AG Neovo X-19 Bedienungsanleitung

www.agneovo.com

X-19

A versatile display that combines

hard glass protection and multiple

video inputs with a distinctive metal

design for modern professional

environments.

Much more than a desktop monitor, the X-19 is a high-resolution

19” display with NeoV™ Optical Glass that protects the display

from scratches, accidents, and incidental damage. A removable

base and VESA compatible wall mounts allow the X-19 to be

displayed virtually anywhere. With strong metal casing design and

the exibility of analogue, DVI, S-Video and CVBS video inputs,

the X-19 provides the versatility that is essential in multi-user

environments.

> NeoV™ Optical Glass

> Durable metal casing

> Swi 3 ms response time

> Crisp 3000:1 dynamic contrast ratio

> DVI video inputs for high quality signal

> S-Video and CVBS inputs

> Hot key for preferred video mode: User, Text, Movie, Game, and Graphic

> Auto-adjustment for optimal settings

> Kensington® security socket

> VESA standard wall mount

> Available colours: black, white

NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

REACH

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: X19QV_X19Q1 Version 25.2, 20130101

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

TFT LCD

19.0” (483 mm)

SXGA 1280 x 1024

0.294 mm

250 cd/m2(Typical)

3000:1 (DCR)

170°/160° (Typical)

16.7M

3 ms (GTG)

Frequency (H/V) H: 30 kHz - 80 kHz

V: 56 Hz - 75 Hz

Input Analogue

Digital

S-Video

CVBS

15-Pin D-Sub

24-Pin DVI-D

4-Pin Mini DIN

RCA

Power AC-DC Adaptor

Power

Consumption

External DC 12V

AC 100 – 240 V, 50 – 60 Hz

< 48 W (On)

< 2 W (Stand-by)

< 1 W (Off)

NeoV™

Optical Glass

Thickness

Reection Rate

Transmission Rate

Coating Hardness

3.0 mm (0.12”)

< 1%

> 96%

> 9H

Plug & Play VESA DCC 2B, DCC/CI

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt 0° ~ +15°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

444 x 419 x 175 mm

(17.5” x 16.5” x 6.9”)

538 x 520 x 226 mm

(21.2” x 20.5” x 8.9”)

Weight Product Weight

Packaged Product Weight

7.9 kg (17.4 lbs)

10.7 kg (23.6 lbs)

Regulation

Approval

Certications &

Compliance

TUV/Bauart, CB, FCC, CE,

BSMI, GOST-R, WEEE, RoHS,

Vista/Basic, REACH

Accessories Supplied Quick Guide, CD ROM

(user manual and drivers),

power cord, power adaptor,

15-Pin D-Sub cable, 24-Pin

DVI-D cable, S-Video cable,

CVBS cable

X-19

NeoV™ Optical Glass and durable metal casing

for water, dust and scratch resistance

Wide range of I/O connectors for exibility and

expandability in endoscopic video installations

Front-panel keypad with Input Select, Screen Menu,

Contrast and Brightness controls for quick adjustments

Available in black or white

Specications X-19
