AMX Color Active-Matrix LCD Bedienungsanleitung

Color Active-Matrix LCD Mini-Touch Panels

(Firmware version G2 or lower)

Instruction Manual

t a k e c o n t r o l

Limited Warranty and Disclaimer

AMX Corporation warrants its products to be free from defects in material and

workmanship under normal use for a period of three years from date of purchase

from AMX, with the following exceptions. Electroluminescent and LCD control

panels are warranted for a period of three years, except for the display and touch

overlay components, which are warranted for a period of one year. Disk drive

mechanisms, pan/tilt heads, codecs, power supplies, modifications, MX Series

products, and KC Series products are warranted for a period of one year. Unless

otherwise specified, OEM and custom products are covered for a period of one year.

AMX software products are warranted for a period of 90 days. Batteries and

incandescent lamps are not covered.

This warranty extends to products purchased directly from AMX or an authorized

AMX dealer. Consumers should inquire from selling dealer as to the nature and

extent of the dealer’s warranty, if any.

AMX is not liable for any damages caused by its products or for the failure of its

products to perform, including any lost profits, lost savings, incidental damages, or

consequential damages. AMX is not liable for any claim made by a third party or

made by you for a third party.

This limitation of liability applies whether damages are sought, or a claim is made,

under this warranty or as a tort claim (including negligence and strict product

liability), a contract claim, or any other claim. This limitation of liability cannot be

waived or amended by any person. This limitation of liability will be effective even

if AMX or an authorized representative of AMX has been advised of the possibility

of any such damages. This limitation of liability, however, will not apply to claims

for personal injury.

Some states do not allow a limitation of how long an implied warranty lasts. Some

states do not allow the limitation or exclusion of incidental or consequential

damages for consumer products. In such states, the limitation or exclusion of the

Limited Warranty may not apply to you. This Limited Warranty gives you specific

legal rights. You may also have other rights that may vary from state to state. You

are advised to consult applicable state laws for full determination of your rights.

EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX MAKES NO OTHER WARRANTIES,

EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE. AMX EXPRESSLY DISCLAIMS ALL WARRANTIES NOT

STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY

LAW ARE LIMITED TO THE TERMS OF THIS LIMITED WARRANTY.

Color Active-Matrix LCD Mini-Touch Panels Table of Contents i

Table of Contents

Introduction ............................................................................ 1

Overview 1

Features 2

Applications 2

What's in this Manual 3

Installing Mini-Touch Panels ................................................. 5

Overview 5

Mounting the Mini-Touch Panels 5

AXU-MCA (/PB), AXU-MCV (/PB),

and low profile back box 5

AXU-MCA (/PB), AXU-MCV (/PB),

and BB-MTP UniMount enclosure

(solid surfaces) 7

AXU-MCA (/PB), AXU-MCV (/PB), and

BB-MTP UniMount enclosure

(plasterboard) 9

AXM-MCA (/PB) or AXM-MCV (/PB)

(rack mount) 11

Wiring the Mini-Touch Panels 12

Preparing captive wires 13

Wiring guidelines 13

Using the TiltScreen mini-XLR connector

for AXlink data and power 14

Using the TiltScreen mini-XLR connector

for AXlink and an external 12 VDC

power supply 14

Using the UniMount and rack-mount

AXlink connector for data and power 15

Using the UniMount and rack-mount

AXlink connector for data and an

external 12 VDC power supply 15

Using the UniMount and rack-mount

4-pin header for mouse control 16

Cleaning the Touch Overlay 17

ii Table of Contents Color Active-Matrix LCD Mini-Touch Panels

Mini-Touch Panel Basics ..................................................... 19

Overview 19

Mini-Touch Panel Pages 19

Standard Buttons 20

General Buttons 20

Message bar 20

Editor bar 21

Selection button 21

Information button 21

Adjustment button 22

Keypad buttons 22

Page menu buttons 23

Decision buttons 23

Status buttons 24

Keyboards 24

Designing a Mini-Touch Panel Page ................................... 29

Overview 29

Activate the Editor Bar 29

Create a Page 31

Add a page 31

Go to NEW PAGE 33

Create a Button 34

Add a button 34

Resize the button 35

Button Attributes 36

Set the button attributes 36

Set the border 37

Set the channel code 38

Set the page flip 38

Add Text 39

Add text to a button 39

Create a Joy Stick 40

Add a joy stick on a page 40

Set the joy stick attributes 41

Set the level code 42

Create a Bargraph 43

Add a bargraph to a page 43

Set the bargraph attributes 44

Set the level code 45

Set the Video Display 45

Color Active-Matrix LCD Mini-Touch Panels Table of Contents iii

Link the New Page to the Main Page 47

Close the Editor Bar 49

Exit editor mode 49

Mini-Touch Panel Program Reference................................. 51

Overview 51

Setup Page 51

Open the Setup Page 52

Buttons 52

Beep 52

LCD timer 53

Serial number, AXlink, and vX.XX 53

SmartPack 54

WAVE 55

Set time and date 57

Double beep 58

Protected setup 58

Set background 59

Brightness 60

Protected Setup Page 61

Open the Protected Setup Page 61

Protected Setup Page Buttons 62

Editor 62

Setup password 63

Auto assign 63

Set serial 64

Set device 66

Page password 67

Power up page 67

Calibrate 68

Page tracking 68

LCD timer message 69

Timer BRT 72

Editor Bar 72

Button Menu Options 73

Add 74

Move 74

Copy image 74

Delete 75

Resize 75

Edit text 76

iv Table of Contents Color Active-Matrix LCD Mini-Touch Panels

Attributes 79

Save 83

Paste 83

Page Menu Options 83

Add 84

Copy 85

Rename 86

Delete 87

Go to 87

Passwd pg flip 88

Print 89

Page color 90

Icons Menu Options 90

Time 91

Date 91

E timer 91

16 char term 92

32 char term 92

Vertical graph 92

Icon feedback 95

Joy stick 97

Drawings 100

Brightness 100

Video Setup 101

System Menu Options 102

Clear buttons 103

Clear drawings 103

Memory 104

Send file 105

Receive file 106

Move edit bar 107

Print 107

Function map 108

Function show 109

Set Defaults 110

Color Active-Matrix LCD Mini-Touch Panels Table of Contents v

AXCESS Programming....................................................... 113

Overview 113

System Send_Commands 113

Color Numbers 119

Color Send_Commands 119

Variable Text Send_Commands 122

WavePack Button Attribute String_Commands124

Replacing the Lithium Batteries ........................................ 125

Overview 125

AXT-MCA (/PB) and AXT-MCV (/PB) 125

AXU-MCA (/PB), AXU-MCV (/PB),

AXM-MCA (/PB), and AXM-MCV (/PB) 127

512K Memory Upgrade ...................................................... 129

Operation 129

AXT-MCA (/PB) and AXT-MCV (/PB) 129

AXU-MCA (/PB), AXU-MCV (/PB),

AXM-MCA (/PB), and AXM-MCV (/PB) 130

Color Guidelines................................................................. 133

Overview 133

Colors 133

Specifications..................................................................... 135

Overview 135

AXT-MCA (/PB) and AXT-MCV (/PB) 135

AXU-MCA (/PB) and AXU-MCV (/PB) 136

AXM-MCA (/PB) and AXM-MCV (/PB) 137

Technical Support .............................................................. 139

Overview 139

Index.................................................................................... 141

Overview 141

vi Table of Contents Color Active-Matrix LCD Mini-Touch Panels

Color Active-Matrix LCD Mini-Touch Panels Introduction 1

Introduction

Overview

The color active-matrix mini-touch panels contain a dedicated 256-color, 320 x 240

(HV) pixel, liquid crystal display (LCD). The mini-touch panels are self-contained

enclosures that use a microprocessor to control a wide range of audiovisual

products. Special mini-touch panel options include a video input port that is PAL-

and NTSC-compatible, and 12 pushbuttons (6 pushbuttons on each side) that can be

programmed to perform specific control operations. With the mini-touch panel

operating system, you can create custom pages with buttons, icons, sliders,

bargraphs, and imported logos and drawings. You can also use the TPDOC or

TPDesign custom touch panel design programs AMX offers to enhance your mini-

touch panel designs. Figure 1shows an AXU-MCA UniMount mini-touch panel.

Figure 2lists the mini-touch panel types and product names described in this

manual.

Color mini-touch panel types and product names

Non-Video Panels Video Panels

Panel types Standard Pushbuttons Standard Pushbuttons

TiltScreen AXT-MCA AXT-MCA/PB AXT-MCV AXT-MCV/PB

UniMount AXU-MCA AXU-MCA/PB AXU-MCV AXU-MCV/PB

Rack mount AXM-MCA AXM-MCA/PB AXM-MCV AXM-MCV/PB

Figure 1

AXU-MCA UniMount mini-

touch panel

Figure 2

Color mini-touch panel types

and product names

2Introduction Color Active-Matrix LCD Mini-Touch Panels

Features

Mini-touch panel features include:

• 5" diagonal display—2.8" x 3.9" (71 mm x 97 mm)

• 256-color active matrix 320 x 240 (HV) pixel LCD

• 12 programmable pushbuttons (6 on each side)

• Microsoft or Logitech mouse compatible (UniMount and rack-mount models

only)

• Panel programming, screens, and drawings that can be uploaded and

downloaded with TPDOC (MS-DOS) or TPDesign (Windows) touch panel

software programs.

• PAL- and NTSC-compatible video input port (optional)

• Internal 4-pin header for mouse control (UniMount and rack-mount models

only)

Applications

The mini-touch panels can control a wide variety of equipment connected to an

AXCESS Control System, serial mouse, or a combination of both. Figure 3 shows

how you can use the AXU-MCA control capabilities with an AXCESS Control

System. The mouse shown in Figure 3is optional.

AXU-MCA Mouse (optional)

port

AXlink cable

AXCESS CardFrame

Television VCR

Lighting

Camera

Figure 3

Sample AXU-MCA and

AXCESS Control System

Note

The mouse can be used to

design mini-touch panel pages

and then removed prior to

installation.

Andere Handbücher für Color Active-Matrix LCD

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere AMX Touchscreen Handbücher

AMX

AMX Modero NXD-1700VG Bedienungsanleitung

AMX

AMX Modero X Series Bedienungsanleitung

AMX

AMX Modero ViewPoint MVP-8400i Bedienungsanleitung

AMX

AMX Modero ViewPoint MVP-5150 Bedienungsanleitung

AMX

AMX MVP-9000i-GB Bedienungsanleitung

AMX

AMX AXM-CP Leitfaden

AMX

AMX Electroluminescent LCD Touch Panels Bedienungsanleitung

AMX

AMX Wireless Touch Panels (Wave Server) Bedienungsanleitung

AMX

AMX NXD-435 Bedienungsanleitung

AMX

AMX AXM-MCV Leitfaden

AMX

AMX AXD-CP4/A Bedienungsanleitung

AMX

AMX Modero NXD-1000Vi Stücklistenhandbuch

AMX

AMX Modero NXD-1200V Stücklistenhandbuch

AMX

AMX Modero NXT-1200V Stücklistenhandbuch

AMX

AMX Modero G4 Bedienungsanleitung

AMX

AMX Modero NXD-CV7 Bedienungsanleitung

AMX

AMX Modero NXD-500i Bedienungsanleitung

AMX

AMX Modero ViewPoint MVP-7500 Stücklistenhandbuch

AMX

AMX MXD-701 Bedienungsanleitung

AMX

AMX MVP-9000i Bedienungsanleitung

AMX

AMX AXD-MCV Leitfaden

AMX

AMX Modero NXD-CV7 Bedienungsanleitung

AMX

AMX AXU-CA10 Leitfaden

AMX

AMX AXU-EL Plus Leitfaden

Beliebte Touchscreen Handbücher anderer Marken

FlowLine

FlowLine Data loop Bedienungsanleitung

ALPEX

ALPEX AEx-8 P Series Bedienungsanleitung

Ltech

Ltech E5S Bedienungsanleitung

Harman

Harman AMX MODERO S MSD-701-L2 Bedienungsanleitung

Acnodes

Acnodes PC 1150 Bedienungsanleitung

AIS

AIS IP10IA99 series Bedienungsanleitung

IBASE Technology

IBASE Technology ASTUT-152-RE1S Bedienungsanleitung

YASKAWA

YASKAWA TP 610C Bedienungsanleitung

B&R

B&R Power Panel C Series Bedienungsanleitung

Beijer Electronics

Beijer Electronics X2 control Bedienungsanleitung

AXIOMTEK

AXIOMTEK GOT321W-521 Bedienungsanleitung

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Bedienungsanleitung

Qomo

Qomo QIT1386 Bedienungsanleitung

DFI

DFI KS104-CD Bedienungsanleitung

Sartorius

Sartorius X3 PR 5410 Bedienungsanleitung

Advantech

Advantech TPC-30 Series Bedienungsanleitung

B&R Industries

B&R Industries MAPPC900-ENG Bedienungsanleitung

FEC

FEC PP-9635 Bedienungsanleitung
