AN -1000X Speaker Monitor

Portable Speaker Monitor Speciﬁcations

Advancing Technology

The AN-1000X is the most versatile powered monitor on the market. You can add it to an A/V

rack setup, use it as a studio monitor, install it in a trade show booth, or place it in the Captain’s

quarters on a US Navy warship to monitor activities in the intelligence room. Just imagine . . .

Anchor Audio, Inc. 888/444-6077

Portable Sound Systems • Torrance, California www.anchoraudio.com

S-ANX/0407

AN-1000X FEATURES

6-YEAR WARRANTY!

REACH CROWDS OF 400+

103 DB OF CLEAR SOUND

BASS & TREBLE CONTROLS

50 WATT SOUND SYSTEM W/

RESPONSE FROM 65HZ - 20KHZ

RCA & 1/4” LINE INPUTS

MIC/LINE CONFIGURABLE XLR INPUT

MAGNETICALLY SHIELDED SPEAKER

220 VOLT CE-COMPLIANT MODEL

DURABLE INJECTION-MOLDED CASE

2-WAY SPEAKER SYSTEM COMBINES

4.5” WOOFER & DOME TWEETER

SPEAKER OUTPUT DRIVES

COMPANION SPEAKER

MADE IN THE USA!

AN-1000X ACCESSORIES

AN-1001X Unpowered companion speaker

MIC-90 Professional dynamic, cardioid

pattern handheld microphone

SC-50 50’ Speaker cable

CC-100 Speaker/accessory bag

CC-100XL Speaker/accessory bag – large

HC-1550 Custom traveling hard case

CC-550 Speaker stand/accessory bag

SS-250 Speaker stand

MSB-201 Mic stand w/ boom

SB-1 Stand mount

SB-3 Ceiling mount bracket*

SB-360 360° swivel wall bracket*

* Available w/ black or white finish

(FEATURES & SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)

AN-1000X TECHNICAL SPECIFICATIONS

Rated Power Output 50 watts continuous @ 4 ohm

Max SPL @ Rated Power 103 dB @ 1 meter

Frequency Response 65 Hz – 20 kHz ± 3 dB

AC Power Reqs. 110 – 125Vac, 50/60 Hz, 90W Max

208 – 240Vac, 50/60 Hz, 90W Max

Dimensions (HWD) 5.25 x 8.4 x 9” / 13 x 21 x 23 cm

Weight 9.5 pounds / 4.3 Kg

Inputs

Balanced mic / line configurable, female

XLR, switchable phantom power

Line Hi-Z, unbalanced, 1/4”-phone & RCA

Outputs

Line Lo-Z, RCA, buffer isolated line-level

Speaker 8 ohm, unswitched, 1/4”-phone

AN-1000X MODELS

AN-1000X Powered monitor speaker

AN-1001X/70 Internal 70 volt transformer

AN-1000X DAISY-CHAIN

DAISY-CHAIN READY • CONNECT MULTIPLE SYSTEMS

SIMPLE LINE-OUT TO LINE-IN CONNECTION EXPANDS COVERAGE.

(AN-1000X Back Panel Shown)
