ASROCK AB350M Pro4 Bedienungsanleitung

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per AsRock AB350M

Pro4 o cerca il tuo prodotto tra le migliori offerte di Schede Madri

Version 1.0

Published January 2017

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 10

Chapter 2 Installation 12

2.1 Installing the CPU 13

2.2 Installing the CPU Fan and Heatsink 15

2.3 Installing Memory Modules (DIMM) 24

2.4 Expansion Slots (PCI Express Slots) 26

2.5 Jumpers Setup 27

2.6 Onboard Headers and Connectors 28

2.7 M.2_SSD (NGFF) Module Installation Guide (M2_1) 33

2.8 M.2_SSD (NGFF) Module Installation Guide (M2_2) 36

Chapter 3 Software and Utilities Operation 39

3.1 Installing Drivers 39

3.2 ASRock Live Update & APP Shop 40

3.2.1 UI Overview 40

3.2.2 Apps 41

3.2.3 BIOS & Drivers 44

3.2.4 Setting 45

3.3 ASRock RGB LED 46

Chapter 4 UEFI SETUP UTILITY 48

4.1 Introduction 48

4.1.1 UEFI Menu Bar 48

4.1.2 Navigation Keys 49

4.2 Main Screen 50

4.3 OC Tweaker Screen 51

4.4 Advanced Screen 52

4.4.1 CPU Conguration 53

4.4.2 North Bridge Conguration 54

4.4.3 South Bridge Conguration 55

4.4.4 Storage Conguration 56

4.4.5 Super IO Conguration 57

4.4.6 ACPI Conguration 58

4.4.7 USB Conguration 59

4.4.8 Trusted Computing 60

4.5 Tools 61

4.6 Hardware Health Event Monitoring Screen 63

4.7 Security Screen 64

4.8 Boot Screen 65

4.9 Exit Screen 67

AB350M Pro4

A320M Pro4

English

Chapter 1 Introduction

ank you for purchasing ASRock AB350M Pro4 / A320M Pro4 motherboard,

a reliable motherboard produced under ASRock’s consistently stringent quality

control. It delivers excellent performance with robust design conforming to

ASRock’s commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock AB350M Pro4 / A320M Pro4 Motherboard (Micro ATX Form Factor)

• ASRock AB350M Pro4 / A320M Pro4 Quick Installation Guide

• ASRock AB350M Pro4 / A320M Pro4 Support CD

• 1 x I/O Panel Shield

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 2 x Screws for M.2 Sockets (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this manual will be subject to change without notice. In case any modica-

tions of this manual occur, the updated version will be available on ASRock’s website

without further notice. If you require technical support related to this motherboard,

please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well.

ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Micro ATX Form Factor

• Solid Capacitor design

CPU • Supports AMD Socket AM4 A-Series APUs (Bristol Ridge)

and Ryzen CPUs (Summit Ridge)

• Digi Power design

• 9 Power Phase design

• Supports 95W Air Cooling

Chipset • AMD Promontory B350 (AB350M Pro4)

• AMD Promontory A320 (A320M Pro4)

Memory • Dual Channel DDR4 Memory Technology

• 4 x DDR4 DIMM Slots

• AMD Ryzen series CPUs support DDR4 3200+(OC)/2933

(OC)/2667/2400/2133 ECC & non-ECC, un-buered

memory*

• AMD 7th Gen A-Series APUs support DDR4 2133 ECC &

non-ECC, un-buered memory*

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

* Please refer to page 24 for DDR4 UDIMM maximum frequency

support.

• Max. capacity of system memory: 64GB

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

• 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*

* Supports NVMe SSD as boot disks

* AMD Ryzen series CPUs support PCIE2: x16 mode

* AMD 7th A-Series APUs support PCIE2: x8 mode

• 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode (AB350M Pro4)

/ x2 mode (A320M Pro4))

• 1 x PCI Express 2.0 x1 Slot

AB350M Pro4

A320M Pro4

English

Graphics • Integrated AMD RadeonTM R7/R5 Series Graphics in A-series

APU

• DirectX 12, Pixel Shader 5.0

• Max. shared memory 2GB

• ree graphics output options: D-Sub, DVI-D and HDMI

• Supports Triple Monitor

• Supports HDMI with max. resolution up to 4K x 2K

(4096x2160) @ 24Hz / (3840x2160) @ 30Hz

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP with DVI-D and HDMI Ports

• Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

and HDMI Ports

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

• Premium Blu-ray Audio support

• Supports Surge Protection

• ELNA Audio Caps

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports LAN Cable Detection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

English

Rear Panel

I/O

• 1 x PS/2 Mouse Port

• 1 x PS/2 Keyboard Port

• 1 x D-Sub Port

• 1 x DVI-D Port

• 1 x HDMI Port

• 2 x USB 2.0 Ports (Supports ESD Protection)

• 1 x USB 3.0 Type-C Port (Supports ESD Protection)

• 4 x USB 3.0 Ports (Supports ESD Protection)

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage • 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

RAID 1 and RAID 10), NCQ, AHCI and Hot Plug*

* M2_2 and SATA3_4 share lanes. If either one of them is in use,

the other one will be disabled.

• 1 x Ultra M.2 Socket (M2_1), supports type 2242/2260/2280

M.2 PCI Express module up to Gen3 x4 (32 Gb/s) (with Ryzen

CPU) or Gen3 x2 (16 Gb/s) (with A-Series APU)**

• 1 x M.2 Socket (M2_2), supports type 2230/2242/2260/2280

M.2 SATA3 6.0 Gb/s module**

** Supports NVMe SSD as boot disks

** Supports ASRock U.2 Kit

Connector • 1 x COM Port Header

• 1 x TPM Header

• 1 x Power LED and Speaker Header

• 1 x RGB LED Header

* Supports up to 12V/3A, 36W LED Strip

• 1 x AMD Fan LED Header

• 1 x CPU Fan Connector (4-pin)

* e CPU Fan Connector supports the CPU fan of maximum

1A (12W) fan power.

• 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin) (Smart Fan

Speed Control)

* CHA_FAN1 can auto detect if 3-pin or 4-pin fan is in use.

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x Front Panel Audio Connector

AB350M Pro4

A320M Pro4

English

* For detailed product information, please visit our website: http://www.asrock.com

Please realize that there is a certain risk involved with overclocking, including adjust-

ing the setting in the BIOS, applying Untied Overclocking Technology, or using third-

party overclocking tools. Overclocking may aect your system’s stability, or even cause

damage to the components and devices of your system. It should be done at your own

risk and expense. We are not responsible for possible damage caused by overclocking.

• 1 x AMD LED Fan USB Header (for AB350M Pro4 only)

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD

Protection)

• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD

Protection)

BIOS

Feature

• AMI UEFI Legal BIOS with multilingual GUI support

• Supports “Plug and Play”

• ACPI 5.1 compliance wake up events

• Supports jumperfree

• SMBIOS 2.3 support

• DRAM Voltage multi-adjustment

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis Fan Tachometer

• CPU/Chassis Quiet Fan

• CPU/Chassis Fan multi-speed control

• Voltage monitoring: +12V, +5V, +3.3V, Vcore

OS • Microso® Windows® 10 64-bit

* For the updated Windows® 10 driver, please visit ASRock’s web-

site for details: http://www.asrock.com

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP ready (ErP/EuP ready power supply is required)

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK P55 DELUXE - V1.1 Bedienungsanleitung

ASROCK

ASROCK SP55DE3 - Bedienungsanleitung

ASROCK

ASROCK X300M-STX Bedienungsanleitung

ASROCK

ASROCK A780LM-S - V1.0 Bedienungsanleitung

ASROCK

ASROCK B150M-HDV/D3 Bedienungsanleitung

ASROCK

ASROCK H61M - ANNEXE 392 Bedienungsanleitung

ASROCK

ASROCK B75M-GL R2.0 Bedienungsanleitung

ASROCK

ASROCK H81M-HDS Bedienungsanleitung

ASROCK

ASROCK P67 Pro Bedienungsanleitung

ASROCK

ASROCK B760M-HDV/M.2 D4 Bedienungsanleitung

ASROCK

ASROCK H55M R2.0 Bedienungsanleitung

ASROCK

ASROCK AD2700B-ITX Bedienungsanleitung

ASROCK

ASROCK G43TWINS-FULLHD Bedienungsanleitung

ASROCK

ASROCK P4DUAL-915GL Bedienungsanleitung

ASROCK

ASROCK IMB-110 Bedienungsanleitung

ASROCK

ASROCK A75M Bedienungsanleitung

ASROCK

ASROCK H55DE3 Bedienungsanleitung

ASROCK

ASROCK H61M-DG3/USB3 Bedienungsanleitung

ASROCK

ASROCK EP2C612D16FM Bedienungsanleitung

ASROCK

ASROCK H67DE Bedienungsanleitung

ASROCK

ASROCK IMB-185 Bedienungsanleitung

ASROCK

ASROCK Z370M Pro4 Bedienungsanleitung

ASROCK

ASROCK AM2CPU Bedienungsanleitung

ASROCK

ASROCK Z97 Extreme4 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
