ASROCK J3160 Bedienungsanleitung

Version 1.0

Published August 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

Website: http://www.asrock.com

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per AsRock Beebox

J3160/B/BB o cerca il tuo prodotto tra le migliori offerte di PC Desktop e Workstation

Important Safety Instructions

Pay close attention to the following safety instructions before performing any of

the operation. Basic safety precautions should be followed to protect yourself from

harm and the product from damage:

• Operation of the product should be carried out by suitably trained, qualied, and

certied personnel only to avoid risk of injury from electrical shock or energy hazard.

• Disconnect the power cord from the wall outlet when installing or removing main

system components, such as the motherboard and power supply unit.

• Place the system on a stable and at surface.

• Use extreme caution when working with high-voltage components.

• When handling parts, use a grounded wrist strap designed to prevent static discharge.

• Keep the area around the system clean and clutter-free.

• Keep all components and printed circuit boards (PCBs) in their antistatic bags when

not in use.

• Handle a board by its edges only; do not touch its components, peripheral chips,

memory modules or contacts.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contact Information

If you need to contact ASRock or want to know more about ASRock, you’re welcome

to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer

for further information. For technical questions, please submit a support request

form at http://www.asrock.com/support/tsd.asp

ASRock Incorporation

2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

ASRock EUROPE B.V.

Bijsterhuizen 11-11

6546 AR Nijmegen

e Netherlands

Phone: +31-24-345-44-33

Fax: +31-24-345-44-38

ASRock America, Inc.

13848 Magnolia Ave, Chino, CA91710

U.S.A.

Phone: +1-909-590-8308

Fax: +1-909-590-1026

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Product Specications 2

Chapter 2 Product Overview 4

2.1 Front View 4

2.2 Rear View 5

2.3 Inside View 6

Chapter 3 Hardware Installation 7

3.1 How to Remove the Bottom Case 7

3.2 How to Remove the M.2 WiFi Module 8

3.3 How to Install the mSATA SSD 9

3.4 How to Install the 2.5-inch Hard Drive 10

3.5 How to Install the Memory Modules

(DDR3 Low Voltage (1.35V)) 12

3.6 How to Install the VESA Bracket 13

3.7 Positions of the Beebox series 14

Chapter 4 Software and Utilities Operation 15

4.1 Installing Drivers 15

4.2 ASRock APP Shop 16

4.2.1 UI Overview 16

4.2.2 Apps 17

4.2.3 BIOS & Drivers 20

4.2.4 Setting 21

4.3 Creating Windows® 7 Installation Disk with USB 3.0 Drivers

Packed 22

Chapter 5 UEFI SETUP UTILITY 26

5.1 Introduction 26

5.1.1 UEFI Menu Bar 26

5.1.2 Navigation Keys 27

5.2 Main Screen 28

5.3 Advanced Screen 29

5.3.1 CPU Conguration 30

5.3.2 Chipset Conguration 32

5.3.3 Storage Conguration 34

5.3.4 IntelRMT Conguration 35

5.3.5 Super IO Conguration 36

5.3.6 ACPI Conguration 37

5.3.7 USB Conguration 39

5.3.8 Platform Trust Technology 40

5.4 Tools 41

5.5 Hardware Health Event Monitoring Screen 43

5.6 Security Screen 44

5.7 Boot Screen 45

5.8 Exit Screen 48

Beebox series

PB 1

English

Chapter 1 Introduction

ank you for purchasing Beebox series, a reliable barebone system produced under

ASRock’s consistently stringent quality control. It delivers excellent performance

with robust design conforming to ASRock’s commitment to quality and endurance.

1.1 Package Contents

• Beebox series Barebone System with:

Beebox series Chassis

Motherboard (pre-installed)

M.2 WiFi Module (pre-installed)

*e barebone system does not include memory, hard drive and mSATA SSD.

• Power Adapter (36W/12V) & Power Plug

• SATA Data and Power Cable

• mSATA Screw

• VESA Mount Bracket & Screw Package

• Remote Controller

• Support CD

• Quick Installation Guide

Because the hardware specications might be updated, the content of this documentation

will be subject to change without notice. In case any modications of this documentation

occur, the updated version will be available on ASRock’s website without further notice. If

you require technical support related to this product, please visit our website for specic

information about the model you are using. ASRock website: http://www.asrock.com.

If any items are missing or appear damaged, contact your authorized dealer.

2 3

English

1.2 Product Specications

Beebox series Full System

(With OS)

Full System

(Without OS) Barebone

CPU

Intel® Quad-Core N3150 Processor

(Up to 2.08 GHz)

Intel® Dual-Core

N3050 Processor

(Up to 2.16 GHz)

Intel® Dual-Core N3000 Processor

(Fanless Design)

OS Windows® 10

Home N/A N/A

Chipset Intel® N3150 / N3050 SoC Intel® N3150 / N3000 SoC

Memory 2GB DDR3L-

1600MHz

(1x2GB)

4GB DDR3L-

1600MHz

(2x2GB)

N/A

Supports DDR3L 1600/1066MHz, 2 x SO-DIMM slots, Max. 16GB

HDD

32GB eMMC N/A

128GB mSATA SSD

Supports 1 x 2.5" SATA HDD*

N/A

LAN Gigabit LAN

WiFi 802.11ac + BT 4.0

Audio Realtek ALC283

eMMC

mSATA

slot

2.5”HDD

Supports 1 x

mSATA slot

Supports 1 x

mSATA slot

Beebox series

2 3

English

Front I/O 1 x USB 3.0, 1 x USB 3.0 (Type C), 1 x IR, 1 x Audio-out with MIC-In

Rear I/O 2 x HDMI, 1 x DP, 2 x USB 3.0, 1 x LAN, 1 x Kensington lock

Power Unit 36W/12V Adapter

Dimension 110mm (W) x 46mm (H) x 118.5mm (L)

Controller Remote Controller

VESA Bracket included , supports 75 x 75 and 100 x 100 mm

Volume

(Liters) 0.6L

Operating

Tempera-

ture

0°C~40°C

* For Beebox N3000 series, it is not recommended to install 2.5” HDD. If you install the 2.5” HDD, please keep the

Beebox series in a vertical position to ensure better cooling performance.

4 5

English

Chapter 2 Product Overview

is chapter provides diagrams showing the location of important components of

the Beebox series.

2.1 Front View

No. Description

1Headphone & Microphone

2 USB 3.0 (Type A)

3 USB 3.0 (Type C)

4 IR Sensor Window

1 2 3 4
