Description
The 911D diesel engine Powerig is
designed to be used with a wide range of
Huck hydraulic Installation Tools (including
Bobtail Tools -see utilisation ), and will
operate one Tool. The maximum Pull
Pressure is 700 bar (10150 psi) and the
maximum Return Pressure is 400 bar (
5800 psi). The Powerig is equipped with a
12 vdc Battery and an electric Starter
Motor operated by a Key Switch.
The Engine and Pump run continuously
and a low hydraulic pressure , (Idle
Pressure ), ensures that the Tool Piston is
kept in the forward position when the Tool
is not being used. The Installation Tool is
connected to the Powerig by means of
Pull and Return pressure Hydraulic Hoses
and an electrical Control Cord. The
Powerig Hydraulic Directional Valve
(HDV), is controlled from the Installation
Tool Trigger by a 12 VDC remote control
circuit.
When operating ST & DT type Bobtail
Tools, or non-Bobtail Tools, the operator
presses and holds the Tool Trigger which
starts the Tool cycle to install the
Fastener. Once the Fastener is installed,
the Trigger is released and the Tool
Piston and Nose Assembly return to the
fully forward position, the Tool/Nose
Assembly are ejected from the installed
Fastener.
When operating “IT” type Bobtail Tools, a
Limit Switch (sometimes referred to as a
Micro-Switch), & a red LED Light on the
Tool are activated when the Nose
Assembly is correctly located onto the
Fastener. The Tool Trigger will only
function if the Limit Switch has been
activated (indicated by the red LED). The
operator now presses and holds the
Trigger which starts the Tool cycle to
install the Fastener. As long as the
Trigger is kept pressed, the Bobtail Collar
will be Swaged correctly and the Tool and
Nose Assembly will return and eject from
the installed Fastener automatically.
“ST” type Bobtail Tools also have a Micro-
Switch and LED light but the operator has
to release the Trigger when the Bobtail
Collar is fully swaged. “DT” Tools also
function that way but do not have a Limit
Switch or LED.
!""#$%&'()*+$,()*(-$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$./0&1$21-3(4*4+$,5-3(6-
Powerig type 911d
Flow L/min (Imp. Gals/min) 1.22 (0.26)
(at Engine speed of 1800 RPM)
Pull Pressure max. bar (p si) (See Note 1, p age 5) 700 (10150)
Swage Pressure max. bar (psi)600(8700)
Return Pressure max. bar (p si) (See Note 2, p age 5) 600 (8700)
Diesel Engine, single cylinder Lombardini 15LD350
(see sep arate Manual for additional information)
Hydraulic Pump Axial, 4 piston
Control Circuit 12 VDC via Alternator
Starter Motor Circuit 12 VDC via Battery
Battery 12 VDC 55 Amp Hour
Noise T B A
Hydraulic Oil Reservoir cap acity max ltrs (imp. Gals) 14.0 (3.11)
Length mm (inches) 850 (33 ‰ )
(without removable Handles)
Width (including wheels) mm (inches) 650 (26)
Height mm (inches) 750 (29.5)
Diameter of min wheels mm (inches) 200 (7.5 )
WeightincludingfluidKg(lbs) 158 (344)
Specification
