WT-2000AP

Turbo-G Wireless AP

User’sManual

AirLive WT-2000AP User’s Manual

The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an

information retrieval system, translated into any language, or transmitted in any form or by any means,

mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written

permission.

Trademarks

All products, company, brand names are trademarks or registered trademarks of their respective companies. They

are used for identification purpose only. Specifications are subject to be changed without prior notice.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against radio interference in a

commercial environment. This equipment can generate, use and radiate radio frequency energy and, if not

installed and used in accordance with the instructions in this manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause interference, in which case

the user, at his own expense, will be required to take whatever measures are necessary to correct the interference.

CE Declaration of Conformity

This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022/A1 Class B.

The specification is subject to change without notice.

AirLive WT-2000AP User’s Manual

Table of Contents

Chapter 1 Introduction ..............................................................................4

Functions and Features.........................................................................4

Packing List..........................................................................................5

Chapter 2 Hardware Installation ...............................................................6

2.1 Panel Layout...................................................................................6

2.2 Procedure for Hardware Installation..............................................8

Chapter 3 Network Settings and Software Installation.............................9

3.1 Make Correct Network Settings of Your Computer.......................9

Chapter 4 Configuring Wireless Access Point........................................10

4.1 Start-up and Log in.......................................................................11

4.2 Status............................................................................................12

4.3 View Log......................................................................................12

4.4 Client List.....................................................................................13

4.5 Wizard ..........................................................................................13

4.6 Basic Setting.................................................................................15

4.7 Advanced Settings........................................................................25

4.8 Maintenance.................................................................................26

Appendix A TCP/IP Configuration for Windows 95/98.........................29

Appendix B 802.1x Setting.....................................................................35

Appendix C WDS Setting.......................................................................40

Appendix D FAQ and Troubleshooting..................................................45

How do I connect AP by using wireless?.....................................45

AirLive WT-2000AP User’s Manual

Congratulations on your purchase of this outstanding AirLive Wireless AP This product is specifically

designed for Small Office and Home Office needs. Instructions for installing and configuring this product can be

found in this manual. Before you install and use this product, please read this manual carefully for fully

exploiting the functions of this product.

Functions and Features

AP Basic functions

zAuto-sensing Ethernet Switch

Equipped with a 4-port auto-sensing Ethernet switch.

zDHCPserver supported

All of the networked computers can retrieve TCP/IP settings automatically from this product.

zWeb-based configuring

Configurable through any networked computer’s web browser using Netscape or Internet Explorer.

Wireless functions

zHigh speed for wireless LAN connection

Up to 54Mbps data rate by incorporating Orthogonal Frequency Division Multiplexing (OFDM).

zRoaming

Provides seamless roaming within the IEEE 802.11b (11M) and IEEE 802.11g (54M) WLAN

infrastructure.

zIEEE 802.11b compatible (11M)

Allowing inter-operation among multiple vendors.

zIEEE 802.11g compatible (54M)

Allowing inter-operation among multiple vendors.

zAuto fallback

54M, 48M, 36M, 24M, 18M, 12M, 6M data rate with auto fallback in 802.11g mode.

11M, 5.5M, 2M, 1M data rate with auto fallback in 802.11b mode.

Security functions

z802.1X supported

When the 802.1X function is enabled, the Wireless user must authenticate to this router first to use the

Network service.

zSupport WPA-PSK and WPA version 1 and 2

When the WPA function is enabled, the Wireless user must authenticate to this router first to

AirLive WT-2000AP User’s Manual

use the Network service

Advanced functions

zSystem time Supported

Allow you to synchronize system time with network time server.

Packing List

zWireless AP unit

zInstallation CD-ROM

zPower adapter

zCAT-5 UTP Fast Ethernet cable

AirLive WT-2000AP User’s Manual

2.1 Panel Layout

2.1.1. Front Panel

Figure 2-1 Front Panel

LED: Ports:

Port Description

PWR Power inlet

Port 1-4 the ports where you will connect networked computers and other

devices.

AirLive WT-2000AP User’s Manual

2.1.2. Rear Panel

Figure 2-2 Rear Panel

LED:

LED Function Color Status Description

Power Power

indication Green On Power is being applied to this product.

Status System

status Green Blinking Status is flashed once per second to indicate system is

alive.

Blinking The WAN port is sending or receiving data.

WLAN

Wireless

activity

Green Blinking Sending or receiving data via wireless

Link.

1~4 Link status Green On An active station is connected to the corresponding

LAN port.

Blinking The corresponding LAN port is sending or receiving

data.

Speed

10/100

Data Rate

Green On Data is transmitting in 100Mbps on the corresponding

LAN port.

Reset To reset system settings to factory defaults

AirLive WT-2000AP User’s Manual

2.2 Procedure for Hardware Installation

2. Decide where to place your WirelessAccess Point

You can place your Wireless Access Point on a desk or other flat surface, or you can mount it on a wall. For

optimal performance, place your Wireless Access Point in the center of your office (or your home) in a

location that is away from any potential source of interference, such as a metal wall or microwave oven.

This location must be close to power and network connection.

2. Setup LAN connection

a. Wired LAN connection: connects an Ethernet cable from your computer’s Ethernet port to one of the

LAN ports of this product.

b. Wireless LAN connection: locate this product at a proper position to gain the best transmit performance.

Figure 2-3 Setup of WLAN and LAN connections for this product.

4. Power on

Connecting the power cord to power inlet and turning the power switch on, this product will automatically

enter the self-test phase. When it is in the self-test phase, the indicators M1 will be lighted ON for about 10

seconds, and then M1 will be flashed 3 times to indicate that the self-test operation has finished. Finally, the

M1 will be continuously flashed once per second to indicate that this product is in normal operation.

AirLive WT-2000AP User’s Manual

To use this product correctly, you have to properly configure the network settings of your computers and install

the attached setup program into your MS Windows platform (Windows 95/98/NT/2000).

3.1 Make Correct Network Settings of Your Computer

The default IP address of this product is 192.168.1.254, and the default subnet mask is 255.255.255.0. These

addresses can be changed on your need, but the default values are used in this manual. If the TCP/IP

environment of your computer has not yet been configured, you can refer to Appendix A to configure it. For

example,

1. configure IP as 192.168.1.1, subnet mask as 255.255.255.0 and gateway as 192.168.1.254, or more

easier,

2. configure your computers to load TCP/IP setting automatically, that is, via DHCP server of this product.

After installing the TCP/IP communication protocol, you can use the ping command to check if your computer

has successfully connected to this product. The following example shows the ping procedure for Windows 95

platforms. First, execute the ping command

ping 192.168.1.254

If the following messages appear:

Pinging 192.168.1.254 with 32 bytes of data:

Reply from 192.168.1.254: bytes=32 time=2ms TTL=64

a communication link between your computer and this product has been successfully established. Otherwise, if

you get the following messages,

Pinging 192.168.1.254 with 32 bytes of data:

Request timed out.

There must be something wrong in your installation procedure. You have to check the following items in

sequence:

1. Is the Ethernet cable correctly connected between this product and your computer?

Tip: The LAN LED of this product and the link LED of network card on your computer must be lighted.

2. Is the TCP/IP environment of your computers properly configured?

Tip: If the IP address of this product is 192.168.1.254, the IP address of your computer must be

192.168.1.X and default gateway must be 192.168.1.254.

AirLive WT-2000AP User’s Manual

This product provides Web based configuration scheme, that is, configuring by your Web browser, such as

Netscape Communicator or Internet Explorer. This approach can be adopted in any MS Windows, Macintosh or

UNIX based platforms.

AirLive WT-2000AP User’s Manual
