ASROCK A620M-HDV/M.2 Bedienungsanleitung

Contact Information

If you need to contact ASRock or want to know more about ASRock, you’re

welcome to visit ASRock’s website at http://www.asrock.com; or you may contact

your dealer for further information. For technical questions, please submit a

support request form at https://event.asrock.com/tsd.asp

ASRock Incorporation

e-mail: info@asrock.com.tw

ASRock EUROPE B.V.

e-mail: sales@asrock.nl

ASRock America, Inc.

e-mail: sales@asrockamerica.com

Scan the QR code to view more manuals and documents.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specifcations 2

1.3 Motherboard Layout 5

1.4 I/O Panel 7

1.5 Block Diagram 8

Chapter 2 Installation 9

2.1 Installing the CPU 10

2.2 Installing the CPU Fan and Heatsink 13

2.3 Installing Memory Modules (DIMM) 21

2.4 Connecting the Front Panel Header 23

2.5 Installing the I/O Panel Shield 24

2.6 Installing the Motherboard 25

2.7 Installing SATA Drives 26

2.8 Installing a Graphics Card 28

2.9 Connecting Peripheral Devices 30

2.10 Connecting the Power Connectors 31

2.11 Power On 32

2.12 Jumpers Setup 33

2.13 Onboard Headers and Connectors 34

2.14 Smart Switches 41

2.15 Post Status Checker 43

2.16 M.2 WiFi/BT PCIe WiFi Module Installation Guide 44

2.17 M.2 SSD Module Installation Guide (M2_1) 46

2.18 M.2 SSD Module Installation Guide (M2_2) 48

English

A620M-HDV/M.2

Chapter 1 Introduction

ank you for purchasing ASRock A620M-HDV/M.2 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

1.1 Package Contents

•ASRock A620M-HDV/M.2 Motherboard (Micro ATX Form Factor)

•ASRock A620M-HDV/M.2 User Manual

•1 x I/O Shield

•2 x Serial ATA (SATA) Data Cables (Optional)

•3 x Screws for M.2 Sockets (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specifcations

Platform •Micro ATX Form Factor

•2oz Copper PCB

CPU •Supports AMD Socket AM5 RyzenTM 7000 Series Processors

Chipset •AMD A620

Memory •Dual Channel DDR5 Memory Technology

•2 x DDR5 DIMM Slots

•Supports DDR5 non-ECC, un-buered memory up to

5600+(OC)*

•Max. capacity of system memory: 64GB

•Supports Extreme Memory Prole (XMP) and EXTended

Proles for Overclocking (EXPO) memory modules

* Please refer to Memory Support List on ASRock's website for

more information. (http://www.asrock.com/)

Expansion

Slot

CPU:

•1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*

Chipset:

•2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)*

•1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe

WiFi module

* Supports NVMe SSD as boot disks

•15μGold Contact in VGA PCIe Slot (PCIE1)

Graphics •Integrated AMD RDNATM 2 graphics (Actual support may

vary by CPU)

•1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR,

HDCP 2.3 and max. resolution up to 4K 120Hz

•1 x DisplayPort 1.4 with DSC (compressed), supports HDCP

2.3 and max. resolution up to 4K 120Hz

Audio •7.1 CH HD Audio (Realtek ALC897 Audio Codec)

•Nahimic Audio

English

A620M-HDV/M.2

LAN •Gigabit LAN 10/100/1000 Mb/s

•Realtek RTL8111H

USB •1 x USB 3.2 Gen1 Type-C (Rear)

•4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front)

•6 x USB 2.0 (2 Rear, 4 Front)

* All USB ports support ESD Protection

Rear Panel

I/O

•2 x Antenna Mounting Points

•1 x HDMI Port

•1 x DisplayPort 1.4

•1 x USB 3.2 Gen1 Type-C Port

•2 x USB 3.2 Gen1 Type-A Ports

•2 x USB 2.0 Ports

•1 x RJ-45 LAN Port

•1 x BIOS Flashback Button

•HD Audio Jacks: Line in / Front Speaker / Microphone

Storage CPU:

•1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280

PCIe Gen4x4 (64 Gb/s) mode*

Chipset:

•1 x M.2 Socket (M2_2, Key M), supports type 2260/2280

SATA3 6.0 Gb/s & PCIe Gen3x2 (16 Gb/s) modes*

•2 x SATA3 6.0 Gb/s Connectors

* Supports NVMe SSD as boot disks

RAID •Supports RAID 0 and RAID 1 for SATA storage devices

•Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe

storage devices*

* Requires additional M.2 NVMe expansion cards to support

RAID 10

English

Connector •1 x Power LED and Speaker Header

•1 x CPU Fan Connector (4-pin)*

•3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan

Speed Control)**

•1 x 24 pin ATX Power Connector

•1 x 8 pin 12V Power Connector

•1 x Front Panel Audio Connector

•2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

•1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)

* CPU_FAN1 supports the fan power up to 1A (12W).

** CHA_FAN1~3/WP support the fan power up to 2A (24W).

** CHA_FAN1~3/WP can auto detect if 3-pin or 4-pin fan is in

use.

BIOS

Feature

•AMI UEFI Legal BIOS with GUI support

OS •Microso® Windows® 10 64-bit / 11 64-bit

Certica-

tions

•FCC, CE

•ErP/EuP ready (ErP/EuP ready power supply is required)

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may aect your system’s stability, or

even cause damage to the components and devices of your system. It should be done

at your own risk and expense. We are not responsible for possible damage caused by

overclocking.

* For detailed product information, please visit our website: http://www.asrock.com

English

A620M-HDV/M.2

1.3 Motherboard Layout

English

No. Description

1 ATX 12V Power Connector (ATX12V1)

2 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)

3 CPU Fan Connector (CPU_FAN1)

4 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)

5 ATX Power Connector (ATXPWR1)

6 USB 3.2 Gen1 Header (USB32_3_4)

7 Clear CMOS Jumper (CLRCMOS1)

8 System Panel Header (PANEL1)

9 Power LED and Speaker Header (SPK_PLED1)

10 SATA3 Connector (SATA3_2)

11 SATA3 Connector (SATA3_1)

12 Post Status Checker (PSC)

13 USB 2.0 Header (USB_5_6)

14 USB 2.0 Header (USB_3_4)

15 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)

16 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)

17 Front Panel Audio Header (HD_AUDIO1)
