AirLive WT-2000ARM Bedienungsanleitung

WT-2000ARM

Turbo-G Wireless ADSL 2/2+ Router

Quick Setup Guide

English ●●

Polski ●●

Deutsch ●●

Español ●●

Czech ●●

Slovensky ●●

Português ●●

Russia ●●

ote: During firmware upgrade, please do not close the

web browse or turn o

the

ower

or 5 minutes.

Turbo-G Wireless ADSL 2/2+

Router

Important Information



The Router mode’s default IP address is 192.168.2.1



The default Subnet Mask is 255.255.255.0



The default login name is admin



The default password is airlive



The default SSID is airlive



The default Channel is 6



Please use only the power adapter provided with the Router

LED Indicators

WT-2000 ARM

LED Status

Indicator Color ON Flashing

Power ●Green Power on -

ADSL ●Green Link

established -

WLAN ●Green - Wireless

Sending/Receiving

LAN ●Green - LAN Sending/Receiving

English

Turbo-G Wireless ADSL 2/2+

Router

Auto Setup Wizard

Interenet: Basic Setting

This setup wizard can be run in Win 98SE/Me/2000/XP. Please make sure

that you have connect your PC to the LAN port of the ADSL router, the

ADSL line is connected to the router before using the Setup Wizard.

1. Please insert the driver CD that came with your device into your

CD-ROM drive, the driver CD will auto start and show the installation

guide. If not, please double click the CD-ROM device icon in "My

computer", and execute the Run.exe.The following screen will be

displayed. Click “Setup Wizard”.

English

Installation Steps

1. Please install your network cards first before the Router

2. Screw-in the antenna (clockwise) into the Antenna connector

3. Connect the power, LAN cable and ADSL cable to the back

4. Use your wireless card to do a site survey, the default ADSL SSID is

“airlive” and Channel is “11”

5. If you need to change router configuration, please follow the

procedure below:

The Router default IP address is 192.168.2.1. Please make

sure your computer IP is in the same subnet as the AP (i.e.

192.168.2.x)

Open the web browser and enter 192.168.2.1. When asked

for Login and Password, just type admin for loginname and

airlive for Password.

English

Turbo-G Wireless ADSL 2/2+

Router English

English

2. This wizard will be executed and try to search for the ADSL

Router.

Turbo-G Wireless ADSL 2/2+

Router

4. Please select the country you have installed the ADSL

router and click “Next”.

English

3. If the router cannot be found, please enter the IP Address and the

Password of the router to search again. Click “Next” to continue.

Turbo-G Wireless ADSL 2/2+

Router

English

5. Please select the ISP (Internet Service Provider) of your

ADSL service.

6. Enter the Username and Password which your ISP has

provided to you if it is needed. Click “Next”.

If your country or ISP is not in the wizard.

Please go to “Manual setup wizard” section for

installion instruction.

Turbo-G Wireless ADSL 2/2+

Router

English

7. Click “Save” to save the settings and reboot the router.

8. The ISP Setting are all finished. If your want to configure

more settiungs. Please Click “Advanced Settings” or click

“Finish” to close the wizard

English

Turbo-G Wireless ADSL 2/2+

Router English

English

Once your Pc has obtained an IP address from upir router, enter default ip

address 192.168.2.1 (router’s IP address) into your PC’s web browser and

press <enter>

Manual Setup Wizard

The login screen below will appear. Enter the “User Name” and

“Password” and then click <OK> to login. By default the user name is

“admin” and the password is “airlive”. For security reasons it is

recommended that you change the password as soon as possible.

The HOME page screen below will appear. The Home Page is divided into

seven sections: Quick Start, Interface Setup, Advanced Setup, Access

Management, Maintenance, Status and Help.

1. Select the Quick Start menu, then click “Run Wizard” to start the

configuration.

Turbo-G Wireless ADSL 2/2+

Router

English

Turbo-G Wireless ADSL 2/2+

Router

Turbo-G Wireless ADSL

2/2+ Router Polski

Ważne Informacje



Domyślnie adres IP to 192.168.2.1



Domyślnie maska podsieci to 255.255.255.0



Domyślnie login name to admin



Domyślnie password to airlive



Domyślnie SSID to airlive



Domyślnie kanał11

Wskaźnik LED

WT-2000 ARM

LED Status

Wskaźnik Kolor Światło stałeŚwiatło błyskające

Power ●Zielony Zasilanie

włączone -

ADSL ●Zielony Połączenie

ustanowione -

WLAN ●Zielony - Bezprzewodowe

wysyłanie/odbieranie

LAN ●Zielony -

Wysyłanie/odbieranie

poprzez przewodową

siećLAN
