Alloy Maxhub C65FA Bedienungsanleitung
1
C65CA-BO9072D-M
Service Manual V1.0
2
Document Revision History
Version
Modification
Date
Page
NO.
Updated Instructions
Reviser
Confirmed
by
1.0
9/19/2020
All
Release Version
Hooke
Lin
Yiqingduo
3
CONTENT
Safety Instructions...............................................................................................................................4
I. Safety warning..................................................................................................... 4
II. Notice................................................................................................................. 5
Product Basic Specifications................................................................................................................6
I. Product Appearance............................................................................................6
Electrical Diagram................................................................................................................................9
Disassembly guide.............................................................................................................................10
I. Exploded Views..................................................................................................10
II. Shell Disassemble............................................................................................. 11
III. Circuit Boards Disassemble............................................................................. 11
IV. Touch Frame Disassembly............................................................................... 16
Internal Cables...................................................................................................................................18
I. Cable Connection Guide....................................................................................18
II. Cable Connection Diagram...............................................................................19
Key Parts List (For reference only).....................................................................................................22
Principle of Key Components............................................................................................................ 23
I. Three-in one Main Board (TP.T972.360W)........................................................ 23
II. Wifi Board (SRV.AP_WiFi_IoT.01)..................................................................... 27
III. Touch Frame(X65G03)..................................................................................... 28
Troubleshoot steps............................................................................................................................ 30
I. LED does not turn red........................................................................................30
II. LED does not turn blue.....................................................................................31
III. Touch issue...................................................................................................... 32
IV. PC issue............................................................................................................33
V. LED turn blue but no backlight......................................................................... 34
Firmware update procedure............................................................................................................. 35
I. Upgrade All (TV & MCU)....................................................................................35
II. Touch frame Update......................................................................................... 36
4
Safety Instructions
Please read the safety information carefully before installing, maintaining, or
disassembling this product.
I. Safety warning
The current of power supply, telephone and communication cable is dangerous
and the on/off button, power switch on the device do not cut off the current
completely. To avoid the danger of electric shock:
Be aware that the device may have several power supply cables at the same time.
To cut off the power, make sure all power supply cables are disconnected.
Do not connect or disconnect any cables, install, maintain, or reset the product
during thunderstorm.
Connect all power cables to the right and use the well grounding power supply
socket.
Connect all devices to the proper connector.
Connect or disconnect cables with one hand is recommended.
Do not turn on any device when there is a fire, flood, or collapse of a house.
Please disconnect the power cable, remote communication system, network,
modem, and other devices before opening the screen, unless otherwise
specified in the installation and configuration process.
When the product is installed, moved or opened, the step of cable connection or
disconnection is provided as below.
To connect cables：
1. Turn off all devices.
2. Connect power cords to devices.
3. Connect signal/ communication
cables to devices.
4. Connect the power cord to power
supply socket.
5. Turn on devices。
To disconnect cables：
1. Turn off all devices.
2. Unplug power cords from the
socket.
3. Disconnect signal
/communication cables from
connector.
4. Disconnect the power cords from
devices
5
II. Notice
1. When replacing the system battery, please use the same kind of battery.
2. Battery containing lithium, improper operation or handling will cause explode.
Please DO NOT：
Put the battery into water
Heat the battery to more than 100 degrees C (212 degrees F)
Repair or disassemble the battery without authorization
3. The AC switch or button mightn't cut off the AC power supply, Please disconnect
the AC cable if you need.
4. Do not remove any cover of the module with the danger label attached.
6
Product Basic Specifications
I. Product Appearance
Front view
Back view
7
Side view
PC Module
Right side signal input/output
AC insert and switch
8
Back view of the screen
Three-in-one main board
TCON
Woofer
USB board
Key board WiFi board
Speaker
Speaker
9
Electrical Diagram
10
Disassembly guide
I. Exploded Views
NO.
NAME
QTY
NO.
NAME
QTY
1
AG Glass bracket(Upper,Middle)
1
21
Side terminal bracket
1
2
Upper bezel
1
22
Three-in-one main board
1
3
Left external upper corner
1
23
TCON
1
4
Left inside upper corner
1
24
WiFi board
1
5
AG Glass bracket
2
25
Small back cover(Left)
1
6
AG Glass
1
26
Small back cover(Middle)
1
7
Touch frame
1
27
Panel pressing block
2
8
Left bezel
1
28
Small back cover(Right)
1
9
Key board
1
29
Big cover
1
10
AG Glass bracket(Upper)
4
30
Camera & MIC board
1
11
Left external bottom corner
1
31
Camera & MIC cover
1
12
Left inside bottom corner
1
32
Camera cover
1
13
AG Glass bracket(Bottom)
1
33
Camera
1
14
USB board
1
34
Woofer
1
15
Bottom bezel
1
35
Backlight
1
