Arista C-230E Bedienungsanleitung
Quick Start Guide
C-230E Access Point
Arista Networks
www.arista.com
DOC-04355-03
ii Quick Start Guide: Access Point
© Copyright 2021 Arista Networks, Inc. The information contained herein is subject to change without notice. Arista Networks
and the Arista logo are trademarks of Arista Networks, Inc in the United States and other countries. Other product or service
names may be trademarks or service marks of others.
Headquarters
5453 Great America Parkway
Santa Clara, CA 95054
USA
408 547-5500
www.arista.com
Support
408547-5502
866 476-0000
support-wifi@arista.com
Sales
408 547-5501
866 497-0000
Contents
Contents
1 About This Guide................................................................................ 1
2 Package Content..................................................................................2
3 Access Point Overview.......................................................................4
3.1 Front Panel............................................................................................................................. 4
3.2 Rear Panel..............................................................................................................................5
3.3 Side Panel.............................................................................................................................. 6
4 Install the Access Point......................................................................8
4.1 Ceiling Mount the Access Point............................................................................................. 8
4.2 Wall Mount the Access Point................................................................................................. 9
4.3 Connect External Antennas to C-230E................................................................................ 12
4.4 Connect the Access Point to the Network............................................................................13
4.4.1 Connect the Access Point using PoE.....................................................................14
4.5 Power the Access Point On..................................................................................................14
4.5.1 Using the C-230E with Power Adapter................................................................... 14
5 Access Point Troubleshooting.........................................................15
6 Appendix A: AP-Server Mutual Authentication...............................16
iii
1 About This Guide
1 About This Guide
This installation guide explains how to deploy the C-230 access point (AP).
Important: Please read the EULA before installing the access point (AP). You can download
and read the EULA from https://www.arista.com/en/support/product-documentation.
Installing the AP constitutes your acceptance of the terms and conditions of the EULA
mentioned above.
Intended Audience
This guide can be referred by anyone who wants to install and configure the access point.
Document Overview
This guide contains the following chapters:
•Package Content
•Access Point Overview
•Install the Access Point
•Access Point Troubleshooting
Note: All instances of the term 'server' in this document refer to the Wireless Manager, unless
the server name or type is explicitly stated.
Product and Documentation Updates
To receive important news on product updates, please visit our website at https://www.arista.com/
en/support/product-documentation. We continuously enhance our product documentation based on
customer feedback
This equipment conforms to the requirements of the NCC.
1
2 Package Content
The access point (AP) package must contain the components shown in the following figure.
Figure 1: Package Components
2
2 Package Content
Table 1: Labels: Package Components
Label Description
1 C-230E Access Point
2 15/16" (24 mm) Mounting Bracket (MNT-AP-24MM)
Important: The MAC address of the AP is printed on a label at the bottom of the product and
the packaging box. Note down the MAC address before mounting the AP on the ceiling or at a
location that is difficult to access.
If the package is not complete, please contact the Arista Networks Technical Support Team at support-
3
3 Access Point Overview
C-230E is a tri-radio 802.11ax access point.
This chapter provides an overview of the C-230E access point (AP) and describes:
•Front Panel
•Rear Panel
•Side Panel
3.1 Front Panel
The front panel of the C-230E has 6 LEDs that indicate the status of various device functions.
Figure 2: Front Panel LEDs
Table 2: Labels: Front Panel LEDs
Label Description
1 Power
2 2.4 GHz Radio
3 5 GHz Radio
4 Third Radio
5 LAN1
6 LAN2
4
3 Access Point Overview
Power LED: The following table describes the Power LED states.
Table 3: Power LED States Description
Green Orange
Solid Running at full capability Running at reduced capability
Blinking Received IP address, but not connected to the
server
Did not receive an IP address
Reduced capability indicates that the AP is getting lower than the required maximum power from the
PoE switch, i.e., 802.3af instead of 802.3at.
LAN1 LED: ON when the corresponding interface is up.
LAN2 LED: ON when the corresponding interface is up and either wired guest or link aggregation is
configured.
Radio LEDs: ON when the corresponding radio is operational.
3.2 Rear Panel
The rear panel of the AP has its DC power port and 802.3at compliant PoE LAN ports to power the
device and connect it to a wired LAN.
Figure 3: Rear Panel
Table 4: Labels: Rear Panel
Label Description
1 LAN2
2 LAN1
3 Power
5
Table 5: C-230E Port Details
Port Description Connector Type Speed/Protocol
Power 12V DC 5.5 mm overall
diameter / 2.1 mm
center pinhole
N/A
LAN 1 5 Gigabit Ethernet with
802.3at compliant PoE
RJ-45 100/1000 Mbps / 2.5/5
Gbps Ethernet
LAN 2 1 Gigabit Ethernet with
802.3at compliant PoE
RJ-45 100/1000 Mbps
Ethernet
3.3 Side Panel
The side panel of the C-230E has a reset pin, USB, and console port.
Figure 4: Side Panel
Table 6: Labels: Side Panel
Label Description
1 Reset
2 USB
3 Console
Port Description Connector Type Speed/Protocol
Console Establish ‘config shell’
terminal session via
serial connection
RJ-45 • RS 232 Serial
(115200 bits per
second)
• Data bits:8; Stop
bits: 1
• Parity: None
• Flow Control: None
USB USB 2.0 port USB Future Use
6
3 Access Point Overview
Reset Reset to factory default
settings port. Hold
down and power cycle
the device to reset.
Pinhole push button N/A
When you reset the AP, the following settings are reset:
• Config shell password is reset to config.
• Server discovery value is erased and changed to the default, redirector.online.spectraguard.net
(primary) and wifi-security-server (secondary).
• All the VLAN configurations are lost.
• If a static IP is configured on the AP, the IP address is erased and DHCP mode is set. The factory
default IP address of the AP is 169.254.11.74.
7
