AirLive Ether-FSH2400N Bedienungsanleitung

User’s Manual

Ether-FSH2400N V.1.0

August, 2003

Fast Ethernet Switch

24 × 10/100Mbps

NWay 10/100BASE-TX

Auto MDI/MDI-X

Ether-FSH2400N

Trademarks

OvisLink and OvisLink Logo are registered trademarks of OvisLink Corp. Other product

names and company names are trademarks or registered trademarks of their respective

owners.

FCC Warning

This equipment has been tested and found to comply with the requirements for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These requirements are designed for

reasonable protection against harmful interference when the equipment operating in a

commercial environment. This equipment can generate and radiate electromagnetic energy

and, if not installed and used in accordance with this guide, may cause significant

interference with radio communication. Operation of this equipment in a residential area is

likely to cause interference to household appliances, in which case the user will be required

to amend at his or her own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate preventive measures.

Disclaimer

Contents in this manual are subject to changes without prior notice.

About this User’s Manual

This User’s Manual aims at helping users to know the key features of

Ether-FSH2400N Fast Ethernet Switch and to install it in a

10/100BASE-TX Fast Ethernet Local Area Network (LAN).

Table of Contents

Ether-FSH2400N Fast Ethernet Switch User’s Manual V1.4.1

Table of Contents

TABLE OF CONTENTS ........................................................................................I

1PRODUCT OVERVIEW ........................................................................1

Introduction....................................................................................................................... 1

24 × 10/100Mbps ports Fast Ethernet Switch................................................................. 1

Store-and-Forward Architecture against Packet Loss..................................................... 1

Active Flow Control ....................................................................................................... 1

Full Wire Speed .............................................................................................................. 1

System/Port Status Information at a Glance ................................................................... 2

Product Features............................................................................................................... 3

Basic Features ................................................................................................................. 3

2PREPARATION BEFORE INSTALLATION.........................................4

Unpack the Package.......................................................................................................... 4

The Front Panel.................................................................................................................5

The Rear Panel..................................................................................................................5

Power Switch .................................................................................................................. 5

AC Power Connector ...................................................................................................... 5

Table of Contents

Ether-FSH2400N Fast Ethernet Switch User’s Manual V1.4.1

3INSTALLATION OF THE SWITCH.......................................................6

Quick Installation..............................................................................................................6

3 Steps to Quick Installation........................................................................................... 6

Rack Mounting.................................................................................................................. 6

Desktop Installation .......................................................................................................... 7

Installation Site Preparation............................................................................................ 7

Cabling Requirements ...................................................................................................... 8

Cable requirement for 100BASE-TX Port...................................................................... 8

Straight-through cabling ................................................................................................. 8

Connecting to Power......................................................................................................... 9

4EXPANDING YOUR NETWORK........................................................11

Connectivity Rules .......................................................................................................... 11

10 Mbps Connection (10BASE-T) ............................................................................... 11

Twisted-pair 100Mbps Connection (100BASE-TX) .................................................... 11

Connecting to another Switch/Hub ............................................................................... 11

Straight-through Cable Connection for Switch-to-Switch/hub Connection ................. 11

Transmission Modes ....................................................................................................... 13

Station Ports (10/100BASE-TX Transmission)............................................................ 13

LAN Micro segmentation through Switching Technology.......................................... 13

5LED INDICATORS..............................................................................14

Table of Contents

iii

Ether-FSH2400N Fast Ethernet Switch User’s Manual V1.4.1

Comprehensive LEDs ..................................................................................................... 14

System LED .................................................................................................................. 14

Station Port LEDs ......................................................................................................... 14

Power LED ...................................................................................................................... 14

Diagnostic LEDs.............................................................................................................. 14

Station Port LEDs ........................................................................................................... 15

Link/Act LED ............................................................................................................... 15

FDX LED...................................................................................................................... 15

100M ............................................................................................................................. 15

APPENDIX A PRODUCT SPECIFICATIONS ..................................................16

APPENDIX B TROUBLESHOOTING...............................................................18

Table of Contents

Ether-FSH2400N Fast Ethernet Switch User’s Manual V1.4.1

Figures

Fig. 2-4 Front Panel ........................................................................................................ 5

Fig. 2-5 Rear Panel ......................................................................................................... 5

Fig. 3-8 Fastening the brackets on the switch................................................................. 6

Fig. 3-9 Attaching the Switch to a 19-inch rack ............................................................. 7

Fig. 3-10 Desktop installation......................................................................................... 7

Fig. 3-11 10/100BASE-TX pin assignments for RJ-45 connector ................................. 8

Fig. 3-12 Pin assignments for straight-through cabling.................................................. 9

Fig 3-13 Connecting the Switch to power outlet .......................................................... 10

Table of Contents

Ether-FSH2400N Fast Ethernet Switch User’s Manual V1.4.1

Tables

Table 3-1 Cabling type for 10BASE-T/100BASE-TX................................................... 9

Table 5-1 Station Port LEDs......................................................................................... 15

1 Product Overview

Ether-FSH2400N Fast Ethernet Switch User’s Manual V1.4.1

1Product Overview

Introduction

24 × 10/100Mbps ports Fast Ethernet Switch

Ether-FSH2400N Fast Ethernet Switch is an auto-sensing and auto-negotiating 10/100ABSE-TX

Fast Ethernet Switch. Its twenty-four 10/100Mbps station ports provide 10/100Mbps connections to

Ethernet/Fast Ethernet network.

Ether-FSH2400N’s unique switching fabric provides full wire speed for all ports. With

auto-sensing, Ether-FSH2400N automatically detects the speed of the devices you plug into, and

routes the incoming data to its destination. Its auto-negotiating function allows existing devices

running at different speeds to communicate easily within the same network.

Store-and-Forward Architecture against Packet Loss

When network is under heavy traffic, the shared memory buffer in the switching devices might yield

incorrect detections due to overfed memory buffer. This setback can happen either when data is

transmitted in IEEE802.3x Full Duplex or Back Pressure Flow Control mode. To solve this problem,

Ether-FSH2400N utilizes a fixed memory buffer allocation with Store-and-forward transmission to

ensure an effective buffer allocation for each port.

Store-and-forward transmission controls data flow from transmitting to receiving nodes with the

receiving buffer threshold adjusted to an optimal value, thus guaranteeing against all possible packet

losses.

Active Flow Control

Ether-FSH2400N Fast Ethernet Switch implements in full duplex mode a flow control that is

compliant with the IEEE 802.3x standard. While in half duplex mode, it employs an optional Back

Pressure Flow Control to stall the incoming data when port buffers are saturated. With this flow

control mechanism, it can be ensured that frames dropped during transmission are reduced to a

minimum.

Full Wire Speed

Ether-FSH2400N’s Full Wire Speed feature provides high-end performance for departmental and

workgroup environments at a fraction of the cost of similar devices. Typically, this feature was

found only in high-end switches designed to handle huge corporate networks. With bandwidth needs

and network efficiency concerns, Ether-FSH2400N’s switching fabric design is the perfect answer

for bandwidth enhancement solution.

1 Product Overview

Ether-FSH2400N Fast Ethernet Switch User’s Manual V1.4.1

System/Port Status Information at a Glance

There are 2 sets of LEDs on the front panel: System LEDs and Station Port LEDs.

The System LEDs consist of the Power, ower LED shows Power On/Off status of the switch.

The Station Port LEDs reveal the link status, half/full duplex transmission, 10/100Mbps speed

mode and the collision status of each station port.

For detailed LED information, refer to Chapter 5, LED Indicators.
