ASROCK NUC BOX-1360P/D4 Bedienungsanleitung

NUC BOX-1260P

NUC BOX-1240P

NUC BOX-1220P

User Manual

Version 1.0

Published May 2022

Version 1.0

Published January 2023

No part of this documentation may be reproduced, transcribed, transmitted, or translated

in any language, in any form or by any means, except duplication of documentation by the

purchaser for backup purpose, without written consent of ASRock Industrial Inc.

Products and corporate names appearing in this documentation may or may not be

registered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specifications and information contained in this documentation are furnished for

informationa l use only and subject to change without notice, and should not be

constructed as a commitment by ASRock Industrial. ASRock Industrial assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Industrial does not provide

warranty of any kind, either expressed or implied, including but not limited to the implied

warranties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock Industrial, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for loss of

prots, loss of business, loss of data, interruption of business and the like), even if ASRock

Industrial has been advised of the possibility of such damages arising from any defect or

error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Industrial’s Website: https://www.asrockind.com

Replaceable batteries

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

Contact Information

If you need to contact ASRock Industrial or want to know more about ASRock

Industrial, you’re welcome to visit ASRock Industrial’s website at https://www.

asrockind.com; or you may contact your dealer for further information.

ASRock Industrial Incorporation

Email: Info_ipc@asrockind.com

e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

4 5

English

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Product Specications 2

1.3 Block Diagram 4

Chapter 2 Product Overview 5

2.1 Front View 5

2.2 Rear View 6

2.3 Inside View 7

Chapter 3 Hardware Installation 8

3.1 How to Remove the Bottom Case 8

3.2 How to Install the Memory Modules 9

3.3 How to Install the WiFi Module 10

3.4 How to Remove the M.2 SSD (Type 2280) and the Bracket 11

3.5 How to Install the M.2 SSD (Type 2260) 12

3.6 How to Install the Hard Drive 14

3.7 How to Install the VESA Bracket 16

Chapter 4 Motherboard 18

4.1 Motherboard Layout 18

4.2 Motherboard Specications 19

4.3 Onboard Headers and Connectors 21

4.4 Expansion Slots (M.2 Slots) 24

Chapter 5 UEFI SETUP UTILITY 25

5.1 Introduction 25

5.1.1 Entering BIOS Setup 25

NUC BOX-1360P/D4

NUC BOX-1340P/D4

4 5

English

5.1.2 UEFI Menu Bar 26

5.1.3 Navigation Keys 27

5.2 Main Screen (Advanced Mode) 28

5.3 Advanced Screen 29

5.3.2 Chipset Conguration 33

5.3.3 Storage Conguration 35

5.3.4 Super IO Conguration 37

5.3.5 AMT Conguration 38

5.3.6 ACPI Conguration 40

5.3.7 USB Conguration 41

5.3.8 Trusted Computing 42

5.4 Hardware Health Event Monitoring Screen 45

5.5 Security Screen 46

5.6 Boot Screen 47

5.7 Exit Screen 49

Chapter 6 Software Support 50

6.1 Install Operating System 50

6 1

English

Chapter 1 Introduction

1.1 Package Contents

• NUC BOX-1360P/D4 / NUC BOX-1340P/D4

• 1 x Screw for M.2 slot

• 1 x 19V/90W Power Adapter

• 1 x Screw Package

• 1 x VESA mounting bracket

• 1 x Bracket for M.2 2280 support

• Quick Installation Guide

NUC BOX-1360P/D4

NUC BOX-1340P/D4

6 1

English

Chapter 1 Introduction

1.1 Package Contents

• NUC BOX-1360P/D4 / NUC BOX-1340P/D4

• 1 x Screw for M.2 slot

• 1 x 19V/90W Power Adapter

• 1 x Screw Package

• 1 x VESA mounting bracket

• 1 x Bracket for M.2 2280 support

• Quick Installation Guide

Because the hardware specications might be updated, the content of this documentation

will be subject to change without notice.

If any items are missing or appear damaged, contact your authorized dealer.

2 3

English

1.2 Product Specications

NUC BOX-1360P/D4

NUC BOX-1340P/D4 Barebone

CPU

Intel® 13th Gen (Raptor Lake-P) Core™ Processors

NUC BOX-1360P/D4 (i7-1360P, 4P+8E)

NUC BOX-1340P/D4 (i5-1340P, 4P+8E)

Chipset MCP

BIOS AMI SPI 256 Mbit

Memory Supports Dual Channel DDR4 3200 MHz

Storage 1 x M.2 (KEY M, 2242/2260/2280)

with PCIe Gen4 x4 for SSD

*M.2 Key M 2280(Supported by bracket)

1 x SATA3.0 (6.0 Gb/s)

LAN Intel® I226LM with 10/100/1000/2500 Mbps

WiFi 1 x Wi-Fi 6E 802.11ax (2.4Gbps) + BT 5.2

(M.2 Key E, 2230 PCIe x1, USB 2.0 for Wireless)

Audio Realtek ALC233, High Denition Audio

Front I/O 1 x USB 3.2 Gen2 (Type A)

1 x USB4 (Supports DP1.4a display output)

1 x USB 3.2 Gen2 (Type-C, Support DP1.4a display

output)

1 (headphone & microphone jack)

Rear I/O 1 x HDMI 2.0b, 1 x DP1.4a, 2 x 2.5 Gigabit LAN, 2 x USB

3.2 Gen2 (Type-A), DC-IN

M.2 slot

SATA

NUC BOX-1360P/D4

NUC BOX-1340P/D4

2 3

English

Power Unit 19V/90W Power Adapter

Dimension 110.mm (W)x 117.5mm (D) x 47.85mm (H)

VESA Bracket included , supports 75 x 75 and 100 x 100 mm

Weight 1Kg

Operating Tem-

perature 0°C~40°C

4 5

English

1.3 Block Diagram

M.2 M Key

2242/2280

PCIe x4 Gen4

3.5mm

Combo Conn.

Transformer

DDR4 SO-DIMM 3200 (32GB)

M.2 KEY-E (2230)

DDR4 - CH1

LAN1

I226LM

Raptor Lake P

PCIe*1+CNVi+USB2*1

Intel

DDR4 - CH0

DDR4 SO-DIMM 3200 (32GB)

PCIe#9

PCIe#6+USB2#10

2.5G LAN

RJ45

OIDMOIDM

CPU_PCIEX4_A_[3:1]

SATA#0

SATA

Header

SPI0 CS0#

SPI ROM 32MB

Flash Box

TPM2.0

CS2#

TCP0+USB2#5

TCP1+USB2#6

TCP2

TCP3

HDMI

Conn.

AUX/DDC

Switch

ITE

Retimer

DP++

Conn.

Retimer

TypeC Conn.

(USB+DP)

HDA

Codec

ALC233

Line_Out

MIC_In

USB2#7#8

USB2

Pin Header

USB3#1+USB#1

USB3#2+USB#2

USB3.2 Rear IO

TypeA

USB3#3+USB2#3

USB3.2 Front IO

TypeA

eSPI BUS

eSPI

Heder

CPU

FAN(4pin)

SIO

NCT5525D

PWM

Hardware

Monitor(+Vcore,+DC in)

Thermal Resistor

(SYS,CPU)

ADC

GPIO

USB

PWR Ctrl

UART(PortA)

3in1

COM transceiver

WDT

(28W)

LAN2

I226LM

PCIe#5(vPro)

2.5G LAN

RJ45

MDIO

Transformer

MDIO

RS-232/422/485

COM

Header

USB3#4+USB2#4

TypeC Conn.

(TBT)

USB4/USB3/DP

TMDS

NUC BOX-1360P/D4

NUC BOX-1340P/D4
