610 Series Campus Access Points | Installation Guide 1

610 Series Campus Access Points

Installation Guide

The Aruba 610 Series Campus Access Points are high-performance, dual-radio tri-band devices that support the

IEEE 802.11ax WLANstandard in the 6GHz band (Wi-Fi 6E) as well as the 5GHz and 2.4GHz bands. Addi-

tionally, this series delivers capacity with MIMO (Multiple-Input, Multiple-Output) and OFDMA (Orthogonal Fre-

quency Division Multiple Access) technologies while also supporting IEEE 802.11a/b/g/n/ac wireless devices.

Hardware Overview

Figure 1 AP-615 Access Point Front View

2| Rev 01|July 2022

Figure 2 AP-615 Access Point Side View

Figure 3 AP-615 Access Point Bottom View

1 E0 Ethernet Port

2 E1Ethernet Port

Figure 4 Access Point Rear View

LED

The LED displays located on the front panel of the access point indicate the system status of the access point.

System Status LED

Color/State Meaning

Off Device Powered off

Green- solid 1Device ready, fully functional, no network restrictions

Green- blinking 2Device booting, not ready

Green- flashing off 3Device ready, fully functional, either uplink negotiated in sub-optimal

speed (<1Gbps)

Green- flashing on Device in deep-sleep mode

Amber- solid Device ready, restricted power mode (limited PoE power available, or

IPM restrictions applied), no network restrictions

Amber- flashing off Device ready, restricted power mode (limited PoE power available, or

IPM restrictions applied), uplink negotiated in sub-optimal speed

(<1Gbps)

Red System error condition - Immediate attention required

Table 1: System Status LED

1. Blinking: one second on, one second off, 2 seconds cycle.

2. Flashing off: mostly on, fraction of a second off, 2 seconds cycle.

3. Flashing on: mostly off, fraction of a second on, 2 seconds cycle.

Radio Status LED

The Radio Status LEDtable below is applicable to 2G, 5G, and 6G labels.

Color/State Meaning

Off Device powered off, or radio disabled

Green- solid Radio enabled in access (AP) mode

Green- flashing off Radio enabled in uplink or mesh mode

Amber- solid Radio enabled in monitor or spectrum analysis mode

Table 2: Radio Status LED

LED Display Settings

The LEDs have three operating modes that can be selected in the system management software:

nDefault mode: refer to Table 1 and Table 2.

nOff mode: all LEDs are off

nBlink mode: all LEDs blink green (synchronized)

Rev 01 | July 2022 | 3

4| Rev 01|July 2022

To force the LEDs into off mode or back to software defined mode, press the reset button for a short duration

(less than 10 seconds).

Bluetooth Low Energy Radios

610 Series access points are equipped with an integrated BLE and 802.15.4 radio that provide the following

capabilities:

nlocation and asset-tracking applications

nwireless console access

nIoT gateway applications

Console Port

The console port is a Micro-B connector is located on the back of this device. Use the proprietary AP-CBL-SERU

cable or AP-MOD-SERU module (sold separately) for direct management of this device when connected to a

serial terminal or laptop. For pin-out details, refer to Figure 5.

Figure 5 Micro-B Port Pin-out

1: NC

2: RXD

3: TXD

4: GND

5: GND

Ethernet Ports

The 610 Series access points are equipped with two active Ethernet ports (E0 and E1). Both ports are

100/1000/2500/5000 Base-T, auto-sensing MDI/MDX, which supports uplink connectivity when linked by an

Ethernet cable. Refer to Figure 6 for a detailed port pin-out.

Figure 6 Ethernet Port Pin-Out

1000Base-T Gigabit

Ethernet Port

RJ-45 Female

Pin-Out 1

Spare Pair

ETH Rx+

ETH Rx-

ETH Tx+

ETH Tx-

(POE positive)

(POE negative)

(POE positive)

Kensington Lock Slot

The 610 Series is equipped with a Kensington lock slot for additional physical security.

USB Interface

The USB 2.0 interface located on the top of the is 610 Series compatible with selected cellular modems and

other peripherals. When active, this port can supply up to 5W/1A to a connected device.

Figure 7 610 Series USB

Reset Button

The reset button located on the bottom of the device can be used to reset the access point to factory default

settings or turn off/on the LED display.

Use one of the following methods to reset the access point to factory default settings:

nTo reset during normal operation:

lHold the reset button for more than 10 seconds while the access point is running.

lRelease the reset button.

nTo reset during power up, hold the reset button while the access point is powering up.

The system status LED will flash again within 15 seconds indicating that the reset is completed. The access

point will now continue to boot with the factory default settings.

To toggle the LED display between Off and Blinking, during the normal operation of the access point, shortly

press and release the reset button using a small, narrow object, such as a paperclip.

Power

Both Ethernet ports support PoE-in, allowing the AP to draw power from an 802.3at/802.3bt PoE power

source. When the AP is powered by both E0 and E1 ports simultaneously, the AP can be configured by

management software to source PoE power from either port, or to combine power from both ports an 802.3af

source may be used.

PoE input rating is 57V max|0.3A. 0.3A is per pair of wires in Ethernet cable. Ethernet cable has 4 pair of wires totally.

Before You Begin

Refer to the sections below before beginning the installation process

FCC Statement:Improper termination of access points installed in the United States configured to non-US model con-

trollers will be in violation of the FCC grant of equipment authorization. Any such willful or intentional violation may res-

ult in a requirement by the FCC for immediate termination of operation and may be subject to forfeiture (47 CFR 1.80).

Pre-Installation Checklist

Before installing your 610 Series access points, ensure that you have the following:

nA mount kit compatible with the APand mount surface

nCat5E or better UTP cable with network access

Rev 01 | July 2022 | 5

6| Rev 01|July 2022

Optional items

nA compatible power adapter with cord

nA compatible PoEmidspan injector with power cord

nAn AP-CBL-SERUconsole cable

nAn AP-MOD-SERU console module

Also, make sure at least one of the following network services is supported:

nAruba Discovery Protocol (ADP)

nDNS server with an “A” record

nDHCP Server with vendor specific options

Aruba, in compliance with governmental requirements, has designed the 610 Series access points so that only

authorized network administrators can change configuration settings. For more information about AP configuration,

refer to theAP Software Quick Start Guide.

If a power adapter other than the Aruba-approved adapter is used in the US or Canada, it should be NRTL listed, with

an output rated 12V DC, minimum 4A, marked “LPS” and “Class 2,” and suitable for plugging into a standard power

receptacle in the US and Canada.

Identifying Specific Installation Locations

Use the access point placement map generated by Aruba 650 Series RF Plan software application to determine

the proper installation location(s). Each location should be as close as possible to the center of the intended

coverage area and should be free from obstructions or obvious sources of interference. These RF

absorbers/reflectors/interference sources will impact RF propagation and should be accounted for during the

planning phase and adjusted for in RF plan.

Identifying Known RF Absorbers/Reflectors/Interference Sources

Identifying known RF absorbers, reflectors, and interference sources while in the field during the installation

phase is critical. Make sure that these sources are taken into consideration when you attach an access point to

its fixed location.

RF absorbers include:

nCement/concrete—Old concrete has high levels of water dissipation, which dries out the concrete, allowing

for potential RF propagation. New concrete has high levels of water concentration in the concrete, blocking

RF signals.

nNatural Items—Fish tanks, water fountains, ponds, and trees

nBrick

RF reflectors include:

nMetal Objects—Metal pans between floors, rebar, fire doors, air conditioning/heating ducts, mesh windows,

blinds, chain link fences (depending on aperture size), refrigerators, racks, shelves, and filing cabinets.

nDo not place an access point between two air conditioning/heating ducts. Make sure that access points are

placed below ducts to avoid RF disturbances.

RF interference sources include:

nMicrowave ovens and other 2.4 or 5 GHz objects (such as cordless phones)

nCordless headset such as those used in call centers or lunch rooms

Portable RF communications equipment should be used no closer than 30 cm (12 inches) to any part of the access

point. Otherwise, degradation of the performance of this equipment could result.

Access Point Installation

All Aruba access points should be professionally installed by an Aruba-Certified Mobility Professional (ACMP). The

installer is responsible for ensuring that grounding is available and meets applicable national and electrical codes.

Failure to properly install this product may result in physical injury and/or damage to property.

Tous les points d'accès Aruba doivent impérativement être installés par un professionnel agréé. Ce dernier doit

s'assurer que l'appareil est mis à la terre et que le circuit de mise à la terre est conforme aux codes électriques

nationaux en vigueur. Le fait de ne pas installer correctement ce produit peut entraîner des blessures corporelles et /

ou des dommages matériels.

For indoor use only. The access point, AC adapter, and all connected cables are not to be installed outdoors. This

stationary device is intended for stationary use in partly temperature controlled weather-protected environments

(class 3.2 per ETSI 300 019).

Software

Aruba 610 Seriesrequires ArubaOS or Aruba Instant8.10.0.0 or later. For instructions on choosing operating

modes and initial software configuration, refer to theAP Software Quick Start Guide.

Aruba access points are classified as radio transmission devices, and are subject to government regulations of the

host country. The network administrator(s) is/are responsible for ensuring that configuration and operation of this

equipment is in compliance with their country’s regulations. For a complete list of approved channels in your country,

refer to the Aruba Downloadable Regulatory Table at https://www.arubanetworks.com/techdocs/DRT/Default.htm.

Verifying Post-Installation Connectivity

The integrated LEDs on the access point can be used to verify that the access point is receiving power and

initializing successfully (see Table 1 and Table 2). Refer to the AP Software Quick Start Guide for further

details on verifying post-installation network connectivity.

Ethernet

lE0: 100/1000/2500/5000 Base-T auto-sensing Ethernet RJ-45 Interfaces

lE1: 100/1000/2500/5000 Base-T auto-sensing Ethernet RJ-45 Interfaces

Power

lPower over Ethernet (IEEE 802.3at and 802.3bt compliant)

l12V DC power interface, support powering through AC-to-DC power adapter

lMaximum power consumption:Refer to datasheet

Environmental

nOperating

lTemperature: 0°C to +50°C (+32°F to +122°F)

lHumidity: 5% to 95% non-condensing

nStorage

lTemperature: -40ºC to 70ºC (-40ºF to 158ºF)

Rev 01 | July 2022 | 7

8| Rev 01|July 2022

lHumidity: 5% to 95% non-condensing

Regulatory Information

For the purpose of regulatory compliance certifications and identification, this product has been assigned a

unique regulatory model number (RMN). The regulatory model number can be found on the product

nameplate label, along with all required approval markings and information. When requesting compliance

information for this product, always refer to this regulatory model number. The regulatory model number

RMN is not the marketing name or model number of the product.

The following regulatory model numbers apply to the 610 Series

nAP-615 RMN:APIN0615

ArubaNetworks provides a multi-language document that contains country-specific restrictions and additional

safety and regulatory information for all Aruba access points. This document can be viewed or downloaded at

www.arubanetworks.com.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s author-

ity to operate this equipment.

Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la conformité

est susceptible d'annuler son droit d'utilisation.

Brazil

Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência

em sistemas devidamente autorizados.

O uso deste equipamento é restrito a ambientes fechados e proibido em plataformas petrolíferas, carros,

trens, embarcações e no interior de aeronaves abaixo de 3.048 m (10.000 pés).

Safety and Regulatory Compliance

RF Radiation Exposure Statement: This equipment complies with RF radiation exposure limits. This equipment

should be installed and operated with a minimum distance of 7.87 inches (20cm) between the radiator and your body

for 2.4 GHz, 5 GHz, and 6GHz operations. This transmitter must not be co-located or operating in conjunction with any

other antenna or transmitter.

Déclaration e la concernant l’exposition aux rayonnements à fréquence radioélectrique (FR): Cet appareil est con-

forme aux limites d’exposition aux rayonnements FR établies par la FCC. Il doit être installé et utilisé à une distance

minimale de 20 cm (7,87 pouces) entre le radiateur et votre corps, qu’il opère sur la bande 2,4 GHz, 5 GHz, ou 6GHz.

Cet émetteur ne doit pas être installé ou utilisé à proximité immédiate d’une autre antenne ni d’un autre transmetteur.

The device could automatically discontinue transmission in case of absence of information to transmit, or operational

failure. Note that this is not intended to prohibit transmission of control or signaling information or the use of repet-

itive codes where required by the technology.

Industry Canada

This Class B digital apparatus meets all of the requirements of the Canadian Interference-Causing Equipment

Regulations.

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Eco-

nomic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1)

This device may not cause interference; and (2) This device must accept any interference, including interference

that may cause undesired operation of the device.

When operated in 5.15 to 5.25 GHz frequency range, this device is restricted to indoor use to reduce the poten-

tial for harmful interference with co-channel Mobile Satellite Systems.

Déclaration d’Industrie Canada

Cet appareil numérique de classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du

Canada.

Cet appareil contient des émetteurs / récepteurs exemptés de licence qui sont conformes aux RSS exempts de

licence d'Innovation, Sciences et Développement économique Canada. Son fonctionnement est soumis aux

deux conditions suivantes: (1) ce périphérique ne doit pas provoquer d’interférences, et (2) ce périphérique

doit accepter toute interférence, y compris les interférences susceptibles de provoquer un dysfonctionnement.

En cas d'utilisation dans la plage de fréquences de 5,15 à 5,25 GHz, cet appareil doit uniquement être utilisé à

intérieur afin de réduire les risques d'interférence avec les systèmes satellites mobiles partageant le même

canal.

EU &UK Regulatory Conformity

The Declaration of Conformity made under Radio Equipment Directive 2014/53/EU as well as the United

Kingdom's Radio Equpment Regulations 2017/UKis available for viewing at: www.hpe.com/eu/certificates.

Select the document that corresponds to your device’s model number as it is indicated on the product label.

Compliance is only assured if the Aruba approved accessories as listed in the ordering guide are used.

https://www.arubanetworks.com/assets/og/OG_610Series.pdf.

Wireless Channel Restrictions

5150-5350MHz band is limited to indoor only in the following countries; Austria (AT), Belgium (BE), Bulgaria

(BG), Croatia (HR), Cyprus (CY), Czech Republic (CZ), Denmark (DK), Estonia (EE), Finland (FI), France (FR),

Germany (DE), Greece (GR), Hungary (HU), Iceland (IS), Ireland (IE), Italy (IT), Latvia (LV), Liechtenstein (LI),

Lithuania (LT), Luxembourg (LU), Malta (MT), Netherlands (NL), Norway (NO), Poland (PL), Portugal (PT),

Romania (RO), Slovakia (SK), Slovenia (SL), Spain (ES), Sweden (SE), Switzerland (CH), Turkey (TR), United

Kingdom (UK) (NI).

Radio Frequency Range MHz Max EIRP

BLE/Zigbee 2402-2480 10 dBm

2412-2472 20 dBm

5150-5250 23 dBm

5250-5350 23 dBm

Wi-Fi 5470-5725 30 dBm

5725-5850 14 dBm

5945-6425 23 dBm

Rev 01 | July 2022 | 9

10 | Rev 01|July 2022

Lower power radio LAN product operating in 2.4 GHz and 5 GHz bands. Please refer to the ArubaOS User

Guide/Instant User Guide for details on restrictions.

European Union and United Kingdom

This device is limited for indoor use. Use in trains with metal-coated windows (or similar structures made of

materials with comparable attenuation characteristic) and aircraft is permitted. Operations in the 6GHz band

are blocked by firmware for some countries pending adoption of spectrum. Refer to Aruba DRT release notes

for details.

Japan

Korean

México

La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o

dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debeaceptar cualquier

interferencia, incluyendo la que pueda causar su operación no deseada.

Нормативные требования Евhразийского Экономического Союза

Russia

HPE Russia: ООО "Хьюлетт Паккард Энтерпрайз" Российская Федерация, 125171, г.

Москва, Ленинградское шоссе, 16А, стр.3, Телефон: +7 499 403 4248 Факс: +7 499

403 4677

'HPE Kazakhstan': TOO «Хьюлетт-Паккард (К)», Республика Казахстан, 050040, г.

Алматы, Бостандыкский район, проспект Аль-Фараби, 77/7, Телефон/факс: + 7 727

355 35 50

Kazakhstan

ЖШС "Хьюлетт Паккард Энтерпрайз" Ресей Федерациясы, 125171, Мәскеу, Ленинград тас жолы, 16A

блок 3, Телефон: +7 499 403 4248 Факс: +7 499 403 4677

Andere Handbücher für 610 Series

Inhaltsverzeichnis

Andere Aruba Drahtloser Zugangspunkt Handbücher

Aruba

Aruba 303 Series Benutzerhandbuch

Aruba

Aruba 570 Series Bedienungsanleitung

Aruba

Aruba 203R Series Bedienungsanleitung

Aruba

Aruba 650 SERIES Bedienungsanleitung

Aruba

Aruba AP-130-MNT-C2 Bedienungsanleitung

Aruba

Aruba AP-92 Bedienungsanleitung

Aruba

Aruba AP-65WB Bedienungsanleitung

Aruba

Aruba 630 Series Bedienungsanleitung

Aruba

Aruba 560 Series Bedienungsanleitung

Aruba

Aruba Instant On AP15 Bedienungsanleitung

Aruba

Aruba 530 Series Bedienungsanleitung

Aruba

Aruba 300 series Bedienungsanleitung

Aruba

Aruba AP-203R Bedienungsanleitung

Aruba

Aruba AP-303H Series Bedienungsanleitung

Aruba

Aruba Instant On AP22 Bedienungsanleitung

Aruba

Aruba AP-318 Bedienungsanleitung

Aruba

Aruba IAP-228 Bedienungsanleitung

Aruba

Aruba AP-105 Bedienungsanleitung

Aruba

Aruba 560EX Series Bedienungsanleitung

Aruba

Aruba 210 Series Bedienungsanleitung

Aruba

Aruba AWS-100 Bedienungsanleitung

Aruba

Aruba AP200 Bedienungsanleitung

Aruba

Aruba 310 Series Bedienungsanleitung

Aruba

Aruba RAP-5WN Bedienungsanleitung

Beliebte Drahtloser Zugangspunkt Handbücher anderer Marken

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Bedienungsanleitung

Ubiquiti

Ubiquiti NanoStation NSM2 Bedienungsanleitung

Cisco

Cisco Aironet 1550 Series Bedienungsanleitung

Advantek Networks

Advantek Networks AWN-AP-54MR Bedienungsanleitung

IP-COM

IP-COM AP355 Bedienungsanleitung

Buffalo

Buffalo AirStation WLA-L11G Bedienungsanleitung

EnGenius

EnGenius EnStationACv2 Bedienungsanleitung

D-Link

D-Link DAP-3662 Bedienungsanleitung

xG Technology

xG Technology xMax CN1300 Bedienungsanleitung

Widelink

Widelink ezWave WAP-1100 Series Bedienungsanleitung

Edimax

Edimax CAP1200 Bedienungsanleitung

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Bedienungsanleitung

LuXout Shades

LuXout Shades LUXSHADE MOTION Bedienungsanleitung

CreatComm

CreatComm TB5F Bedienungsanleitung

SineDigital

SineDigital MW-1500AP(H) Bedienungsanleitung

TP-Link

TP-Link AP9650 V1 Bedienungsanleitung

Draytek

Draytek VIGORAP 902 Bedienungsanleitung

EnGenius

EnGenius EAP350 Bedienungsanleitung
