Akai DR16 pro Bedienungsanleitung
Version V2.0 addendum
WARNING
To prevent fire or shock hazard, do not
expose this appliance to rain or moisture.
Operator’s Manual
DR16 V2.0 Addendum
Backup to SCSI Tape Drive
The DR16 is now able to make backups to SCSI Tape Drives (SCSI-DAT, etc.) in addition to the
audio DAT backup and backup to ADAT.
Connect the SCSI connector of the SCSI Tape Drive to the SCSI-A connector of the DR16
using an appropriate SCSI cable (bearing in mind all the precautions and considerations
regarding SCSI termination, SCSI ID numbers and the total SCSI cable length).
Preparation of backup
Before making backups, the tape must first be formatted.
1) Press the SUB-MENU key followed by the 1(DISK) key in the numeric keypad then select
on the display by rotating the JOG/SHUTTLE control.
2) Press the STORE/ENT key. The message will appear on the display.
3) Select with the JOG/SHUTTLE control then press the STORE/ENT key. The
message will appear on the display.
4) Select with the JOG/SHUTTLE control then press the STORE/ENT key.
5) The message will be displayed. This is the SCSI ID number of the SCSI Tape
Drive that is to be formatted.
6) Select the SCSI ID number of the SCSI Tape Drive using the JOG/SHUTTLE control and
press the STORE/ENT key to start formatting.
If the tape has been used, the message will appear in the display. Pressing
the STORE/ENT key will cause the tape to be erased and re-formatted.
Press the ESCAPE key to abort formatting.
WARNING
The previous data on the tape will be destroyed once formatting is executed
even when it is aborted. The great care must be taken when formatting the
tape.
Creating a Backup
1) Press the SUB-MENU key followed by the 1(DISK) key in the numeric keypad then select
on the display by rotating the JOG/SHUTTLE control.
2) Press the STORE/ENT key. The message will appear in the display.
3) Select with the JOG/SHUTTLE control then press the STORE/ENT key . The
message TRANSMIT will appear in the display.
4) Select with the JOG/SHUTTLE control (if not already selected) and then press
the STORE/ENT key.
5) The message will be displayed. This is the SCSI ID number of the SCSI Tape
Drive that is to be formatted.
6) Select the SCSI ID number of the SCSI Tape Drive using the JOG/SHUTTLE control and
press the STORE/ENT key. The message will appear in the display.
7) Select the SCSI ID of the hard disk that is to be backed up using the JOG/SHUTTLE
control.
Page 1
DR16 V2.0 Addendum
Select “0” to backup the internal hard disk.
8) Select the type of backup mode ( or ) with the JOG/SHUTTLE control
then press the STORE/ENT key.
. . . to backup the entire contents of disk
. . . to backup by the project
9) When is selected in step 8) above, select the project name you want to backup
using the JOG/SHUTTLE control and then press the STORE/ENT key to start the backup.
When the backup is completed, the message will be displayed momentarily, then it
resumes normal mode operation.
Press the ESCAPE key to abort backup operation.
Note1: If the tape in the SCSI Tape Drive is write protected, the message will
appear on the display and the backup operation will pause allowing you to eject the tape and
disable its write protect tab. Press the STORE/ENT key to continue the backup operation, after
disabling the write protecting tab (or ESCAPE to abort).
Note2: If the tape already contains backup data, the message will appear in the
display and the backup operation will be aborted automatically.
Note3: If the tape is not formatted, the message will appear in the display. The
tape will be formatted when the STORE/ENT key is pressed. ALL DATA ON THE TAPE WILL BE
ERASED!!
Backup to multiple tapes
If a single tape cannot accommodate the entire backup data, it is possible to back it up across
several tapes.
10) When the tape becomes full during backup, the backup operation is temporarily stopped
and the message will appear in the display.
11) Replace the tape in the SCSI Tape Drive with a new formatted tape.
12) Press the STORE/ENT key to resume backup.
When the backup is completed, the message will appear in the display momentarily,
then it resumes the normal mode operation.
Press the ESCAPE key to abort backup.
NOTE: When backing up to multiple tapes, it is recommended that you number the tapes
carefully in sequence for the purpose of proper restoring later.
Page 2
DR16 V2.0 Addendum
Backup of multiple disks
The DR16 may use audio data spread over several disks for a single project. When such a project
is backed up, the DR16 will automatically access the appropriate disks that contain the necessary
audio data. However, if the same audio data is used for several projects, the same audio data will
be backed up in duplicate.
If the entire disk mode is selected and the project(s) use multiple disks, the message
will appear in the display. Press the STORE/ENT key to continue the backup operation or
press the ESCAPE key to abort.
NOTE: When ENTIRE MODE is selected for backup, it will backup one disk only. When the
backup is successfully finished, the other disks that contains the necessary audio data must also
be backed up separately, again in the ENTIRE DISK mode. Please note that It is not possible to
backup data from several disks onto a single tape.
Verifying backup data
The DR16 can verify the backup data.
1) Press the SUB-MENU key followed by the 1(DISK) key in the numeric keypad and then
select on the display by rotating the JOG/SHUTTLE control.
2) Press the STORE/ENT key . The message will appear in the display.
3) Select with the JOG/SHUTTLE control then press the STORE/ENT key. The
message will appear in the display.
4) Select with the JOG/SHUTTLE control and then press the STORE/ENT key.
5) The message will be displayed. This is the SCSI ID number of the SCSI Tape
Drive that is to be verified.
6) Select the SCSI ID number of the SCSI Tape Drive using the JOG/SHUTTLE control and
press the STORE/ENT key to start verifying.
Assuming the verify process is completed without any errors, the message will
appear in the display momentarily, then it resumes the normal mode of operation.
If any error is detected, the message will be displayed.
Page 3
DR16 V2.0 Addendum
Restore from SCSI Tape Drive
The RESTORE process will restore your backups from the SCSI Tape Drive back to the hard disk.
Restore
1) Press the SUB-MENU key followed by the 1(DISK) key in the numeric keypad then select
on the display by rotating the JOG/SHUTTLE control.
2) Press the STORE/ENT key . The message will appear in the display.
3) Select the SCSI ID number of the hard disk that is to be restored using the JOG/SHUTTLE
control and press the STORE/ENT key.
4) The message will be displayed. Select using the
JOG/SHUTTLE control.
5) Press the STORE/ENT key and the message will appear in the display. This is
the SCSI ID of the SCSI Tape Drive you are restoring from.
6) Select the SCSI ID of the SCSI Tape Drive using the JOG/SHUTTLE control then press the
STORE/ENT key to start restoring.
NOTE: If the data on the tape is not read properly for some reason, the message will
appear on the display and the restore operation is aborted.
Restoring from multiple tapes
When restoring backups spread across several tapes, the message will appear in
the display when a tape comes to an end during the restore operation.
7) Replace the tape in the SCSI Tape Drive with the next one required.
8) Press the STORE/ENT key to continue restoring.
Press the ESCAPE key to abort the restore operation.
NOTE: When the data has been backed up over several tapes, the tapes MUST be loaded in the
same order as they were backed up. If a wrong tape is inserted, the message will
appear on the display and the restore operation will pause, allowing you to insert the correct tape.
To continue restoring, place the correct tape then press the STORE/ENT key.
Interchangeability with DD1500
The AKAI DD1500 system allows you to store several backups on a single tape, while the DR16
can store only one backup. Further, the title of the backup made on the DR16 is always fixed as
“Backup”. This cannot be changed by the user.
If tapes with several backups originally made by the DD1500 are used, the DR16 will restore the
first backup it can find (i.e. the data stored at the beginning of the tape). Subsequent backups
that may be on the tape will be ignored and are not accessible.
Page 4
DR16 V2.0 Addendum
Messages during Backup and Restore
The file count or the following messages will be displayed whilst the DR16 is backing up or
restoring data to or from the SCSI Tape Drive:
Preparing to access the SCSI Tape Drive
Searching the backup data on the SCSI tape
Rewinding the SCSI tape
Ejecting the SCSI tape from the SCSI Tape Drive
PROJECT SAVE
The new menu has been added to the UTILITY page of SUB-MENU mode. This
enables to save projects under different names.
This allows you to save a project that may have undergone extensive editing either as an
alternative version of the song or as a safeguard in case of any irreversible mistake.
Another application for this is to create ‘template’ projects. These are empty projects that contain
certain configurations of customised settings files which can subsequently be used as the basis
for new projects that require these settings. The actual projects you make using these ‘templates’
can, of course, also be saved with a new name.
To save a project with a different name.
1) Press the SUB-MENU key followed by the UTILITY key.
2) Select using the JOG/SHUTTLE control then press the STORE/ENT key.
3) Input the new project name you want to save using the JOG/SHUTTLE control.
4) Press the STORE/ENT key to save.
