Datasheet | IEEE 802.3af Power over Ethernet

AT-6101

Single Port PoE Injector

IEEE 802.3af Power over Ethernet

Injector

The AT-6101 Power over Ethernet Injector

provides data and power through the Ethernet

cable to PoE-equipped devices, such as Access

Points, IP Cameras,VoIP phones and any other

equipment supporting the IEEE 802.3af

standard.

Using the companion AT-6102 PoE Splitter even

non PoE devices can be remote powered with

all the benefits of PoE remote powering.

IEEE 802.3af Detection

The AT-6101 complies to IEEE 802.3af standard

and can detect if the connected device supports

IEEE 802.3af and then provides the power to

the device. If the injector detects that the

connected device does not support IEEE

802.3af then it will not provide the power to

the connected device avoiding damages.

Main Applications

Sensible cost savings can be achieved using the

AT-6101 PoE injector for remotely powering

VoIP phones, IP cameras,Wireless Access Points

and any other PoE powered device.

There is no need for additional power cabling

since the AT-6101 feeds power to the

equipment through the same cable used for

data.

Connecting the AT-6101 Power over Ethernet

Injector to a UPS protected power line easily

protects the powered device from power

outages.

The AT-6101 PoE Injector helps in protecting

network investments. In fact there's no need to

replace the existing LAN infrastructure for

connecting PoE enabled devices.

The AT-6101 PoE injector is usually installed

close to the LAN switch but may be installed

close to the powered device as a standard

power supply.

Key Features

•Power over Ethernet Injector

•Remote power feeding application

•Shortcircuit protection

•Mix Ethernet and power into a single LAN

cable

•Deliver power up to 100 meters

•Light weight and compact size

•IEEE 802.3af compliant

•Plug-and-Play

•RoHS and WEEE compliant

•CE, FCC, GOST, C-Tick approved

•UL Listed

AT-6101

Single Port PoE Injector

Allied T

elesis www.alliedtelesis.com

Technical Specifications

Physical Characteristics

Dimensions: 11.7cm x 6cm x 3.5cm

(W x D x H)

Weight: 180g (0.4 lbs)

Status Indicators (LEDs)

Power On Green

Power Characteristics

Power: AC100-240V (50/60Hz,+2/-4%),

Input current (0.1A)

Power

consumption: < 16W

Power Feed: 48vDC, 0.35A, 15.4W

Environmental Specifications

Operating Conditions

Max Temperature: 0°C to 45°C (41°F to 113°F)

Relative Humidity: 10% to 90% (non-condensing)

Storage Conditions

Max Temperature: 0°C to 70°C (32°F to 158°F)

Relative Humidity: 8% to 90% (non-condensing)

Robustness

MTBF: > 180,000 hrs

Interfaces

Data Out

LAN: 10/100TX RJ-45 female

Cable: EIA/TIA-568 100-ohm (100m)

10T: 4-pair UTP/STP Cat.3, 4, 5

100TX: 4-pair UTP/STP Cat.5

Power feed: V+ on pins 4 and 5

V-on pins 7 and 8

Data In

LAN: 10/100TX RJ-45 female

Regulatory Approvals

EMI/EMC: FCC class B, CE

Safety: UL, cUL, CE/EN60950, UL60950, C-Tick,

GOST

RoHS Compliant

Protocols and Standards

IEEE 802.3

IEEE 802.3u

IEEE 802.3af

Ordering Information

AT-6101-xx

IEEE 802.3af Power over Ethernet Injector

where xx= 10 US Power Cord

30 UK Power Cord

40 AU Power Cord

50 EU Power Cord

Associated Products

AT-6102

IEEE 802.3af Universal Multi-voltage PoE Splitter

AT-6101 |Single Port PoE Injector

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 T

ai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

elesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000210-00 Rev B
