Aruba 175 Series Outdoor Access Points Aruba Data Sheet

The 175 series can be congured to provide part-time or dedicated

air monitoring for spectrum analysis and wireless intrusion protection,

VPN tunnels to extend remote locations to corporate resources, and

wireless mesh connections where Ethernet drops are not available.

CHOOSE YOUR OPERATING MODE

The 175 series of outdoor APs offers a choice of operating modes

to meet your unique management and deployment requirements.

• Controller-managedmode. When managed by Aruba Mobility

Controllers, 175 series APs offer centralized conguration, data

encryption, policy enforcement and network services, as well as

distributed and centralized trafc forwarding. Please refer to the

Aruba Mobility Controller data sheets for more details.

• ArubaInstant™mode. In Aruba Instant mode, a single AP

automatically distributes the network conguration to other

Instant APs in the WLAN. Simply power-up one Instant AP,

congure it over the air, and plug in the other APs – the entire

process takes about ve minutes.

For large installations across multiple sites, the Aruba Activate™

service signicantly reduces deployment time by automating device

provisioning, rmware upgrades, and inventory management. With

Aruba Activate, Instant APs are factory-shipped to any site and

congure themselves when powered up.

If WLAN and network requirements change, a built-in migration

path allows 175 series Instant APs to become part of a WLAN that

is centrally managed by a Mobility Controller.

ADVANCED FEATURES

• Spectrum Analysis:

-Spectrum analyzer remotely scans the 2.4-GHz and 5-GHz

radio bands to identify sources of RF interference.

• Security:

-With an OpenDNS service subscription, Aruba Instant

delivers integrated web ltering, malware and botnet

protection to every device connected to the WLAN

-Integrated Trusted Platform Module (TPM) for secure storage

of credentials and keys

-SecureJack-capable for secure tunneling of wired

Ethernet trafc

OPERATING MODES

• 802.11a/b/g/n Aruba Instant AP

• 802.11a/b/g/n Mobility Controller-managed AP

• Air monitor (AM)

• Secure enterprise mesh

• Remote AP (RAP) when used with a Mobility Controller

ARUBA 175 SERIES OUTDOOR ACCESS POINTS

For high-density Wi-Fi client environments

Multifunctional175seriesoutdoorwirelessaccesspoints

(APs)deliverenterprise-gradeWi-Fitohigh-densityclient

environmentsincampuses,storageyards,warehouses,

containerandtransportationfacilities,extremeindustrial

productionareasandotherharshenvironments.

These high-performance 802.11n outdoor APs deliver

wireless data rates up to 300 Mbps per radio and ensure peak

performance by utilizing channel bonding, block acknowledgement

and MIMO radios. Advanced antenna technology also increases

RF signal range and reliability.

Able to survive in harsh outdoor environments, 175 series APs

withstand exposure to high and low temperatures, persistent

moisture and precipitation, and are fully sealed to keep out

airborne contaminants. All electrical interfaces include industrial-

strength surge protection.

The 175 series outdoor APs feature two dual-band 2.4-GHz and

5-GHz radios with 2x2 MIMO and four external antenna connectors.

WI-FI CLIENT OPTIMIZATION

To eliminate sticky client behavior, every Aruba AP comes with

ClientMatch™ technology, which continuously gathers session

performance metrics and utilizes this data to steer mobile devices

to the best AP and radio on the WLAN, even while users roam.

BEST-IN-CLASS RF MANAGEMENT

All Aruba APs include Adaptive Radio Management™ technology,

which is essential to creating the most reliable, high-performance

WLANs. ARM™ manages the 2.4-GHz and 5-GHz radio bands to

optimize Wi-Fi client performance and ensures that APs stay clear

of RF interference.

Aruba 175 Series Outdoor Access Points Aruba Data Sheet

WIRELESS RADIO SPECIFICATIONS

• AP type: Dual-radio, dual-band 802.11n outdoor

• Software-congurable dual radio supports 2.4 GHz and 5 GHz

• 2x2 MIMO 802.11n with two spatial streams and up to

300 Mbps per radio

• Supported frequency bands (country-specic restrictions apply):

-2.400 to 2.4835 GHz

-5.150 to 5.250 GHz

-5.250 to 5.350 GHz

-5.470 to 5.725 GHz

-5.725 to 5.850 GHz

• Available channels: Dependent upon congured regulatory domain

• Dynamic frequency selection (DFS) optimizes the use of

available RF spectrum

• Supported radio technologies:

-802.11b: Direct-sequence spread-spectrum (DSSS)

-802.11a/g/n: Orthogonal frequency division multiplexing (OFDM)

-802.11n: 2x2 MIMO with two spatial streams

• Supported modulation types:

-802.11b: BPSK, QPSK, CCK

-802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM

• Transmit power: Congurable in increments of 0.5 dBm

• Maximum transmit power:

-2.4 GHz: 25 dBm aggregate

(limited by local regulatory requirements)

-5 GHz: 25 dBm aggregate

(limited by local regulatory requirements)

• Maximum ratio combining (MRC) for improved receiver performance

• Cyclic delay diversity for improved downlink RF performance

• Space-Time Block Coding (STBC) for increased range and

improved reception

• Association rates (Mbps):

-802.11b: 1, 2, 5.5, 11

-802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54

-802.11n: MCS0 to MCS15 (6.5 Mbps to 300 Mbps)

• 802.11n high-throughput (HT) support: HT 20/40

• 802.11n packet aggregation: A-MPDU, A-MSDU

POWER IN

• IAP-175P and AP-175P: 48-volt DC 802.3at power over

Ethernet (PoE+)

• IAP-175AC and AP-175AC: 100-240-volt AC from external

AC power source

• AP-175DC: 12-48 volt DC from external DC power source

• Maximum power consumption: 18 watts; excludes power

consumed by any PoE device connected to and powered by the

IAP-175AC and AP-175AC

POWER OUT

• The AC and DC powered models provide an 802.3af PoE power

source (PSE) on the Ethernet interface

ANTENNA

• Four N-type female interfaces (two 2.4 GHz and two 5 GHz) for

external MIMO antennas

• Feeder cable may be used for external antenna deployments

INTERFACES

• Network: One 10/100/1000BASE-T Ethernet (RJ-45),

auto-sensing link speed and MDI/MDX

• Power: One AC power connector (IAP-175AC and AP-175AC)

and one DC power connector (IAP-175DC and AP-175DC)

• Other: One USB console interface

MOUNTING

• Wall or mast mounted using the mounting bracket supplied with

the unit; solar shield included

MECHANICAL

• Dimensions/weight (unit):

-225 mm x 225 mm x 105 mm (8.9” x 8.9” x 4.1“),

excluding connectors

-3.5 kg (7.7 lb): IAP-175P and AP-175P

-4.25 kg (9.4 lb): IAP-175AC, AP-175AC and AP-175DC

• Dimensions/weight (shipping):

-395 mm x 348 mm x 375 mm (15.6” x 13.7” x 14.8“)

-8.25 kg (18.2 lb): IAP-175P and AP-175P

-9 kg (19.8 lb): IAP-175AC, AP-175AC and AP-175DC

ENVIRONMENTAL

• Operating temperature:

--30° C to 60° C (-22° F to 140° F): IAP-175P and AP-175P

--40° C to 55° C (-40° F to 131° F): IAP-175AC, AP-175AC

and AP-175DC

• Operating humidity: 5% to 95% non-condensing

• Operating altitude: Up to 3,000 meters (9,850 feet)

• Storage and transportation temperature: -40° C to +70° C

(-40° F to +158° F)

• Weather rating: IP66 and IP67

• Wind survivability: Up to 165 mph

• Shock and vibration: ETSI 300-19-2-4 spec T41.E class 4M3

REGULATORY

• FCC/Industry of Canada

• CE Marked

• R&TTE Directive 1995/5/EC

• Low Voltage Directive 72/23/EEC

• EN 300 328

• EN 301 489

• EN 301 893

• UL/IEC/EN 60950

For more country-specic regulatory information and approvals,

please see your Aruba representative.

CERTIFICATIONS

• CB Scheme Safety, cTUVus

• Wi-Fi certied 802.11a/b/g/n

WARRANTY

• One year parts and labor

MINIMUM ARUBAOS VERSION

• 5.0.2.1 on an Aruba Mobility Controller

• Aruba Instant 2.0.0.3 software

Aruba 175 Series Outdoor Access Points Aruba Data Sheet

175 SERIES AP RF PERFORMANCE TABLE

Max transmit power

per active transmit

chain (dBm)

Receive sensitivity

(dBm)

Max transmit power

per active transmit

chain (dBm)

Receive sensitivity

(dBm)

2.4 GHz 5 GHz

802.11b

1 Mbps 20 -96 – –

2 Mbps 20 -96 – –

5.5 Mbps 20 -94 – –

11 Mbps 20 -93 – –

802.11a/g

6 Mbps 20 -96 22 -97

9 Mbps 20 -96 22 -96

12 Mbps 20 -96 22 -96

18 Mbps 20 -95 22 -94

24 Mbps 19 -92 22 -88

36 Mbps 18 -89 20 -86

48 Mbps 17 -85 19 -82

54 Mbps 17 -83 18 -80

802.11n HT20

MCS0 22 -94 21 -97

MCS1 22 -93 20 -94

MCS2 22 -92 19 -91

MCS3 22 -89 18 -87

MCS4 21 -85 17 -86

MCS5 20 -81 16 -81

MCS6 19 -80 15 -79

MCS7 18 -78 15 -77

MCS8 22 -94 21 -97

MCS9 22 -93 20 -94

MCS10 22 -92 19 -91

MCS11 22 -89 18 -87

MCS12 21 -85 17 -86

MCS13 20 -81 16 -81

MCS14 19 -80 15 -79

MCS15 18 -78 15 -77

802.11n HT40

MCS0 21 -92 19 -92

MCS1 21 -91 19 -90

MCS2 21 -89 18 -88

MCS3 20 -86 17 -85

MCS4 19 -83 16 -83

MCS5 18 -79 15 -79

MCS6 18 -77 14 -77

MCS7 17 -75 14 -73

MCS8 21 -92 19 -92

MCS9 21 -91 19 -90

MCS10 21 -89 18 -88

MCS11 20 -86 17 -85

MCS12 19 -83 16 -83

MCS13 18 -79 15 -79

MCS14 18 -77 14 -77

MCS15 17 -75 14 -73

Maximum capability of the hardware provided. Maximum transmit power is limited by local regulatory settings.

Aruba 175 Series Outdoor Access Points Aruba Data Sheet

owners. The scale may vary depending upon the deployment scenario and features enabled. DS_AP175Series_060513

1344 Crossman Avenue. Sunnyvale, CA 94089

1-866-55-ARUBA | Tel. +1 408.227.4500 | Fax. +1 408.227.4550 | [email protected]

www.arubanetworks.com

ORDERING INFORMATION

Part Number Description

IAP-175P Aruba Instant 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 802.3at PoE+. Includes

mounting kit and sun shield. These products should be considered rest-of-world products and must not be deployed in the

United States, Japan or Israel.

IAP-175P-US Aruba Instant 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 802.3at PoE+. Includes

mounting kit and sun shield. Restricted regulatory domain: United States

IAP-175P-IL Aruba Instant 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 802.3at PoE+. Includes

mounting kit and sun shield. Restricted regulatory domain: Israel

IAP-175P-JP Aruba Instant 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 802.3at PoE+. Includes

mounting kit and sun shield. Restricted regulatory domain: Japan

IAP-175AC Aruba Instant 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 100-240 VAC power.

Includes mounting kit and sun shield. These products should be considered rest-of-world products and must not be deployed in

the United States, Japan or Israel.

IAP-175AC-US Aruba Instant 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 100-240 VAC

power. Includes mounting kit and sun shield. Restricted regulatory domain: United States

IAP-175AC-IL Aruba Instant 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 100-240 VAC

power. Includes mounting kit and sun shield. Restricted regulatory domain: Israel

IAP-175AC-JP Aruba Instant 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 100-240 VAC

power. Includes mounting kit and sun shield. Restricted regulatory domain: Japan

AP-175-P Aruba 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 802.3at PoE+. Includes mount-

ing kit and sun shield.

AP-175AC Aruba 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 100-240 VAC power. Includes

mounting kit and sun shield.

AP-175DC Aruba 175 outdoor wireless AP, 802.11a/b/g/n, 2x2:2, dual radio, external antenna connectors, 12-48 VDC power. Includes

mounting kit and sun shield.

For a complete list of accessories, please see the AP-175 Conguration Guide.

Andere Aruba Networks Drahtloser Zugangspunkt Handbücher

Aruba Networks

Aruba Networks RAP-2WG Bedienungsanleitung

Aruba Networks

Aruba Networks AP-270 Series Bedienungsanleitung

Aruba Networks

Aruba Networks 110 SERIES Bedienungsanleitung

Aruba Networks

Aruba Networks AP-93 Bedienungsanleitung

Aruba Networks

Aruba Networks AP-80 MB Bedienungsanleitung

Aruba Networks

Aruba Networks AP-324 Bedienungsanleitung

Aruba Networks

Aruba Networks AP-175DC Bedienungsanleitung

Aruba Networks

Aruba Networks AP-214 Bedienungsanleitung

Aruba Networks

Aruba Networks Access Point Aruba AP 60/61 Bedienungsanleitung

Aruba Networks

Aruba Networks IAP-130 Series Bedienungsanleitung

Aruba Networks

Aruba Networks AP-200 Series Bedienungsanleitung

Aruba Networks

Aruba Networks IAP-114 Bedienungsanleitung

Aruba Networks

Aruba Networks 370P Series Bedienungsanleitung

Aruba Networks

Aruba Networks Aruba 52 Bedienungsanleitung

Aruba Networks

Aruba Networks AP-220 Series Bedienungsanleitung

Aruba Networks

Aruba Networks RAP-5 Bedienungsanleitung

Aruba Networks

Aruba Networks IAP-105 Bedienungsanleitung

Aruba Networks

Aruba Networks IAP-93 Bedienungsanleitung

Aruba Networks

Aruba Networks AP-228 Bedienungsanleitung

Aruba Networks

Aruba Networks AP-93H Bedienungsanleitung

Aruba Networks

Aruba Networks AP-90 Series Bedienungsanleitung

Aruba Networks

Aruba Networks 340 Series Bedienungsanleitung

Aruba Networks

Aruba Networks IAP-175 Bedienungsanleitung

Aruba Networks

Aruba Networks AP-103 Bedienungsanleitung

Beliebte Drahtloser Zugangspunkt Handbücher anderer Marken

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Bedienungsanleitung

Ubiquiti

Ubiquiti NanoStation NSM2 Bedienungsanleitung

Cisco

Cisco Aironet 1550 Series Bedienungsanleitung

Aruba

Aruba IAP-335 Bedienungsanleitung

Advantek Networks

Advantek Networks AWN-AP-54MR Bedienungsanleitung

IP-COM

IP-COM AP355 Bedienungsanleitung

Buffalo

Buffalo AirStation WLA-L11G Bedienungsanleitung

EnGenius

EnGenius EnStationACv2 Bedienungsanleitung

D-Link

D-Link DAP-3662 Bedienungsanleitung

xG Technology

xG Technology xMax CN1300 Bedienungsanleitung

Widelink

Widelink ezWave WAP-1100 Series Bedienungsanleitung

Edimax

Edimax CAP1200 Bedienungsanleitung

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Bedienungsanleitung

Aruba

Aruba AP-203R Bedienungsanleitung

LuXout Shades

LuXout Shades LUXSHADE MOTION Bedienungsanleitung

CreatComm

CreatComm TB5F Bedienungsanleitung

SineDigital

SineDigital MW-1500AP(H) Bedienungsanleitung

TP-Link

TP-Link AP9650 V1 Bedienungsanleitung
