American Dynamics 61
IP Video Encoders
IP Encoders allow you to
transform analog video into high
quality IP video streams.
American Dynamics 62
IP ENCODERS COMPARISON TABLE
8-Channel 4-Channel
Number of channels Eight composite video inputs Four composite video inputs
Resolution D1, 2CIF, CIF
Via Intellex IP:
704 x 480, 704 x 240, 352 x 240
Via Browser:
See list above; also
640 x 480, 640 x 240, 320 x 240
Compression (Model) H.264 (ADEIP8H)
MPEG-4, MJPEG (ADEIP8M) Active Content Compression (ACC)
Frame Rate 1-30 ips on each channel + dual encode 4CIF NTSC up to 30 ips per channel
Connector type Eight BNC Four BNC
Network Interface Ethernet 10/100/1000 Base-T Ethernet 10/100 Base-T
Supported Recording Devices VideoEdge NVR, Intellex IP, HDVR HTTP, TCP, DHCP, (client)
Supported Protocols RTP, RTSP, HTTP, UDP, TCP/IP HTTP, TCP, DHCP (client)
Supported Camera Protocols
American Dynamics RS422
BBV Star Card
Cyberscan1
Pelco D
Pelco P
Phillips TC7560
RS422 Dome
American Dynamics
Pelco P
Pelco D,
Bosch,
BBV Star Card
Dimensions 141 x 439.5 x 43.6 mm
(5.55 x 17.3 x 1.71 in)
221 x 113 x 43 mm
(8.7 x 4.4 x 1.7 in)
Weight 2.4 kg (5.3 lbs) 0.6 kg (1.3 lb)
Operating Temperature 0°C - 50°C (32°F -122°F) 0° to 50°C (32° to 122°F)
Certifications UL, FCC, CE
USA: FCC part 15 Class A
Canada: ICES-003/NMB-003 Class A
Europe: EN55022 Class A, EN50130-4
Australia/New Zealand: AS/NZS CISPR22
UL: UL60950-1, CSA C22.2 No. 60950-1
TUVGS: EN60950-1
CB: IEC60950-1
62
Encoders
American Dynamics 63
Preserve your investment in
Sensornet with our add-on
USB module.
8-Channel:
t Video streaming over IP network
t Supports two-way audio to enable
audio streaming applications
t Easy-to-use built-in web interface
lets you control all aspects of video
encoding
t A wide range of PTZ camera
protocols is supported and an
open API is included for application
integration and future support of
other formats
t 8 analog video sources
t 1U 19 in rack mount
t H.264 and MPEG-4/MJPEG models
available
t 30 ips on every channel at D1
t Dual streaming
t Built-in de-interlacing
t Gigabit Ethernet
t 8 audio in/out
t RS232 + RS422/485 for PTZ control
t Compatible with VideoEdge NVR
MODEL NUMBERS
ADEIP8M
MPEG-4, MJPEG
ADEIP8H-US
H.264
SNETH-US
Add on USB module to enable
Sensornet (for ADEIPH only)
IP Encoders
American Dynamics 64
Preserving Your Camera
Investment
Keep your analog cameras as you
migrate to an IP solution. Easily
transform analog video into high quality
IP video streams.
4-Channel:
t Developed to leverage Active
Content Compression (ACC)
technology
t Power over Ethernet
t Manage network bandwidth
usage through individual stream
configuration
t Compatible with Intellex IP and the
Intellex Management Suite (Network
Client, Intellex Policy Manager,
Intellex Archive Manager, and
Browser Client)
t 30 ips NTSC/25 ips PAL at 4CIF
t Access and control the IP encoder
from a web browser or Intellex IP
user interface
t Watchdog system monitoring with
auto-reset
t Video loss detection
t Camera PTZ, focus, aperture
adjustment, preset, and pattern
controls for selected cameras
t Text stream input
t Multi-level password protected user
access
t 10Base-T/100Base-TX network
support
t 1U form factor for shelf, wall, or rack
mounting
MODEL NUMBERS
ADEIP4
4-Channel IP encoder
ADEIP4PS
4-Channel IP encoder with power supply
Accessories
ADEIP4RM
Rack mount kit
ADEIP4WM
Wall mount kit
ADEIP4PWRS
12V DC Power supply kit
ADEIP4RS232
RS-232 Cable Adapter
IP Encoders
