PIX-221

Electronic Time Recorder

Operation Manual

SAFETY

Installation, maintenance, etc. of this apparatus should only be performed by a

qualified electrician.

PROPRIETARY NOTICE

This document contains proprietary information and such information may

not be reproduced in whole or in part without the written permission from

Amano Cincinnati, Inc., 140 Harrison Avenue, Roseland, New Jersey, 07068

Amano Cincinnati, Inc. reserves the right to make equipment changes and

improvements which may not be reflected in this document. Portions of this

document may have been updated to include the latest hardware or firmware

version, if applicable.

We recommend that this document be read in its entirety before any attempt is

made to operate the equipment.

Before You Begin

The Daylight Saving Time date settings have been preset. DO NOT change

the Daylight Saving Time date settings unless you live in Arizona, Hawaii,

parts of Indiana, or any other area that does not use Daylight Saving TIme.

External View

Removing the Cover & Packing Materials

1. Lift the printer block and remove

the spacer.

2. Insert the key provided and turn

clockwise to open the case. Lift

the cover to remove.

Page 1

3. Remove the spacer

between the Ribbon

Cartridge and the Printer

Carriage.

4. Re-install the cover. Your

PIX-21 is ready for use!

Front Panel Description

The RESET Button is located on the

bottom of the clock. It is used with the

CHANGE or ENTER Button to start the

Program mode.

When in the Program mode, press the

PRINT/CHANGE Button to change data

or advance to the next menu selection.

When in the Program mode, press the PRINT/ENTER Button to accept a value

or enter a selection into memory.

When in the Normal mode, the PIX-21 as a default will automatically print when

a time card or piece of paper is inserted. This default can be changed in the

Program mode to require both PRINT buttons to be pressed simultaneously in

order to print.

Page 2

LCD Display Window Print/Change Button Print/Enter Button

Mounting the Clock

1. Remove the mounting bracket from the clock by pushing forward on the

top tabs “A” and then pushing the tabs down “B” (See below).

2. If you are using the

Mobile Mounting Unit

gooseneck and special

mounting bracket (P/N

AJR-208800), mount

the gooseneck to the

vehicle in the desired

location first. Mount the

special mounting

bracket to the

gooseneck using the

three #M5 acorn nuts

and washers provided.

You may discard the

original PIX mounting

bracket if you wish.

3. If you are not using the Mobile Mounting Unit, securely mount the PIX

mounting bracket on the wall using three #10 wood screws or equivalent.

4. Refer to the illustration below to plug the appropriate power cord into the

bottom rear of the clock.

If you are using the DC power cord, locate the rubber grommet on the

power cord and install the grommet into the notch in the housing. The

power cord will exit the clock through the opening on the bottom. Refer

to page 16 for more information about using the DC power cord.

Page 3

Quick Program Mode

These instructions must be followed in the order in which they are given.

The PIX-21 has two programming modes: Normal and Quick. Either mode

may be accessed by simply entering a specific password. To enter the

Normal programming mode, use the password “8088” and follow the

instructions to program all the items. Refer to page 9 to enter the Normal

mode password. For a quick setup of a particular item in the PIX-21, use the

alternate password which correlates to the print style of choice. (See chart on

page 5.) The “Quick” mode shortens the print style setup. Refer to page 6 to

enter the Quick mode.

1. Understanding the Front Panel

2. Plug In the Power Cord and Make a Test Print

Insert a piece of paper or time card into the PIX-21. The clock will

automatically print a 4-digit YEAR, MONTH, DATE, and TIME with AM or PM.

Note: The PIX-21 will automatically adjust for Daylight Saving Time.

If these conditions are unsatisfactory, you must change the program settings.

3. The Reset Button

Press the RESET button to exit the programming mode at any time and

return to the time display.

Page 4

LCD Display Window Print/Change Button Print/Enter Button

The RESET Button is

located in the right lower

corner on the bottom of

the clock.

Chart 1 - Passwords for the Quick Program Mode

Password Print Style Print Direction

6510 DAY, 12H, 60th Right Side Printing

6210 DAY, 24H, 10th Right Side Printing

6810 DAY, 24H, 100th Right Side Printing

6520 DATE, 12H, 60th Right Side Printing

6620 DATE, 24H, 60th Right Side Printing

6820 DATE, 24H, 100th Right Side Printing

6540 DATE, MONTH, 12H, 60th Right Side Printing

6640 DATE, MONTH, 24H, 60th Right Side Printing

6840 DATE, MONTH, 24H, 100th Right Side Printing

6680 DATE, MONTH, 2-digit YEAR, 24H, 60th Right Side Printing

6530 MONTH, DATE, 12H, 60th Right Side Printing

6630 MONTH, DATE, 24H, 60th Right Side Printing

6830 MONTH, DATE, 24H, 100th Right Side Printing

6570 2-digit YEAR, MONTH, DATE, 12H, 60th Right Side Printing

6071 2-digit YEAR, MONTH, DATE, RCV’D Right Side Printing

6072 2-digit YEAR, MONTH, DATE, SENT Right Side Printing

6073 2-digit YEAR, MONTH, DATE, FAX’D Right Side Printing

6074 2-digit YEAR, MONTH, DATE, VOID Right Side Printing

6075 2-digit YEAR, MONTH, DATE, PAID Right Side Printing

6076 2-digit YEAR, MONTH, DATE, CFM’D Right Side Printing

6077 2-digit YEAR, MONTH, DATE, APR’D Right Side Printing

6078 2-digit YEAR, MONTH, DATE, CMPL’D Right Side Printing

6079 2-digit YEAR, MONTH, DATE, ORIGN Right Side Printing

6070 2-digit YEAR, MONTH, DATE, FILE Right Side Printing

6910 4 digit YEAR, MONTH, DATE, 12H, 60th Right Side Printing

6920 4 digit YEAR, MONTH, DATE, 24H, 60th Right Side Printing

5510 DAY, 12H, 60th Left Side Printing

5210 DAY, 24H, 10th Left Side Printing

5810 DAY, 24H, 100th Left Side Printing

5520 DATE, 12H, 60th Left Side Printing

5620 DATE, 24H, 60th Left Side Printing

5820 DATE, 24H, 100th Left Side Printing

5540 DATE, MONTH, 12H, 60th Left Side Printing

5640 DATE, MONTH, 24H, 60th Left Side Printing

5840 DATE, MONTH, 24H, 100th Left Side Printing

5680 DATE, MONTH, 2-digit YEAR, 24H, 60th Left Side Printing

5530 MONTH, DATE, 12H, 60th Left Side Printing

5630 MONTH, DATE, 24H, 60th Left Side Printing

5830 MONTH, DATE, 24H, 100th Left Side Printing

5570 2-digit YEAR, MONTH, DATE, 12H, 60th Left Side Printing

5071 2-digit YEAR, MONTH, DATE, RCV’D Left Side Printing

5072 2-digit YEAR, MONTH, DATE, SENT Left Side Printing

5073 2-digit YEAR, MONTH, DATE, FAX’D Left Side Printing

5074 2-digit YEAR, MONTH, DATE, VOID Left Side Printing

5075 2-digit YEAR, MONTH, DATE, PAID Left Side Printing

5076 2-digit YEAR, MONTH, DATE, CFM’D Left Side Printing

5077 2-digit YEAR, MONTH, DATE, APR’D Left Side Printing

5078 2-digit YEAR, MONTH, DATE, CMPL’D Left Side Printing

5079 2-digit YEAR, MONTH, DATE, ORIGN Left Side Printing

5070 2-digit YEAR, MONTH, DATE, FILE Left Side Printing

5910 4 digit YEAR, MONTH, DATE, 12H, 60th Left Side Printing

5920 4 digit YEAR, MONTH, DATE, 24H, 60th Left Side Printing

If you cannot locate the desired print style from the above list, change to the Normal mode

and refer to the instructions for programming the print style manually.

Page 5

4. Entering the Quick Program Mode

The following steps describe how to get into the Quick Program mode.

Note: Please refer to Chart 1 for the password listing.

1. Press and hold down the RESET button.

2. While holding down the RESET button, press and hold down the

ENTER button.

3. While holding down the ENTER button, release the

RESET button.

4. When Pro9 flashes in the display, release the ENTER

button.

5. Press the ENTER button again.

6. Press the CHANGE button until the number you desire

appears in the first position, then press the ENTER button.

7. Press the CHANGE button until the number you desire

appears in the second position, then press the

ENTER button.

8. Press the CHANGE button until the number you desire

appears in the third position, then press the

ENTER button.

9. Press the CHANGE button until the number you desire

appears in the fourth position, then press the

ENTER button.

10. When the display flashes all four numbers, press the

ENTER button.

5. Setting the Year, Month and Date

1. When the display flashes PPdA E, press the ENTER button.

2. Press the CHANGE button until the correct year appears,

then press the ENTER button.

3. Press the CHANGE button until the correct month appears,

then press the ENTER button.

4. Press the CHANGE button until the correct date appears,

then press the ENTER button.

5. When the display flashes the correct year, month and date,

press the ENTER button.

6. When the display flashes PPdA E, press the CHANGE

button to move to Setting the Time.

Pro9

6 0

0 0

6 5

0 0

6 5

7 0

6 5

7 0

Page 6

PPll

d A

9955

0 l

9999

0 l

9999

040l

9999

04l8

PPll

d A

Page 7

6. Setting the Time

Note: Use 24 hour and 60 minute format when setting the time.

For example: 2:00 pm = 14:00.

1. When the display flashes PP22Clock, press the ENTER button.

2. Press the CHANGE button to choose 12 hour AM/PM

display or 24 hour military time, then press the

ENTER button.

3. Press the CHANGE button until the correct hour appears,

then press the ENTER button.

4. Press the CHANGE button until the correct minutes

appear, then press the ENTER button.

5. When the display flashes the correct time, press the

ENTER button.

6. When the display flashes PP22CLoc, press the

CHANGE button to move to the beginning of the Daylight

Saving Setting.

7. The Beginning of the Daylight Saving Setting

Note: The PIX-21 will automatically adjust for Daylight Saving Time.

This will take effect on the first Sunday in April and on the last Sunday in

October. To disable Daylight Saving Time, set the beginning date equal to

the ending date.

1. When the display flashes PP33bdL , press the

ENTER button.

2. Press the CHANGE button until the correct year appears,

then press the ENTER button.

3. Press the CHANGE button until the correct month appears,

then press the ENTER button.

4. Press the CHANGE button until the correct date appears,

then press the ENTER button.

5. When the display flashes the correct year, month and date,

press the ENTER button.

6. When the display flashes PP33bdL , press the CHANGE

button to move to the end of the Daylight Saving Setting.

PP22

CLoc

2244

l 2

:00

2244

l2:00

2244

l2:00

2244

l2:00

PP22

CLoc

PP33

bdL

9900

040l

9999

040l

9999

040l

9999

0402

PP33

bdL__

Page 8

8. The End of the Daylight Saving Setting

1. When the display flashes PP44EdL , press the

ENTER button.

2. Press the CHANGE button until the correct year appears,

then press the ENTER button.

3. Press the CHANGE button until the correct month appears,

then press the ENTER button.

4. Press the CHANGE button until the correct date appears,

then press the ENTER button.

5. When the display flashes the correct year, month and date,

press the ENTER button.

6. When the display flashes PP44EdL , press the CHANGE

button to move to the end of the Program.

Note: To disable the Daylight Saving Setting, set the beginning and

ending date to the same date.

9. Exit Program Mode

1. When the display flashes End, press the ENTER button to

exit the program mode.

PP44

EdL__

9900

l028

9999

l028

9999

l028

9999

l029

PP44

EdL__

End

Andere Handbücher für PIX-21

Inhaltsverzeichnis

Andere Amano Uhr Handbücher

Amano

Amano EX-3500 Bedienungsanleitung

Amano

Amano BX6000 Bedienungsanleitung

Amano

Amano EX3500N Bedienungsanleitung

Amano

Amano PIX-10 Bedienungsanleitung

Amano

Amano NS 5000 Series Bedienungsanleitung

Amano

Amano PIX-3000x Series Bedienungsanleitung

Amano

Amano PIX-21 Bedienungsanleitung

Amano

Amano PIX-3000x Series Bedienungsanleitung

Amano

Amano EX9000 series Bedienungsanleitung

Amano

Amano EX9000 series Bedienungsanleitung

Amano

Amano PIX-10 Bedienungsanleitung

Amano

Amano MICRODER MR-7000 Series Bedienungsanleitung

Amano

Amano MJR-8500 SERIES Bedienungsanleitung

Amano

Amano PIX-3000x Series Leitfaden

Amano

Amano 4700 Series Bedienungsanleitung

Amano

Amano PIX-10 Bedienungsanleitung

Amano

Amano TS-3000i Bedienungsanleitung

Amano

Amano PIX-55 Bedienungsanleitung

Amano

Amano TCX-22 Bedienungsanleitung

Amano

Amano TCX-85 Bedienungsanleitung

Amano

Amano EX3000N Bedienungsanleitung

Amano

Amano Time Partner TCX-11 Bedienungsanleitung

Amano

Amano MJR-8000 Series Fehlerbehebungshandbuch

Amano

Amano EX7500 series Bedienungsanleitung

Beliebte Uhr Handbücher anderer Marken

Silicon Laboratories

Silicon Laboratories SI5324 Bedienungsanleitung

Heathkit

Heathkit GC-1005 Bedienungsanleitung

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Bedienungsanleitung

Andrew O'Malley

Andrew O'Malley DOTKLOK Bedienungsanleitung

ALGE-Timing

ALGE-Timing ASC3 Bedienungsanleitung

Bodet

Bodet Profil 960 Bedienungsanleitung

Nixie Clock

Nixie Clock Divergence Meter Bedienungsanleitung

La Crosse Technology

La Crosse Technology WS-8256-AL Bedienungsanleitung

Mini Gadgets

Mini Gadgets MCPro Bedienungsanleitung

Casio

Casio TMR-200 Bedienungsanleitung

Progetti

Progetti ILTEMPOSTRINGE Handbuch

BVItech

BVItech BV-101 Bedienungsanleitung

Progetti

Progetti KALIMERO Handbuch

La Crosse Technology

La Crosse Technology WT-3141b Handbuch

La Crosse Technology

La Crosse Technology W86531 Bedienungsanleitung

Sharp

Sharp SPC900 Bedienungsanleitung

La Crosse Technology

La Crosse Technology 404-50447 Bedienungsanleitung

Datexx

Datexx DF0063 Bedienungsanleitung
