Arec CI-T25H Bedienungsanleitung
CI-T25H
PTZ Tracking Camera 5X
User Manual English
AREC Inc.© All Rights Reserved 2020. l www.arec.com
All information contained in this document is Proprietary
CI-T25H User Manual
2
This manual introduces the function installation and operation of the Camera.
Prior to installation and usage, please read the manual thoroughly.
1. Warning
(1) This product can be only used in specied range in order to avoid any damage or danger;
(2) Don’t expose the camera to rain or moisture place
(3) Don’t remove the cover to reduce the risk of electric shock. Refer servicing to qualied
personnel.
(4) Never operate the camera under unqualied temperature , humidity and power supply;
(5) Please use the soft cloth to clean the camera. Use neuter cleanser if bad smeared .Don’t
use the strong or cleanser avoiding scufng.
2. Electric Safety
Installation and operation must accord with electric safety standard.
3. Caution to transport
Avoid stress,vibration and soakage in transport,storage and installation.
4. Polarity of power supply
This product uses DC 12V power supply.
5. Careful of installation
(1) This series item must put on the smooth desk or platform,and it can not be installed
slant ways.
(2) Don’t apply in corrosive liquid,gas or solid environment to avoid the cover which is made
up of organic material.
(3) This product has a heating device inside, please keep ventilated.
(4) Never power on before installation is completed.
6. Don’t disassemble discretionarily
We are not responsible for any unauthorized modication or dismantling.
7. Attention
Electromagnetic led under certain rate may affect camera image!
Preface
CI-T25H User Manual
Table of Contents
Preface
Product overview
Quick Installation Instructions
Connection and Settings
Chapter 1 Applications
1.1 Setup Tracking Parameter
1.2 RS-232 Interface
1.2.1 RS-232C interface specication as shown below
1.2.2 RS-232 Mini-DIN 8-pin Port Denition
1.2.3 RS232 (DB9) Port Denition
1.2.4 VISCA networking as shown below
1.3 Serial Communication Control
1.3.1 VISCA protocol list
1.3.2 Pelco-D protocol command list
1.3.3 Pelco-P protocol command list
Chapter 2. Remote Controller
2.1 Keys Instruction
2.2 Menu Setting
2.2.1 Main Menu
2.2.2 System Setting
2.2.3 Camera Setting
2.2.4 P/T/Z
2.2.5 Video Format
2.2.6 Version
2.2.7 Restore Default
Chapter 3. Network Connection
3.1 Direct connection
3.2 Internet connection mode
Chapter 4. Overview of the Web Interface
4.1 Preview
4.2 Playback
4.3 Conguration
4.3.1 Local congure
4.3.2 Audio congure
4.3.3 Video congure
4.3.3.1 Video encode
4.3.3.2 Stream publish
4.3.3.3 Video parameters
4.3.3.4 Video OSD
4.3.3.5 OSD font size
4.3.3.6 Video out
4.3.4 Network Congure
4.3.4.1 Network port
4.3.4.2 Ethernet parameters
4.3.4.3 DNS
02
05
09
12
14
14
20
20
20
20
21
22
22
28
28
30
30
32
32
32
32
35
35
35
36
37
37
39
40
41
42
43
44
45
46
47
48
49
53
54
54
55
56
57
58
CI-T25H User Manual
4.3.4.4 GB28181
4.3.5 System congure
4.3.5.1 System attribute
4.3.5.2 System time
4.3.5.3 User set
4.3.5.4 Release upgrade
4.3.5.5 Restore factory defaults
4.3.5.6 Reboot
4.4 Logout
Chapter 5. Camera Maintenance and Troubleshooting
5.1 Camera Maintenance
5.2 Troubleshooting
Table of Contents
59
60
61
62
64
65
65
65
65
66
66
66
CI-T25H User Manual
5
CI-T25H Auto-Tracking PTZ Camera is a professional-grade high quality PTZ camera that also can track a moving
presenter automatically while shooting video. Combining a high-performance pan/tilt/zoom camera, compact design
and excellent motion-sensitive tracking technology, CI-T25H is ideal for mid to large-size conference, huddle rooms, or
lecture capture, bridging the feature and price gap between current webcam and professional PTZ cameras in the market.
Product Overview
1. Dimension
95.00 116.00
151.64
128.89
180
131.25
118.74
14.00
CI-T25H User Manual
6
2. Accessory
No. CI-T25H
1Power Adaptor
2RS-232 Cable
3USB3.0 Cable
4Remote Controller
5AM-600 (include USB Cable & QIG)
6X type 2 in 1 Tracking Cable (RS-232 & Power)
73.5mm phone jack to USB Cable
(PC Cong Tool setting cable)
8Quick Installation Guide
The camera offers perfect functions, superior performance and versatile interfaces. The features include advanced ISP
processing algorithms to provide vivid images with a strong sense of depth, high resolution and fantastic color rendition.
It supports H.264/H.265 encoding which makes motion video fluent and clear even with less than ideal bandwidth
conditions. By adopting high accuracy step driving motor mechanism, it works extremely quiet and moves smoothly and
very quickly to designated position. Product works stable and reliable, and it is easy to use, installation and maintenance.
3. Camera performance
CI-T25H User Manual
7
4. Technical specication
Camera Parameter
Optical Zoom 5X, f=3.1~15.5mm
Sensor 1/2.8 inch high quality HD CMOS sensor
Effective Pixels 16: 9 2.07 megapixel
Video Format
HDMI video format
1080P60/50/30/25/59.94/29.97;1080I60/50/59.94;
720P60/50/30/25/59.94/29.97
U3 video format
(1) U3:1920X1080P60/50/30/25;1280X720P60/50/30/25;960X540P30;640X360P30;
640X480P30;352X288P30;960X540P30;
(2) U3 compatible with U2: 960X540P30; 640X360P30; 1280X720P10/15;
720X576P50; 720X480P60; 640X480P30; 352X288P30.
View Angle 16.43°(tele)--83.7°(wide)
Iris F1.8--F2.8
Digital Zoom 5X
Minimum Illumination 0.5Lux (F1.8,AGC ON)
DNR 2D & 3D DNR
White Balance Auto / Manual / One Push / 3000K / 3500K / 4000K / 4500K / 5000K /
5500K / 6000K / 6500K / 7000K
Exposure Auto / Manual / Shutter Automatic Exposure / Aperture Automatic Exposure /
Brightness priority
Focus Auto / Manual / One Push
Aperture Auto / Manual
Electronic Shutter Auto / Manual
BLC ON / OFF
WDR OFF / Dynamic level adjustment
Video Adjustment Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
SNR >55dB
Input/Output Interface
Video Interfaces RS232(INPUT), LAN, HDMI, USB3.0
Image Code Stream Dual stream output
Image Output Multiple
Code Source Dual Code Source output(HDMI/ USB3.0 LAN )
Video Compression
Format H.264, H.265
CI-T25H User Manual
8
* Without wall, human body or any large size barrier in between.
** Power saving function: The AM-600 will automatically power off, if it has been placed flat and static for more than 5
minutes.
Audio Output HDMI LAN output together with video
Audio Compression Format AAC MP3 G.711A
HD IP Interface 100M IP port(100BASE-TX)
Network Protocol RTSP/RTMP, ONVIF, GBT28181; Support IP Visca control protocol; Distance update,
Distance restart, Distance reset
Control Interface RS232
Control Protocol VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400 bps
Power Interface HEC3800 outlet (DC12V)
Supply Adapter AC110V-AC220V to DC12V/2A
Input Voltage DC12V±10%
Input Current 2A (Max)
Consumption 24W (Max)
PTZ Parameter
Pan Rotation ±135°
Tilt Rotation -30°~+30°
Pan Control Speed 0.1-60°/sec
Tilt Control Speed 0.1-30°/sec
Preset Speed Pan: 60°/sec, Tilt: 30°/sec
Preset Number 255 presets (10 presets by remote controller)
Tracking Parameter
Tracking Distance* 3~7m
Battery life of AM-600** Approximate continuous operating time: 4 hours
Other Parameter
Store Temperature -10°C ~ +60°C
Store Humidity 20% - 95%
Working Temperature -10°C ~ +50°C
Working Humidity 20% - 80%
Dimension (L x W x H) 131 x 151 x 180 mm
Weight 1.1 kg
Using Environment Indoor
CI-T25H User Manual
9
Quick Installation Instructions
1. Camera interface and indicators description
3
4
1
5
6
2
No. LED Color Glow Rule Operation
2
Red/Green
dual-color
light
Red light blinking Power Adaptor plug to Socket
Green light turns on Power on
Green light blinking Receive remote control signal
6
Red/Green
dual-color
light
Green light flashes 1 sec Power Adaptor plug to Socket
Light goes off Auto tracking ongoing
Red light flashes Auto tracking error
Red/green lights flicker alternately Firmware update or setting of tracking parameters
via PC cong tool
RS232 HDMI DC12V IN
A1
B C D E
A2
Figure 1.1
No. CI-T25H
1Camera Lens
2Remote Controller Receiver
3Tripod Screw Hole (¼ UNC 20, Depth 6.5mm)
4Locating Hole (Ø5.5, Depth 6.5mm)
5Auto-Tracking Receiver
A1 RS232 Control Interface (Output)
A2 RS232 Control Interface (Input)
BLAN Interface
CHDMI Interface
DUSB3.0 Interface
EDC12V Input Power Supply Socket
F3.5mm phone jack (for PC Cong Tool)
F
CI-T25H User Manual
10
(1) Power on: Connect DC12V power supply adapter with power supply socket.
(2) Initial conguration: Power on with power indicator light on and remote control receiver light blinking, camera head
moves from bottom left to the bottom, and then goes to the HOME position (intermediate position of both horizontal
and vertical ),while the camera module stretches. When remote control receiver light stops blinking, the self-checking
is nished.
Note:
1. The default address of the remote controller is the 1# address.
2. If you set preset 0, when Power on self-test is completed, the camera automatically moves to the preset 0 position.
(1) Video Output from LAN
a. Network Cable Connection Port: Connect this product and your computer through network cable, the device LAN
interface refer to No B in Figure 1.1.
b. Webpage Login: Open your browser and enter 192.168.11.202 in the address bar (factory default); press Enter to
enter into the login page; click on the “player is not installed, please download and install!" and follow the
installation steps for installation. Then enter the user name admin and password admin (factory default); press
Enter to enter into the preview page, users can carry out PTZ control, video recording, playback, conguration and
other operations.
( Note: If you forget your user name, password, IP address, you can manually restore the default by the remote
controller key combination * # )
(2) HDMI Video Output
a. HDMI Video Cable Connection: CI-T25H refer to No.C in Figure 1.1.
b. Connect the camera and the monitor via HDMI video cable; video output is available after camera self-test.
(3) USB3.0 video output
a. USB3.0 video cable connection: CI-T25H refer to No.D in Figure 1.1.
b. Connect the camera and the monitor via USB3.0 video cable, open video display software, select image device, and
then video output will be available.
(4) USB3.0 compatible with USB2.0 output
a. USB3.0 video cable connection: CI-T25H refer to No.D in Figure 1.1.
b. Connect the camera and the monitor via USB3.0 video cable, open video display software, select image device, and
then video output will be available.
1.1 Power on initial conguration
1.2 Video output
