Note
• Do not deliberately damage this product and put it in damp, direct sunlight or high
temperature environment.
• If improper use, demolition or operation not according to the instructions result in any
damage of your device or product, our company will not be liable for any compensation
or maintenance responsibility.
Introduction Physical Layout
Making the Connection
FCC Warning
Features
Increase the functionality of your iPad Pro/MacBook Pro/Air’s with the ALOGIC USB-C Anchor
Card Reader Hub. Designed and engineered specifically for your USB-C enabled device the
USB-C Anchor Card Reader Hub provides you full access to some of the most popular ports at
home, the oce or on-the-go. Featuring SD and micro SD card reader’s for transferring your
data, photos and videos, USB-C with Power Delivery (60W), USB-A (USB 2.0) supporting up
to 480Mbps data transfer rate and a 3.5mm AUX audio port. With a plug-and-play design, the
Anchor Card Reader Hub becomes an extension of your iPad Pro or MacBook without the need
for software or drivers.
1. Plug the Anchor Card Reader Hub’s USB-C connector into your iPad Pro/MacBook Pro/
Air USB-C port. With a Plug and Play design, the device should work automatically
without the need of additional driver or software installation.
2. Use your existing USB2.0 cables to connect devices like your mouse or USB flash drive.
3. Attach your headphones to the Anchor Card Reader Hub additional 3.5mm audio
headphone jack to listen to music while charging your iPad Pro (2018) simultaneously for
an uncompromising portable experience.
4. The Anchor Grip can be removed and replaced with the opposite orientation to allow
desired position on the left or right of your devise. It can also be removed, and the Hub
used without the anchor grip.
This device complies with part 18 of the FCC Rules. Operation is subject to the following
two conditions:
NOTE: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Anchor Grip
SD card reader
USB-A
USB-C Port (Power Delivery)
Micro SD card reader
3.5mm Audio Port
USB-C Connector
• Highly portable due to its compact and lightweight design
• Crafted from aluminium and soft touch ABS for an elegant design
• Anchor Grip to strengthen the grip/connection between the hub and your device
• Includes a full array of ports – USB-A (USB 2.0), USB-C with Power Delivery (60W), 3.5mm
audio headphone jack and SD and micro SD card reader
• Universal compatibility with most USB-C devices such as the iPad Pro, MacBook Air/Pro, etc
Package Contents
USB-C Anchor Card Reader Hub
User Manual
1
5
6
7
4
3
2
Specifications
Model UCANCCR
Input USB-C
Output
1 x USB-A (USB 2.0) with 480Mbps data transfer rate,
1 x SD and micro SD card reader, 1 x 3.5mm Headphone jack,
1 x USB-C with Power Delivery (60W)
System Requirement iPad Pro, MacBook Pro/Air or any USB-C enabled devices
