Apollo TE-210A Bedienungsanleitung
2
SELECT OPTION:
2. Enter New Time
3. View Last Message
4. Range Test Mode
5. Edit Alarm Message
6. View Alarm Status
7. Edit PPG Message
8. Clear All Data
9. Protocol Type Sel.
0. Frequency Setting
A. HeartBeat Setup
B. Factory Setup
1. Edit Pagers
2.1. The Administration Menu:
Press ↑ or ↓ to move cursor up or down . Press ENTER to into the item
2.2. Edit Pagers
PAGER TO EDIT:210 █
Enter Pager No#
Pager no #
210 ▼
×
× PAGER TYPE A
× BAUD RATE 1200
× FUNCTION BIT 0
× NAME
× PAGER GROUP
× DELETE
× SAVE & EXIT
CAPCODE
2.2.1. Edit Pagers menu
2. Press ESC to advance to the Administration Menu
Enter Password
Enter Password
█
****
ENTER default password “ 1234 ”
2.1.1.6. PAGER GROUP
2.1.1.7. DELETE
2.1.1.8. SAVE & EXIT
2.2. Enter New Time
2.3. View Last Message
2.4. Range Test Mode
ENTER PAGER GROUP:
█
Range = 00 ~ 99
SET TIME
:00PM12
LAST MESSAGE: 210
This is the Message
Body!
RANGE TEST MODE
MSG: RANGE TEST 001
PAGER ID: 100
PAGING COUNT DOWN: 10
PageTo Number
Last Message
Body
Message Content
Page to #100
Sending counter
4
2.5. Edit Alarm Message
2.5.1. Edit
PageTo no#
Press ENTER to Edit Alarm Message
2.6. View Alarm Status
2.7. Edit PreProgramming Msg
“1” is active; “0” is no active
Press ENTER to Edit PreProgramming Msg ,
There are 99 PPG available .
ALARM MESSAGE: 1
[101] Contact 1!
ALARM MESSAGE:
Input Message
Input PageTo
ALARM STATUS:
10101000
PPGM MESSAGE: 01
No 1. Ppg Message!
Alarm Input no#
Message Body
PPGM no#
Message Body
Press ENTER when done
PPGM MESSAGE: 01
No 1. Ppg Message!
2.7.1. Edit
5
RESET DATABASE
ARE YOU SURE?
Protocol Selection
Type: Programming
Speed: 19200
Mode: 8 , n , 1
Press ENTER to link to computer .
2.9. Protocol Type Selection
Operation
Disconnection
Press any key
TO Continue…
Frequency Setting
00Hz4545000
If “YES” , by Pressing ENTER
If “NO” , by Pressing ESC
Press any key to disconnect to computer
2.0. Frequency Setting
PS:
1. Have to select Protocol type in “Factory setting” .
2. You can select to
1. GATAP , 2. Ipage2 , 3. WaveWare , 4. Programming , 5. GACOMP2 ,
6. POCSAG TEXT , 7. POCSAG NUMERIC , 8. COMP2 , 9. COMP1 ,
10. SCOPE
2.8. Clear All Data
6
8
