SPECIAL APPLICATION

MANUAL PART NUMBER: 400-0399-001

KEYBOARD and MOUSE

TO FIBER OPTIC TRANSMITTER

USER’S GUIDE

DA1935KM

SPECIAL APPLICATION

TABLE OF CONTENTS

Page

PRECAUTIONS / SAFETY WARNINGS ............. 2

GENERAL ......................................................... 2

INSTALLATION................................................. 2

CLEANING ........................................................ 2

FCC /CE NOTICE ............................................. 2

ABOUT YOUR DA1935KM.................................. 3

TECHNICAL SPECIFICATIONS.......................... 3

PRODUCT DESCRIPTION.................................. 4

APPLICATION DIAGRAM ................................... 5

DIAGRAM 1: TYPICAL CONFIGURATION........ 5

DIAGRAM 2: INTERNAL VIEW.......................... 6

INSTALLING YOUR DA1935KM ......................... 7

OPERATION ....................................................... 7

DA1935KM SETTINGS ..................................... 7

CHANGING THE MOUSE ................................. 7

TROUBLESHOOTING GUIDE ............................ 7

LED IS NOT RED .............................................. 7

KEYBOARD/MOUSE DOES NOT WORK ......... 8

ALTINEX POLICY................................................ 8

LIMITED WARRANTY/RETURN POLICY ......... 8

CONTACT INFORMATION ............................... 8

SPECIAL APPLICATION

PRECAUTIONS / SAFETY WARNINGS 1

Please read this manual carefully before using your

DA1935KM. Keep this manual handy for future

reference. These safety instructions are to ensure

the long life of your DA1935KM and to prevent fire

and shock hazard. Please read them carefully and

heed all warnings.

1.1 GENERAL

•Qualified ALTINEX service personnel, or their

authorized representatives must perform all

service.

1.2 INSTALLATION

•To prevent fire or shock, do not expose this unit

to rain or moisture. Do not place the DA1935KM

in direct sunlight, near heaters or heat radiating

appliances, or near any liquid. Exposure to

direct sunlight, smoke, or steam can harm

internal components.

•Handle the DA1935KM carefully. Dropping or

jarring can damage the unit.

•Do not pull the cables that are attached to the

DA1935KM.

1.3 CLEANING

•Clean only with a dry cloth. Never use strong

detergents or solvents, such as alcohol or

thinner. Do not use a wet cloth or water to clean

the unit. Do not open the unit to clean.

1.4 FCC / CE NOTICE

•This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause

harmful interference, and (2) this device must

accept any interference received, including

interference that may cause undesired

operation.

•This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when the

equipment is operated in a commercial

environment. This equipment generates, uses,

and can radiate radio frequency energy and, if

not installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications. Operation

of this equipment in a residential area is likely to

cause harmful interference in which case the

user will be required to correct the interference

at his own expense.

•Any changes or modifications to the unit not

expressly approved by ALTINEX, Inc. could void

the user’s authority to operate the equipment.

SPECIAL APPLICATION

ABOUT YOUR DA1935KM 2

DA1935KM

KEYBOARD/MOUSE TO FIBER OPTIC

TRANSMITTER

The DA1935KM provides a means of transmitting

keyboard and mouse serial data over fiber optic

cable. The DA1935KM is designed to be used

together with an ALTINEX Fiber Optic Receiver,

such as DA1934KM.

The DA1935KM is compact and easy to use. As a

direct connect, it connects directly to the keyboard

and mouse and is able to transmit both keyboard

and mouse data over the same fiber optic cable.

The DA1935KM may also be used to send mouse

and keyboard data to different computers, or

multiple computers by using an Altinex

Multi-Tasker™ Enclosure, with a matrix system that

includes the MT107-204 and MT107-304.

Internal memory allows the user to save the

keyboard configuration for Number Lock, Caps

Lock and Scroll Lock.

TECHNICAL SPECIFICATIONS 3

FEATURES/

DESCRIPTION DA1935KM

GENERAL

Inputs 2

PC Compatible

Keyboard and Mouse 6 Pin Mini DIN Female

Outputs 1

Output Connectors ST Fiber Optic Transmitter

Compatibility

Signal types Keyboard and Mouse

Serial Data

Signal Rate 5Mbaud

Operating Systems Windows 2000, NT and XP.*

Mouse Types

(1) 5 buttons, 1 wheel

(2) 2 buttons, 1 wheel

(3) 2 buttons, no wheel

Table 1. DA1935KM General

MECHANICAL DA1935KM

Material 0.062” ABS 94 HB

Finish ALTINEX Black

Height (inches) 2.40in (60.9mm)

Width (inches) 2.27in (57.7mm)

Depth (inches) 1.00in (25.4mm)

Weight (pounds) 0.14lb (0.06kg)

Ship Weight (pounds) 0.5lbs (0.23kg)

T°Operating 10°C-40°C

T°Maximum 50°C

Humidity 90%non-condensing

MTBF (calculations) 40,000 hrs

Table 2. DA1935KM Mechanical

ELECTRICAL DA1935KM

Input

Keyboard and Mouse Serial

Data TTL Levels

Maximum Rate 5MBaud (5mb/s)

Output

Fiber Optic Receiver

Compatible Fibers 62.5/125um

Power

External Adapter (included) 9V DC, 500mA

Table 3. DA1935KM Electrical

*Windows 98 and earlier operating systems are not

supported.

SPECIAL APPLICATION

PRODUCT DESCRIPTION 4

SPECIAL APPLICATION

APPLICATION DIAGRAM 5

DIAGRAM 1: TYPICAL CONFIGURATION

SPECIAL APPLICATION

DIAGRAM 2: INTERNAL VIEW

DA1935KM

KEYBOARD/MOUSE TRANSMITTER TO FIBER OPTIC CABLE

SPECIAL APPLICATION

INSTALLING YOUR DA1935KM 6

Step 1. Prior to installing the DA1935KM, make

sure the keyboard and mouse are working

normally with the computer.

Step 2. Turn OFF the receiving computer.

Step 3. On the transmitting end, connect the

keyboard to the port labeled KEYBOARD

and the mouse to the port labeled

MOUSE on the side of the unit.

Step 4. Connect the DA1935KM to the

DA1934KM using a fiber optic cable. The

DA1934KM should be connected to the

receiving computer per its user manual.

Step 5. Plug the 9V power adapter into an AC

outlet and then connect the other end to

the POWER input jack on the

DA1935KM.

Step 6. Verify the DA1935KM initializes by

observing the keyboard LED's flash on,

then off and then go to their default state

of Num Lock ON, Caps Lock OFF and

Scroll Lock OFF. Additionally, Verify the

PWR LED next to the power jack is

illuminated RED.

Step 7. Turn ON the receiving computer and wait

for system to boot.

Step 8. Verify the mouse and keyboard operate

on the remote computer.

OPERATION 7

The DA1935KM will operate successfully as long

as cables are attached properly and other technical

specifications are followed.

7.1 DA1935KM SETTINGS

The DA1935KM allows the settings for Num

Lock, Caps Lock and Scroll Lock to be saved in

its internal memory. These settings will be

recalled whenever the unit is restarted. In order

to save these settings, press the left SHIFT key,

then the right SHIFT key and then a number

from 1 to 6 as follows:

Key Setting Saved

1 Num Lock ON

2 Caps Lock ON

3 Scroll Lock ON

4 Num Lock OFF

5 Caps Lock OFF

6 Scroll Lock OFF

NOTE: Do NOT hold down the shift keys during

this process.

7.2 CHANGING THE MOUSE

In order to change the mouse, make sure

everything is on and working correctly.

Turn off the DA1935KM and then replace the

mouse.

Turn the DA1935KM back on and wait for the

initialization process.

Restart the computer.

After restarting the computer, the new mouse

will be recognized and working.

TROUBLESHOOTING GUIDE 8

We have carefully tested and have found no

problems in the supplied DA1935KM. However, we

would like to offer suggestions for the following:

8.1 LED IS NOT RED

The LED should be ON and RED when power is

applied.

Cause 1: No AC power.

Solution: Verify the adapter is plugged into a

working AC outlet and that the outlet

has power.

Cause 2: Adapter is not plugged into

DA1935KM.

Solution: Verify the DC power plug coming

from the AC adapter is plugged all

the way into the DA1935KM.

SPECIAL APPLICATION

Cause 3: The DA1935KM has a problem.

Solution: If there is AC power to the adapter

and the LED still does not turn on,

the DA1935KM or the power

adapter may require service. Call

ALTINEX at (714) 990-2300.

8.2 KEYBOARD/MOUSE DOES NOT WORK

Cause 1: The DA1934KM Receiver has no

power.

Solution 1: The DA1934KM receives its power

from the PC. Make sure the

DA1934KM is connected to the

computer keyboard and mouse

ports. If there is still no power, see

Solution 2.

Solution 2: Verify the computer is turned on and

working. If there is still no power,

call ALTINEX at

(714) 990-2300.

Cause 2: The cables are swapped.

Solution: If both devices are inoperative,

check the attachments to the

DA1934KM and the DA1935KM.

Make sure the mouse is plugged

into the DA1935KM port labeled

Mouse and the keyboard to the port

labeled Keyboard. On the receiving

end, make sure the Mouse output of

the DA1934KM is connected to the

mouse input port on the computer

and the keyboard is connected to

the Keyboard port. If the devices still

do not function properly, see

Cause 3.

Cause 3: The devices are not recognized.

Solution1: Reset the power to the DA1935KM

and wait for the initialization. This

should take only a few seconds. If

the keyboard and mouse still do not

work, see Solution 2.

Solution2: Restart the computer. If the

keyboard and mouse still do not

work, see Cause 4.

Cause 4: A device is bad.

Solution: If only one of the devices is

malfunctioning, connect the

inoperative device directly to the

computer. If the device is good, see

Cause 5.

Cause 5: Fiber optic cable is damaged.

Solution: Move the DA1934KM and the

DA1935KM close together and

connect the two units using a short

piece of known good fiber optic

cable. If the devices function

properly, the cable needs to be

replaced. If the device is still not

functioning, call ALTINEX at

(714) 990-2300.

ALTINEX POLICY 9

9.1 LIMITED WARRANTY/RETURN POLICY

Please see the Altinex website at

www.altinex.com for details on warranty and

return policy.

9.2 CONTACT INFORMATION

ALTINEX, INC

592 Apollo street

Brea, CA 92821 USA

TEL: 714 990-2300

TOLL FREE: 1-800-ALTINEX

WEB: www.altinex.com

E-MAIL: [email protected]

Inhaltsverzeichnis

Andere Altinex Sender Handbücher

Altinex

Altinex Multi Tasker MT103-122 Bedienungsanleitung

Altinex

Altinex TP315-106 Bedienungsanleitung

Altinex

Altinex TP115-121 Bedienungsanleitung

Altinex

Altinex TP110 Bedienungsanleitung

Altinex

Altinex DA1930CT Bedienungsanleitung

Altinex

Altinex MT315-101 Bedienungsanleitung

Altinex

Altinex SIGNAL MANAGEMENT SOLUTIONS UT260-105 Bedienungsanleitung

Altinex

Altinex MT319-401 Bedienungsanleitung

Altinex

Altinex ISV3000-W Bedienungsanleitung

Altinex

Altinex DA1930CT Bedienungsanleitung

Altinex

Altinex Multi Tasker MT103-122 Bedienungsanleitung

Altinex

Altinex MT318-102 Bedienungsanleitung

Altinex

Altinex TP316-101 Bedienungsanleitung

Altinex

Altinex TP315-105 Bedienungsanleitung

Altinex

Altinex TP115-110 Bedienungsanleitung

Altinex

Altinex Intera Video+Audio to Twisted Pair (UTP) Transmitter... Bedienungsanleitung

Altinex

Altinex MUSE MU400-111 Bedienungsanleitung

Altinex

Altinex VGA to CAT-5 Transmitter Card MT103-115 Bedienungsanleitung

Altinex

Altinex Computer/Component Video+ Audio Dual Twisted Pair Transmitter... Bedienungsanleitung

Altinex

Altinex MT318-101 Bedienungsanleitung

Beliebte Sender Handbücher anderer Marken

NIVELCO

NIVELCO EasyTREK SCA-300 Series Betriebsanleitung

Honeywell

Honeywell 5816WMBR Bedienungsanleitung

Kamstrup

Kamstrup READy MTU Betriebsanleitung

Omega

Omega ZW Series Bedienungsanleitung

ABB

ABB Field 264H Leitfaden

Alinco

Alinco DJ-V17T Bedienungsanleitung

Dejero

Dejero EnGo 3x Bedienungsanleitung

Rosemount

Rosemount 4600 Bedienungsanleitung

Speaka Professional

Speaka Professional 2342740 Bedienungsanleitung

trubomat

trubomat GAB 1000 Bedienungsanleitung

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Bedienungsanleitung

Rondish

Rondish UT-11 Bedienungsanleitung

MG 10JRE Bedienungsanleitung

Burkert

Burkert 8177 Bedienungsanleitung

Firetide

Firetide HotPort 3203 Handbuch

Tele Radio

Tele Radio T9-02 Bedienungsanleitung

Rotronic

Rotronic HygroFlex HF3 Series Bedienungsanleitung

Jamara

Jamara FCX6 Pro Tel Bedienungsanleitung
