Use & Care Guide
Dishwasher
ASKO D5132
2
Dear ASKO customer,
Thank you for choosing this quality product from Scandinavia, which was made in Sweden.
We want you to feel assured that the inside of your new machine is just as good as the outside and that
the ethics and standards that went into the production of this machine are just as high as the quality
and performance that you will receive from it. We hope that this product will give you many years of
pleasure.
To ensure that you get the most out of your new machine, we recommend that you read the operating in-
structions before using the machine. The operating instructions also contain information on how to avoid
damaging the environment.
3
Contents
Page
Before doing your first wash 4
Safety 5
Child safety 6
Parts of the dishwasher 7
Technical information 7
Baskets 8
Control panel 11
Dispenser 11
Basic Course 12
Eco-dishwashing 16
Fragile dishes 17
Program description 18
Cleaning 19
Rinse aid 22
Salt 23
Settings 24
Fault indications 25
Page
Troubleshooting 26
Performance information 29
Installation 30
Service & guarantee 34
Own comments 35
Quick Guide 36
4
Before doing your first wash
Read the directions of use
Read the directions of use before starting to
use your machine, especially the Safety, Child
Safety and Basic Course sections.
Take care with certain materials
Read the section ‘Fragile dishes’ before wash-
ing china with unglazed decoration or other
household goods made of plastic, wood or crys-
tal requiring careful treatment.
5
Safety
General
Winter storage/Transport
• Read and keep the directions for use!
• Installation of water, drainage and electricity
must be carried out by a qualified professional.
• Do not use the dishwasher for any purposes
other than those stated in this User Guide.
• Do not load the dishwasher with anything other
than dishes.
• Only use dishwasher detergent!
• Place knives and other sharp objects so that
they cannot cause injury to people or damage
the dishwasher.
Never put dishes containing solvent residue in
the machine due to risk of explosion. Neither
may dishes containing ashes, wax or lubricating
grease be washed in the dishwasher.
Winter storage/Transport
Store the machine away from frost.
Avoid long journeys in extreme cold. Transport
the machine in an upright position or lying on its
back.
Overfill protection
The overfill protector starts pumping out water
and closes off the water intake if the machine’s
water level exceeds the normal level. If the over-
fill protector starts up, shut off the water supply
and phone for service. See ‘Troubleshooting’.
Cleaning
Only use a slightly damp cloth for cleaning
around the edge of the door. Do not use a spray
bottle! Water can penetrate into the lock and
come into contact with the electrical compo-
nents.
Packaging materials
Sort at source in accordance with the re-
commendations of your local authority.
Scrapping
When the time comes for the machine to be
scrapped, it should immediately be rendered
unusable. Remove the plug and cut off the lead
as short as possible.
Contact your refuse collection department or
your local authority for information on the correct
way to dispose of the machine!
The machine is manufactured and labelled for
recycling.
6
Child Safety!
Child safety lock
A child safety lock is fitted to prevent children
from opening the door of the dishwasher.
1. Activate the child safety lock by pressing in
the door latch and turning the screw slot (up
in the left hand corner) to the vertical position
with a screwdriver.
2. To open the door, you must press the white
plastic latch (illustrated below) to the left at
the same time as pressing the catch up-
wards.
Reset by returning the screw slot to the horizon-
tal position.
Child-safe dishwashing
• Use the knife basket, or knife holder, for all
long/sharp items.
• Always close the door and start the program
immediately once dishwasher detergent has
been added.
• Keep children away from the dishwasher when
it is open. There might be remains of dishwas-
her detergent present!
• Do not allow children to use or play with the
dishwasher. Always take particular care when
the door is open.
Protect your children!
- Dishwasher detergent is
corrosive!
Store dishwasher detergent and rinse aid out
of the reach of children! Should dishwasher
detergent be swallowed, immediately drink one
or two glasses of milk or water. Do not attempt
to induce vomiting. Contact a doctor! Should
dishwasher detergent come into contact with the
eyes, rinse (for at least 15 minutes) with copious
amounts of water.
Closed
Open
7
Parts of the dishwasher*
Technical information
Height
Width
Depth
Weight
Capacity*
Water pressure
Connection
Max
Accessories
*In accordance with standard, EN50242
**See type plate.
820-870 mm
596 mm
550 mm****
48 kg/51 kg
14 place settings
0.03-1.0 MPa (0.3–10 kp/cm2)
1-phase, 120 V, 60Hz 10/10A**
1200 W**
Work surface, Side panels, Anti-tilt
1. Upper basket
2. Spray arms
3. Cutlery basket
4. Lower basket
5. Rinse aid dispenser
6. Dishwasher detergent compartment
7. Main switch
8. Program panel
9. Filter
10. Type plate
* Details may differ
depending on model and market!
2
3
4
5
6
7
8
1
9
10
8
Baskets*
11
2
3
4
5
*Details may differ depending on the
model and market!
Upper basket 1. Wine glass shelf
2. Knife stop
3. Upper spray arm
4. Locking handle for upper basket
5. Catch
Raising/lowering the upper basket
1. Pull out the upper basket.
2. Pull out the catches (5) on either side of the
upper basket and lower the upper basket at
the same time.
3. Grab the basket by the sides and lift it.
Lower basket
9
Cutlery basketbasket
1a
1b
1c
Cutlery basket cover
2b
2a
2c
*Details may differ depending on the
model and market!
Baskets*
10
Positioning the cutlery basket cover
The cover for the cutlery basket can be removed and used, for example, as an extra cutlery basket
in the upper basket (see illustrations below).
3a
3b
3c
Baskets*
*Details may differ depending on the
model and market!
