6980A-D18 Desktop Intel® ATOM D2550 Network System, DDR3, 6 RJ45 GbE,
SATA, CF, Bypass
SCB-6980B-D18 Desktop Intel® ATOM D2550 Network System, DDR3, 4 RJ45 GbE,
SATA, CF, PCI-E
DK001 Cable development kit
46L-CO5204-00 Cross over cable
46L-EC5200-00 Ethernet cable
46L-RJDB91-00 RJ45 Console cable
46L-DB9200-01 Null modem cable
46L-IVGA01-00 VGA cable
46L-IPS200-00 KB/MS cable
46L-IUSB01-00 USB cable
1.4 Packaging
Please make sure that the following items have been included in the package
before installation.
1. SCB-6980 Appliance
2. Quick Installation Guide (Optional)
3. Cables (Optional)
4. CD-ROM that contains the following folders:
(1) Manual
(2) System Driver
(3) Ethernet Driver
(4) Utility Tools
If any item of above is missing or damaged, please contact your dealer or
retailer from whom you purchased the SCB-6980. Keep the box and carton
when you probably ship or store SCB-6980 in near future. After you unpack the
goods, inspect and make sure the packaging is intact. Do not plug the power
adapter to the appliance of SCB-6980 if you already find it appears damaged.
Note: Keep the SCB-6980 in the original packaging until you start installation.
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
7
1.5 Precautions
Please make sure you properly ground yourself before handling the SCB-6980
appliance or other system components. Electrostatic discharge can be easily
damage the SCB-6980 appliance.
Do not remove the anti-static packing until you are ready to install the
SCB-6980 appliance.
Ground yourself before removing any system component from it protective
anti-static packaging. To ground yourself, grasp the expansion slot covers or
other unpainted parts of the computer chassis.
Handle the SCB-6980 appliance by its edges and avoid touching the
components on it.
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
8
1.6 System Layout
SCB-6980 Front Side
SCB-6980 Rear Side
DDR3
SO-DIMM
CF card
2.5” SATA HDD Bay
CPU
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
9
1.7 Board Dimension
User’s Manual
AEWIN Technologies Co., Ltd Jan., 2013
10
Chapter 2. Connector/Jumper Configuration
2.1 Connector/Jumper Location and Definition
