B85M Pro4/ASM

English

Motherboard Layout

Intel

B85

DDR3_A2 (64 bit, 240-pin module)

DDR3_A1 (64 bit, 240-pin module)

DDR3_B2 (64 bit, 240-pin module)

DDR3_B1 (64 bit, 240-pin module)

ATX1 2V 1

CMOS

Battery

Super

I/O

USB 2. 0

T: USB0

B: USB1

PS2

Keyboard

ATXPWR1

USB10_11

LAN

Top:

RJ-45

USB 2.0

T: USB4

B: USB5

Top:

Central/Bass

Center:

REAR SPK

Top:

LIN E IN

Center:

FRONT

Bottom:

Optical

SPDIF

Bottom:

MIC I N

CLRCMOS1

SPEAKER1

IR1

HDLED RESET

PLED PWRBTN

PANEL1

USB6_7

USB8_9

COM1

HD_AUDIO1

B85M Pro4/ASM

SATA_0_1 SATA_2_3 SATA_4_5

CHA_FAN1

CHA_FAN2

PCI1

RoHS

CPU_FAN1

CPU_FAN2

64Mb

BIOS

HDMI1

VGA1

DVI1

PCI2

USB 3. 0

T: USB2

B: USB3

Audio

CODEC

SPDIF1_OUT1

PCIE1

Fast USB

Fast RAM

Fast LAN

PCI Express 3.0

Front USB 3.0

PCIE2

PWR_FAN1

TPMS1

LPT1

CI1

English

No. Description

1 Power Fan Connector (PWR_FAN1)

2 CPU Fan Connector (CPU_FAN2)

3 CPU Fan Connector (CPU_FAN1)

4 ATX 12V Power Connector (ATX12V1)

5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)

6 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)

7 ATX Power Connector (ATXPWR1)

8 USB 3.0 Header (USB10_11)

9 SATA2 Connectors (SATA_4_5)

10 SATA3 Connectors (SATA_2_3)

11 SATA3 Connectors (SATA_0_1)

12 System Panel Header (PANEL1)

13 Chassis Speaker Header (SPEAKER1)

14 Infrared Module Header (IR1)

15 Chassis Fan Connector (CHA_FAN1)

16 USB 2.0 Header (USB8_9)

17 USB 2.0 Header (USB6_7)

18 TPM Header (TPMS1)

19 Chassis Intrusion Header (CI1)

20 Print Port Header (LPT1)

21 COM Port Header (COM1)

22 Clear CMOS Jumper (CLRCMOS1)

23 Front Panel Audio Header (HD_AUDIO1)

24 SPDIF Out Connector (SPDIF_OUT)

25 Chassis Fan Connector (CHA_FAN2)

B85M Pro4/ASM

English

I/O Panel

No. Description No. Description

1 USB 2.0 Ports (USB01) 8 Microphone (Pink)

2 D-Sub Port 9 Optical SPDIF Out Port

3 LAN RJ-45 Port* 10 USB 2.0 Ports (USB_45)

4 Central / Bass (Orange) 11 USB 3.0 Ports (USB_23)

5 Rear Speaker (Black) 12 HDMI Port

6 Line In (Light Blue) 13 DVI-D Port

7 Front Speaker (Lime)** 14 PS/2 Keyboard Port

1 2 3 5

891011121314

English

* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

** If you use a 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See the table below

for connection details in accordance with the type of speaker you use.

Audio Output

Channels

Front Speaker

(No. 7)

Rear Speaker

(No. 5)

Central / Bass

(No. 4)

Line In

(No. 6)

2V -- -- --

4V V -- --

6V V V --

8V V V V

To enable Multi-Streaming, you need to connect a front panel audio cable to the front

panel audio header. Aer restarting your computer, you will nd the “Mixer” tool

on your system. Please select “Mixer ToolBox” , click “Enable playback multi-

streaming”, and click “ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are

allowed to select “Realtek HDA Primary output” to use the Rear Speaker, Central/

Bass, and Front Speaker, or select “Realtek HDA Audio 2nd output” to use the front

panel audio.

ACT/LINK LED

SPEED LED

LAN Port

B85M Pro4/ASM

English

Chapter 1 Introduction

ank you for purchasing ASRock B85M Pro4/ASM motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

1.1 Package Contents

• ASRock B85M Pro4/ASM Motherboard (Micro ATX Form Factor)

• ASRock B85M Pro4/ASM Quick Installation Guide

• ASRock B85M Pro4/ASM Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Micro ATX Form Factor

• All Solid Capacitor design

CPU • Supports 4th Generation Intel® CoreTM i7 / i5 / i3 / Xeon® /

Pentium® / Celeron® in LGA1150 Package

• Digi Power Design

• 4 Power Phase Design

• Supports Intel® Turbo Boost 2.0 Technology

Chipset • Intel® B85

• Supports Intel® Small Business Advantage 2.0

Memory • Dual Channel DDR3 Memory Technology

• 4 x DDR3 DIMM slots

• Supports DDR3 1600/1333/1066 non-ECC, un-buered

memory

• Max. capacity of system memory: 32GB

(see CAUTION)

• Supports Intel® Extreme Memory Prole (XMP)1.3/1.2

Expansion

Slot

• 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)

• 1 x PCI Express 2.0 x16 slot (PCIE2: x4 mode)

• 2 x PCI slots

• Supports AMD Quad CrossFireXTM and CrossFireXTM

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 4600

• Pixel Shader 5.0, DirectX 11.1

• Max. shared memory 1792MB

• ree VGA Output options: D-Sub, DVI-D and HDMI

B85M Pro4/ASM

English

• Supports Triple Monitors

• Supports HDMI Technology with max. resolution up to

1920x1200 @ 60Hz

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required)

• Supports HDCP function with DVI-D and HDMI ports

• Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

and HDMI ports

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

• Premium Blu-ray audio support

LAN • Gigabit LAN 10/100/1000 Mb/s

• Giga PHY Intel® I217V

• Supports Intel® Remote Wake Technology

• Supports Wake-On-LAN

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Keyboard Port

• 1 x D-Sub Port

• 1 x DVI-D Port

• 1 x HDMI Port

• 1 x Optical SPDIF Out Port

• 4 x USB 2.0 Ports

• 2 x USB 3.0 Ports

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front

Speaker / Microphone

Andere Handbücher für B85M Pro4/ASM

Inhaltsverzeichnis

Sprachen:

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK ION 330 - V1.0 Bedienungsanleitung

ASROCK

ASROCK IMB-192 Service-Handbuch

ASROCK

ASROCK IMB-197-D Bedienungsanleitung

ASROCK

ASROCK 890FX Deluxe4 Bedienungsanleitung

ASROCK

ASROCK N68- S Bedienungsanleitung

ASROCK

ASROCK H61M-S1 PLUS Bedienungsanleitung

ASROCK

ASROCK ALIVEXFIRE-ESATA2 R3.0 - Bedienungsanleitung

ASROCK

ASROCK Q1900TM-ITX Bedienungsanleitung

ASROCK

ASROCK A780FULLHD Bedienungsanleitung

ASROCK

ASROCK H510M-HVS R2.0 Bedienungsanleitung

ASROCK

ASROCK Z490 Taichi Bedienungsanleitung

ASROCK

ASROCK 4Core1333-eSATA2 Bedienungsanleitung

ASROCK

ASROCK Z68 Extreme4 Gen3 Bedienungsanleitung

ASROCK

ASROCK Z87 OC Formula ac Bedienungsanleitung

ASROCK

ASROCK H81M-G Bedienungsanleitung

ASROCK

ASROCK H61M - ANNEXE 392 Bedienungsanleitung

ASROCK

ASROCK B75M-DGS R2.0 Bedienungsanleitung

ASROCK

ASROCK IMB-1211-D R2 Bedienungsanleitung

ASROCK

ASROCK 939A790GMH Bedienungsanleitung

ASROCK

ASROCK B250M-HDV Bedienungsanleitung

ASROCK

ASROCK B150 PRO4/D3 Bedienungsanleitung

ASROCK

ASROCK GE PRO-HT Bedienungsanleitung

ASROCK

ASROCK 775Dual-880Pro Bedienungsanleitung

ASROCK

ASROCK H110M-I Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
