Freestanding cooker 500 and 600 / Range 2013

Gas - electric

Ceramic - electric

Electric

SERVICE MANUAL

2

Manual developed by:

R. Stołowski

E. Banach

R. Bedoński

Address your questions to:

[email protected]

3

Contents

1. Product identication 4

2. Door assembly 5

3. Oven chamber seal 8

4. Knob assembly (gas cooker) 9

5. Oven shelves 10

6. Hob (gas cooker) 11

7. Thermocouple (gas cooker) 13

8. Front panel assembly 14

9. Programmer 15

10. Control panel buttons 16

11. Igniter connector assembly (gas cooker) 17

12. Temperature regulator assembly and function switch 18

13. Rotisserie motor assembly 19

14. Convection fan assembly 20

15. Bottom heater 21

16. Convection fan heater 22

17. Top heater 23

18. Front wall 24

19. Fittings 25

20. Hob assembly (ceramic hob cooker) 27

21. Energy metering device (ceramic hob cooker) 29

22. Hob assembly (electric cooker) 30

23. Cam connector of the hot plate 31

4

Product identication

Location of nameplate

All the necessary information about the product can be found on the nameplate. The

nameplate of the freestanding cooker is located on the back wall.

The serial number

The appliance serial number is printed on the nameplate. The serial number is nec-

essary to match the correct spare parts for the product.

Decoding the serial number.

An example of the serial number: 99991111136513

9999 - serial number in the batch of the product

11111 - Product Code (a unique number for each type of appliance)

365 - day of production

13 - year of production

5

Door assembly

Removing the door assembly

1. Lift the lock of the left and right door hinge.

2. Position the door at an angle of 45° relative to the front of the appliance, lift and

pull out toward yourself.

3. Place the door on a at surface with the handle facing downward. Using a at

screwdriver, pry the cap of the prole on one side to remove it.

6

4. Pull out the inner glass panel and carefully lift it. Do the same with the middle

glass panel(s).

Door assembly

5. Remove the screw that fastens the hinge to the inner glass prole. Pull the hinge

out of the prole.

6. Use the screwdriver to pry and remove the glass panel bracket.

Refer to the Annex to the SBI_001 service manual.

7

Door assembly

7. Remove the door handle by undoing the screws.

8. To reassemble the components follow the above steps in reverse order.

8

Oven chamber seal

Dismantling the oven chamber seal

1. Unhook the seal holders from the front wall in four places (in the corners).

2. To reassemble the components follow the above steps in reverse order.

The seal should be mounted

with the joint facing down.

9

Knob assembly (gas cooker)

1. Pry the knob's interior part, squeeze both parts together and pull toward your-

self.

2. To reassemble the components follow the above steps in reverse order. Impor-

tant! There is a spring between the two elements.

10

Oven shelves

Dismantling the shelf supports

1. Remove the runners from the shelf supports, unhook the shelf supports from the

mounting holes.

2. To reassemble the components follow the above steps in reverse order.
