Altinex Furniture Mount Interconnect Box... Bedienungsanleitung

DESIGNER SOLUTIONS

MANUAL PART NUMBER: 400-0520-

001

FURNITURE MOUNT

INTERCONNECT BOX

USER’S GUIDE

SP107-101/101C

DESIGNER SOLUTIONS

400-0520-001 1

TABLE OF CONTENTS

Page

PRECAUTIONS / SAFETY WARNINGS...............2

GENERAL..........................................................2

INSTALLATION PRECAUTIONS .......................2

CLEANING.........................................................2

FCC NOTICE .....................................................2

ABOUT YOUR SP107-101......................................3

TECHNICAL SPECIFICATIONS.............................3

PRODUCT DESCRIPTION.....................................5

APPLICATION DIAGRAMS ....................................6

DIAGRAM1: CUTOUT DIMENSIONS................6

DIAGRAM2: DIMENSIONS ...............................7

DIAGRAM3: SP107-101 INSTALLATION..........8

INSTALLING YOUR SP107-101/101C..................9

OPERATION.............................................................9

TROUBLESHOOTING GUIDE...............................9

ALTINEX POLICIES ................................................9

LIMITED WARRANTY/RETURN POLICIES.......9

CONTACT INFORMATION................................9

DESIGNER SOLUTIONS

400-0520-001 2

PRECAUTIONS / SAFETY WARNINGS 1

Please read this manual carefully before using your

SP107-101 AV Interconnect. Keep this manual

handy for future reference. These safety

instructions are to ensure the long life of your

SP107-101 and to prevent fire and shock hazards.

Please read them carefully and heed all warnings.

1.1 GENERAL

•Unauthorized personnel shall not open the unit.

There are high-voltage components inside.

•Qualified ALTINEX service personnel or their

authorized representatives must perform all

service.

1.2 INSTALLATION PRECAUTIONS

•For best results, place the SP107-101 in a dry

area away from dust.

•To prevent fire or shock, do not expose this unit

to water or moisture. Do not place the

SP107-101 in direct sunlight, near heaters or

heat-radiating appliances, or near any liquid.

Exposure to direct sunlight, smoke, or steam can

harm internal components.

•Handle the SP107-101 carefully. Dropping or

jarring can damage the bezel.

•Never place fingers inside the opening on either

side of the unit. This action could cause injury

due to sharp edges inside.

•Disconnect the SP107-101’s power cord to turn

off the main power. This supplies power to the

AC socketson the panel. The power outlet

should be installed near the equipment and

should be easily accessible.

•We recommend using wall outlets with a Ground

Fault Circuit Interrupter (GFCI) for maximum

protection.

•Install all cables according to the instructions

found herein. Do not force or pull any cable or

power cord that is attached to the SP107-101.

1.3 CLEANING

•Surfaces should be cleaned with a dry cloth.

Never use strong detergents or solvents such as

alcohol or thinner. Do not use a wet cloth or

water to clean the unit.

1.4 FCC NOTICE

•This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause

harmful interference, and (2) this device must

accept any interference received, including

interference that may cause undesired

operation.

•This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when the

equipment is operated in a commercial

environment. This equipment generates, uses,

and can radiate radio frequency energy and, if

not installed and used in accordance with the

instructions found herein, may cause harmful

interference to radio communications. Operation

of this equipment in a residential area is likely to

cause harmful interference in which case the

user will be required to correct the interference

at his expense.

•Any changes or modifications to the unit not

expressly approved by ALTINEX, Inc. could void

the user’s authority to operate the equipment.

DESIGNER SOLUTIONS

400-0520-001 3

ABOUT YOUR SP107-101 2

SP107-101

Surface Mount AV Interconnect Plate

The SP107-101 is designed for use in a table,

podium, or other piece of furniture and is part of the

many interconnection solutions offered by

ALTINEX. It provides a means of connecting a

laptop or other audiovisual equipment on the

surface to a presentation system below the

furniture or in another room. The SP107-101 offers

interconnections for the most frequently used

presentation inputs.

•AC power

•Computer audio and video

•Network and USB

Female receptacles for power and computer

signals are provided in the panel. The AC power

cable is permanently attached to the SP107-101

and has a cord length of 10 ft (3 m). Short adapter

cables are preinstalled at the factory for computer

audio, HDMI, S-Video, USB, and network

connections for ease of installation. Bulkhead

connectors are provided for computer video,

composite video, and left and right audio. Six foot

extension cables are provided for all signal

connections.

The SP107-101C is customizable and allows

different connector types to be selected at the time

of purchase. The AC receptacle and circuit breaker

are fixed, but the other connectors can be replaced

with other video, audio, and communication type

connectors. For example, the 15-pin HD computer

video input connector can be replaced with a 9-pin

D-sub connector for serial communication. There

are several options available for use in the network

location. See the ALTINEX website for a complete

list of available connector types including: RCA

jacks, LED indicators, 4-pin Mini-DINs, etc.

TECHNICAL SPECIFICATIONS 3

Specifications are subject to change.

See www.altinex.com for up-to-date information.

FEATURES/

DESCRIPTION SP107-101

PASS-THROUGH

AC Power

10 ft (3 m)

110 VAC, 60 Hz, 5 ANEMA F-M

Audio, Video, USB, and Network

8 in (203 mm)

Computer Audio 3.5mm F-F (1)

Digital Video HDMI F-F (1)

S-Video 4-pin Mini DIN F-F (1)

USB Type-A F-F (1)

Network RJ-45 F-F (1)

Bulkhead Connector

Computer Video 15-pin HD F-F (1)

Composite Video RCA F-F (1)

Left & Right Audio RCA F-F (2)

Accessories Included

Extension cables

6ft (2 m)

§VGA, M-M

§S-Video, M-M

§RCA x3 (V, L, R), M-M

§CAT-5, M-M

§HDMI, M-M

§USB Type-A, M-M

§Audio 3.5mm, M-M

Miscellaneous

Hardware §Mountings brackets

§Mounting screws

Table 1. SP107-101 Description

DESIGNER SOLUTIONS

400-0520-001 4

MECHANICAL SP107-101

Max. Table Thickness 3.0 in (76 mm)

Width 6.4 in (163 mm)

Depth 4.4 in (112 mm)

Height

(from surface down,

not including cables)3.0 in (76 mm)

Net Weight SP107-101 2.4 lb (1.1 kg)

Net Weight Extension Cables 2.2 lb (1.0 kg)

Shipping Weight (approx.) 6.1 lb (2.8 kg)

Material 0.062 in Aluminum

Finish Black paint,

Fine texture

T°Operating (T°Max) 10°C-35°C (40°C)

Humidity 90%non-condensing

Table 2. SP107-101 Mechanical

ELECTRICAL SP107-101

Power Rating

(pass-through AC power) 120VAC, 60Hz, 15A

Table 3. SP107-101 Electrical

DESIGNER SOLUTIONS

400-0520-001 5

PRODUCT DESCRIPTION 4

DESIGNER SOLUTIONS

400-0520-001 6

APPLICATION DIAGRAMS 5

DIAGRAM 1: CUTOUT DIMENSIONS

DESIGNER SOLUTIONS

400-0520-001 7

DIAGRAM 2: DIMENSIONS

DESIGNER SOLUTIONS

400-0520-001 8

DIAGRAM 3: SP107-101 INSTALLATION

DESIGNER SOLUTIONS

400-0520-001 9

INSTALLING YOUR SP107-101/101C 6

Step 1.Cut an opening into the furniture’s

surface.

Note: The furniture can be 3” or less in

thickness. Always confirm dimensions

before cutting to insure that specifications

have not changed.

Step 2.Insert the SP107-101/101Cinto the table

cutout.

Step 3.Refer to Diagram 3and from underneath

the furniture surface, attach the mounting

brackets to the 6-32 studs on the bottom

side of the SP107-101/101C using the

screws provided.

NOTE: If the surface is too thick for the

screws provided, longer 6-32

screws can be used.

Step 4.Secure the audio/video cables by using

cable clamps, tie wraps, or other standard

mounting hardware. Pass the power cord

from the bottom of the housing and attach

it to the furniture separately from the

audio/video cables.

Step 5.Connect the appropriate cables with the

correct input connectors on the bottom of

the unit.

Step 6. The SP107-101/101C is now operational.

OPERATION 7

The SP107-101/101C requires no adjustments for

performance. Once set-up, the SP107-101/101C

will work trouble-free without user intervention.

Connect external devices to the appropriate

connector on the SP107-101/101C.

TROUBLESHOOTING GUIDE 8

The SP107-101/101C supplied was carefully tested

and no problems were detected. However, we

would like to offer the following suggestions:

•Please make sure that the highest quality

network cables are used.

•Make sure that no cable or power cord is

damaged or pinched. If there has been damage,

do not use the SP107-101/101C.Please call the

ALTINEX Customer Service Department at

(714) 990-2300 to have the unit repaired.

ALTINEX POLICIES 9

9.1 LIMITED WARRANTY/RETURN POLICIES

Please see the ALTINEX website at

www.altinex.com for details on warranty and

return policies.

9.2 CONTACT INFORMATION

ALTINEX, Inc.

592 Apollo Street

Brea, CA 92821 USA

TEL: 714 990-2300

TOLL FREE: 1-800-ALTINEX

WEB: www.altinex.com

E-MAIL: [email protected]

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Altinex Schalten Handbücher

Altinex

Altinex MX2406RM Bedienungsanleitung

Altinex

Altinex MX2214RM Bedienungsanleitung

Altinex

Altinex UT260-102 Bedienungsanleitung

Altinex

Altinex MX2106AV Bedienungsanleitung

Altinex

Altinex MX2436RM Bedienungsanleitung

Altinex

Altinex UT260-041 Bedienungsanleitung

Altinex

Altinex MULTI-TASKER MT104-108 Bedienungsanleitung

Altinex

Altinex MX2222AT Bedienungsanleitung

Altinex

Altinex MX2216RM Bedienungsanleitung

Altinex

Altinex MX2456RM Bedienungsanleitung

Altinex

Altinex MX2226AT Bedienungsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

Altinex

Altinex Universal Tilt 'N Plug Interconnect Box... Bedienungsanleitung

Altinex

Altinex MT104-100/103 Bedienungsanleitung

Altinex

Altinex MX430-101 8x8 Bedienungsanleitung

Altinex

Altinex MX2414RM Bedienungsanleitung

Altinex

Altinex DA1916SX Bedienungsanleitung

Altinex

Altinex MULTI-TASKER MT104-102 Bedienungsanleitung

Altinex

Altinex SW1956CT Bedienungsanleitung

Altinex

Altinex SW104-130 Bedienungsanleitung

Altinex

Altinex MT105-8X8 Bedienungsanleitung

Altinex

Altinex MX2100AV Bedienungsanleitung

Altinex

Altinex MX2206RM Bedienungsanleitung

Altinex

Altinex MT304-203 Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Bedienungsanleitung
