Allied Telesis AT-FS705LE Bedienungsanleitung
AT-FS705LE
Fast Ethernet Switch
Installation Guide
PN 613-50138-00 Rev D
Copyright © 2003 Allied Telesyn, Inc.
960 Stewart Drive, Suite B, Sunnyvale, CA 94085, USA
All rights reserved. No part of this publication may be
reproduced without prior written permission fromAllied
Telesyn, Inc.
Ethernet is a registered trademark of Xerox Corporation. All
other product names, company names, logos or other
designations mentioned herein are trademarks or registered
trademarks of their respective owners.
Allied Telesyn, Inc. reserves the right to make changes in
specifications and other information contained in this
document without prior written notice. The information
provided herein is subject to change without notice. In no
event shall Allied Telesyn, Inc. be liable for any incidental,
special, indirect, or consequential damages whatsoever,
including but not limited to lost profits, arising out of or
related to this manual or the information contained herein,
even if Allied Telesyn, Inc. has been advised of, known, or
should have known, the possibility of such damages.
iii
Electrical Safety and Emission
Compliance Statement
Standards: This product meets the following standards.
U.S. Federal Communications Commission
Declaration Of Conformity
Manufacturer Name: Allied Telesyn, Inc.
Manufacturer Address: 960 Stewart Drive, Suite B
Sunnyvale, CA 94085 USA
Manufacturer Telephone: 408-730-0950
Declares that the product: Fast Ethernet Switch
Model Number: AT-FS705LE
This product complies with FCC Part 15B, Class B Limits:
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device must not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Radiated Energy
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to Part
15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with instructions, may cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on. The user is
encouraged to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the
receiver.
iv
RFI Emission FCC Class B
EN55022 Class B
VCCI Class B
C-TICK 1
Warning: In a domestic environment this product
may cause radio interference in which case the
user may be required to take adequate measures.
2
Immunity EN55024 3
Electrical Safety EN60950 (TUV)
UL60950 (cULus)4
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
Changes and modifications not expressly approved by the
manufacturer or registrant of this equipment can void your
authority to operate this equipment under Federal
Communications Commission rules.
Industry Canada
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du
Canada.
v
Important: Appendix A contains translated safety
statements for installing this equipment. When you see the
, go to Appendix A for the translated safety statement in
your language.
Wichtig: Anhang A enthält übersetzte Sicherheitshinweise
für die Installation dieses Geräts. Wenn Sie sehen,
schlagen Sie in Anhang A den übersetzten Sicherheitshinweis
in Ihrer Sprache nach.
Vigtigt: Tillæg A indeholder oversatte sikkerhedsadvarsler,
der vedrører installation af dette udstyr. Når De ser symbolet
, skal De slå op i tillæg A og finde de oversatte
sikkerhedsadvarsler i Deres eget sprog.
Belangrijk: Appendix A bevat vertaalde
veiligheidsopmerkingen voor het installeren van deze
apparatuur. Wanneer u de ziet, raadpleeg Appendix A
voor vertaalde veiligheidsinstructies in uw taal.
Important: L'annexe A contient les instructions de sécurité
relatives à l'installation de cet équipement. Lorsque vous
voyez le symbole , reportez-vous à l'annexe A pour
consulter la traduction de ces instructions dans votre langue.
Tärkeää: Liite A sisältää tämän laitteen asentamiseen
liittyvät käännetyt turvaohjeet. Kun näet -symbolin, katso
käännettyä turvaohjetta liitteestä A.
Importante: l’Appendice A contiene avvisi di sicurezza
tradotti per l’installazione di questa apparecchiatura. Il
simbolo , indica di consultare l’Appendice A per l’avviso di
sicurezza nella propria lingua.
Viktig: Tillegg A inneholder oversatt sikkerhetsinformasjon
for installering av dette utstyret. Når du ser , åpner du til
Tillegg A for å finne den oversatte sikkerhetsinformasjonen
på ønsket språk.
Importante: O Anexo A contém advertências de segurança
traduzidas para instalar este equipamento. Quando vir o
símbolo , leia a advertência de segurança traduzida no seu
idioma no Anexo A.
vi
Importante: El Apéndice A contiene mensajes de seguridad
traducidos para la instalación de este equipo. Cuando vea el
símbolo , vaya al Apéndice A para ver el mensaje de
seguridad traducido a su idioma.
Obs! Bilaga A innehåller översatta säkerhetsmeddelanden
avseende installationen av denna utrustning. När du ser ,
skall du gå till Bilaga A för att läsa det översatta
säkerhetsmeddelandet på ditt språk.
vii
Table of Contents
Electrical Safety and Emission
Compliance Statement ...............................iii
Table of Contents........................................ vii
Welcome to Allied Telesyn.........................ix
Where to Find Related Guides........................ix
Document Conventions ...................................ix
Contacting Allied Telesyn...............................xi
Online Support .........................................xi
E-mail and Telephone Support................xi
Returning Products..................................xi
For Sales or Corporate Information ....... xii
Chapter 1
Overview ........................................................ 1
Key Features.................................................... 2
Physical Description........................................ 3
Ports 1 Through 4..................................... 3
Port 5 and the Uplink Port ...................... 4
Status LEDs .................................................... 5
Auto MDI/MDI-X............................................. 6
Auto-Negotiation ............................................. 7
MAC Address Table......................................... 9
External Power Supply .................................. 11
Network Topologies........................................ 12
Table of Contents
viii
Standalone Topology ............................... 12
Back-to-Back Topology............................ 13
Chapter 2
Installation ................................................... 15
Verifying the Package Contents .................... 15
Selecting a Site ........................................ 16
Reviewing Safety Guidelines .................. 17
Installing the Switch on a Table or Desktop. 19
Wall-Mounting the Switch ............................. 22
Warranty Registration ................................... 26
Chapter 3
Troubleshooting .......................................... 27
Appendix A
Technical Specifications ........................... 29
Physical ........................................................... 29
Environmental................................................ 29
Temperature ............................................ 29
Humidity.................................................. 29
Altitude .................................................... 29
Electrical Rating............................................. 30
Standards & Compliance ............................... 30
Electrical/Mechanical Approvals ................... 30
Pinout Assignments........................................ 31
Appendix B
Translated Safety and Emission
Information .................................................. 33
ix
Welcome to Allied Telesyn
This guide contains instructions on how to
install the AT-FS705LE Fast Ethernet Switch.
Where to Find Related Guides
The Allied Telesyn web site at
www.alliedtelesyn.com offers you an easy
way to access the most recent documentation,
software, and technical information for all of
our products. For product guides, select
“Support & Services” from our web site.
Document Conventions
This guide uses the following conventions:
Note
A note provides additional information.
Welcome to Allied Telesyn
x
Caution
Cautions informs you that performing or
omitting a specific action may result in
equipment damage or loss of data.
Warning
Warnings informs you that performing or
omitting a specific action may result in
bodily injury.
