AG Neovo X-22 Bedienungsanleitung

www.agneovo.com

NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

Given its hard glass protection and

metal casing, the X-22 promises

to excel in all sorts of public

environments, however demanding

they may be.

Built on an LED-backlit panel delivering 1920 x 1080 Full HD

resolution, the X-22 comes with AG Neovo’s AIP technology that

reproduces contrast, colours and details with an extraordinary

faithfulness. Armed with EcoSmart Sensor the energy ecient

X-22 runs on less than 0.5W at stand-by mode, a feature that

ensures its performing nonstop service immaculately. Craed with

equal emphasis on function and form, the slim bezel display is

the logical choice that makes business sense for all sorts of public

places.

> LED-backlit technology with high FHD 1920 x 1080 resolution

> Crisp 2,000,000 dynamic contrast ratio

> Slim 14 mm border & bezel design for a stylish look

> NeoV™ Optical Glass

> AIP technology: PIP and PBP functions; 3D Comb Filter/Deinterlace/Noise

Reduction; Image rotation function

> Selectable aspect ratio for ultimate image

> EcoSmart Sensor for low watt power consumption

> Black-level alignment

> Versatile inputs: VGA, DVI, HDMI, S-Video, CVBS (RCA x 2), Audio in

> Built-in speakers (1.5W x 2)

> Touch sensor control keys to prevent vandalism

> Durable metal housing

> Rigorous screening of the components for mission-critical 24/7 applications

X-22

Specications X-22

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: X22A0, Version 2.1, 20130822

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

LED-backlit TFT LCD

21.5”

FHD 1920 x 1080

0.2482 mm

250 cd/m2 (Typical)

2,000,000 : 1 (DCR)

170°/160° (Typical)

16.7M

3 ms (GTG)

Frequency (H/V) H: 24 kHz - 82 kHz

V: 50 Hz - 75 Hz

Input VGA

DVI

CVBS

S-Video

HDMI

15-Pin D-Sub

24-Pin DVI-D

RCA x 2

4-Pin mini DIN

HDMI x 1

Audio Audio In

Speaker

1 x stereo audio in for PC (audio

jack, 3.5 Ø)

1 x stereo audio in for CVBS (RCA)

or S-Video

1.5W x 2

Power Power Supply

Power Requirements

Consumption

External

DC 12V

<28W (On)

<0.5W (Active Off)

<0.5W (Off)

NeoV™

Optical Glass

Thickness

Reection Rate

Transmission Rate

Coating Hardness

3.0 mm (0.12”)

< 1%

> 96%

> 9H

Operating

Conditions

Temperature

Humidity

0°C ~ 40°C (32°F~104°F)

10%~90% (No condensation)

Storage

Conditions

Temperature

Humidity

-20°C ~ 60°C (-4°F~140°F)

5%~95% (No condensation)

Mounting VESA FPMPMI Yes (100 x 100mm & 75 x 75mm)

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

513 x 369 x 155 mm

(20.2” x 14.5” x 6.1”)

602 x 476 x 212 mm

(23.7” x 18.7” x 8.3”)

Weight (net) w/o base

w base

Packaging Weight

6.3 kg (13.9 lbs)

6.9 kg (15.2 lbs)

9.5 kg (20.9 lbs)

Regulation

Approval

Certications &

Compliance

FCC, CB, CE, BSMI, RoHS, WEEE,

REACH, GOST-R

Accessories Supplied CD ROM(user manual), power

cord, power adapter, 15-Pin D-Sub

cable, audio cable

X-22

NeoV™ Optical Glass protects against scratches,

impacts and other physical damage

On top of PIP and PBP, Smart Omni Viewer oers selectable

aspect ratios and the option of 180° image rotation

Available in black or white

Multiple video inputs (HDMI, DVI, VGA, CVBS, S-Video)

make possible eortless system integration

EcoSmart Sensor and versatile capabilities ensure

round-the-clock operations

Light environment

(Brightness increased)

Dark environment

(Brightness reduced)
