ASROCK H61M-ITX Bedienungsanleitung

H61M-ITX

User Manual

Version 1.0

Published May 2012

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction ......................................................... 5

1.1 Package Contents ......................................................... 5

1.2 Specications ................................................................. 6

1.3 Motherboard Layout ....................................................... 12

1.4 I/O Panel ...................................................................... 13

2 Installation ........................................................... 14

2.1 Screw Holes ................................................................... 14

2.2 Pre-installation Precautions ......................................... 14

2.3 CPU Installation ............................................................. 15

2.4 Installation of Heatsink and CPU fan ............................. 17

2.5 Installation of Memory Modules (DIMM) ........................ 18

2.6 Expansion Slot (PCI Express Slot) .................................... 19

2.7 Dual Monitor and Surround Display Features ................ 20

2.8 ASRock Smart Remote Installation Guide ..................... 23

2.9 Jumpers Setup .......................................................... 24

2.10 Onboard Headers and Connectors ............................ 24

2.11 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks

Installation .................................................................. 28

2.12 Hot Plug Function for SATA / SATAII HDDs .................. 28

2.13 SATA / SATAII HDD Hot Plug Feature and Operation

Guide ......................................................................... 29

2.14 Driver Installation Guide ............................................ 31

2.15 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

/ XP / XP 64-bit Without RAID Functions ................... 31

2.15.1 Installing Windows® XP / XP 64-bit Without RAID

Functions............................................................ 31

2.15.2 Installing Windows® 7 / 7 64-bit / VistaTM /

VistaTM 64-bit Without RAID Functions ............... 32

3 UEFI SETUP UTILITY ................................................. 33

3.1 Introduction .................................................................... 33

3.1.1 UEFI Menu Bar .................................................... 33

3.1.2 Navigation Keys ................................................... 34

3.2 Main Screen ................................................................... 34

3.3 OC Tweaker Screen ...................................................... 35

3.4 Advanced Screen ........................................................... 40

3.4.1 CPU Conguration ............................................... 41

3.4.2 North Bridge Conguration................................... 42

3.4.3 South Bridge Conguration .................................. 43

3.4.4 Storage Conguration .......................................... 44

3.4.5 Intel(R) Rapid Start Technology ........................... 45

3.4.6 Intel(R) Smart Connect Technology ..................... 46

3.4.7 Super IO Conguration ........................................ 47

3.4.8 ACPI Conguration............................................... 48

3.4.9 USB Conguration ............................................... 49

3.5 Hardware Health Event Monitoring Screen ................... 50

3.6 Boot Screen ................................................................... 51

3.7 Security Screen ............................................................. 52

3.8 Exit Screen .................................................................... 53

4 Software Support ................................................. 54

4.1 Install Operating System ................................................ 54

4.2 Support CD Information ................................................. 54

4.2.1 Running Support CD ............................................ 54

4.2.2 Drivers Menu ........................................................ 54

4.2.3 Utilities Menu........................................................ 54

4.2.4 Contact Information .............................................. 54

Chapter 1: Introduction

Thank you for purchasing ASRock H61M-ITX motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock H61M-ITX Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock H61M-ITX Quick Installation Guide

ASRock H61M-ITX Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x 3.5mm Audio Cable (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-

bit, it is recommended to set the BIOS option in Storage Conguration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

1.2 Specifications

Platform - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm

- All Solid Capacitor design (100% Japan-made high-quality

Conductive Polymer Capacitors)

CPU - Supports 3rd and 2nd Generation Intel® CoreTM i7 / i5 / i3 in

LGA1155 Package

- Supports Intel® Turbo Boost 2.0 Technology

- Supports K-Series unlocked CPU

- Supports Hyper-Threading Technology (see CAUTION 1)

Chipset - Intel® H61

- Supports Intel® Rapid Start Technology and Smart Connect

Technology

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 2)

- 2 x DDR3 DIMM slots

- Supports DDR3 1600/1333/1066 non-ECC, un-buffered

memory (DDR3 1600 with Intel® Ivy Bridge CPU, DDR3

1333 with Intel® Sandy Bridge CPU)

- Max. capacity of system memory: 16GB (see CAUTION 3)

- Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2 with

Intel® Ivy Bridge CPU

Expansion Slot - 1 x PCI Express 3.0 x16 slot (blue @ x16 mode)

* PCIE 3.0 is only supported with Intel® Ivy Bridge CPU. With

Intel® Sandy Bridge CPU, it only supports PCIE 2.0.

Graphics * Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU

integrated.

- Supports Intel® HD Graphics Built-in Visuals: Intel® Quick

Sync Video 2.0, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 2500/4000

with Intel® Ivy Bridge CPU

- Supports Intel® HD Graphics Built-in Visuals: Intel® Quick

Sync Video, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® HD Graphics 2000/3000, Intel® Advanced

Vector Extensions (AVX) with Intel® Sandy Bridge CPU

- Pixel Shader 5.0, DirectX 11 with Intel® Ivy Bridge CPU.

Pixel Shader 4.1, DirectX 10.1 with Intel® Sandy Bridge

CPU.

- Max. shared memory 1760MB with Intel® Ivy Bridge CPU.

Max. shared memory 1759MB with Intel® Sandy Bridge

CPU. (see CAUTION 4)

- Three VGA Output options: D-Sub, DVI-D and HDMI

(see CAUTION 5)

- Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports DVI with max. resolution up to 1920x1200 @

60Hz

- Supports D-Sub with max. resolution up to 2048x1536 @

75Hz

- Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate

Audio) with HDMI (Compliant HDMI monitor is required)

(see CAUTION 6)

- Supports HDCP function with DVI and HDMI ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with DVI and HDMI ports

Audio - 7.1 CH HD Audio (Realtek ALC887 Audio Codec)

- Supports THX TruStudioTM

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 1 x HDMI Port

- 1 x Optical SPDIF Out Port

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x eSATA2 Connector

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone (see CAUTION 7)

USB 3.0 - 2 x USB 3.0 ports by ASMedia ASM1042, support

USB 1.0/2.0/3.0 up to 5Gb/s

Connector - 3 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

Hot Plug functions

- 1 x CIR header

- 1 x Power LED header

- CPU/Chassis FAN connector

- 24 pin ATX power connector

- 4 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

BIOS Feature - 32Mb AMI BIOS

- AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

Multimedia Suite - OEM

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 8)

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 9)

- ASRock APP Charger (see CAUTION 10)

- ASRock SmartView (see CAUTION 11)

- ASRock XFast USB (see CAUTION 12)

- ASRock XFast LAN (see CAUTION 13)

- ASRock XFast RAM (see CAUTION 14)

- ASRock On/Off Play Technology (see CAUTION 15)

- Hybrid Booster:

- ASRock U-COP (see CAUTION 16)

- Boot Failure Guard (B.F.G.)

- Good Night LED

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis Fan Tachometer

- CPU/Chassis Quiet Fan (Allow Chassis Fan Speed

Auto-Adjust by CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

/ XP / XP 64-bit compliant

Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 17)

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. About the setting of “Hyper Threading Technology”, please check page

40.

2. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 18 for proper installation.

3. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows® 7 /

VistaTM / XP. For Windows® OS with 64-bit CPU, there is no such limita-

tion. You can use ASRock XFast RAM to utilize the memory that Win-

dows® cannot use.

4. The maximum shared memory size is dened by the chipset vendor and

is subject to change. Please check Intel® website for the latest informa-

tion.

5. You can choose to use two of the four monitors only. D-Sub, DVI-D and

HDMI monitors cannot be enabled at the same time. Besides, with the

DVI-to-HDMI adapter, the DVI-D port can support the same features as

HDMIport.

6. xvYCC is only supported under Windows® 7 64-bit / 7. HBR is supported

under Windows® 7 64-bit / 7 / VistaTM 64-bit / VistaTM.

7. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 13

for proper connection.

8. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune

different system functions in a user-friendly interface, which is including

Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In

Hardware Monitor, it shows the major readings of your system. In Fan

Control, it shows the fan speed and temperature for you to adjust. In

Overclocking, you are allowed to overclock CPU frequency for optimal

system performance. In OC DNA, you can save your OC settings as a

prole and share with your friends. Your friends then can load the OC

prole to their own system to get the same OC settings. In IES (Intelligent

Energy Saver), the voltage regulator can reduce the number of output

WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or

using the third-party overclocking tools. Overclocking may affect your system

stability, or even cause damage to the components and devices of your system.

It should be done at your own risk and expense. We are not responsible for possible

damage caused by overclocking.

phases to improve efciency when the CPU cores are idle without

sacrificing computing performance. Please visit our website for the

operation procedures of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

9. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems rst like MS-DOS or Windows®. With

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool

and save the new BIOS le to your USB ash drive, oppy disk or hard

drive, then you can update your BIOS only in a few clicks without prepar-

ing an additional oppy diskette or other complicated ash utility. Please

be noted that the USB ash drive or hard drive must use FAT32/16/12 le

system.

10. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful

solution for you - ASRock APP Charger. Simply installing the APP Char-

ger driver, it makes your iPhone charged much quickly from your com-

puter and up to 40% faster than before. ASRock APP Charger allows you

to quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP

Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

11. SmartView, a new function of internet browser, is the smart start page for

IE that combines your most visited web sites, your history, your Facebook

friends and your real-time newsfeed into an enhanced view for a more

personal Internet experience. ASRock motherboards are exclusively

equipped with the SmartView utility that helps you keep in touch with

friends on-the-go. To use SmartView feature, please make sure your

OS version is Windows® 7 / 7 64 bit / VistaTM / VistaTM 64 bit, and your

browser version is IE8. ASRock website: http://www.asrock.com/Feature/

SmartView/index.asp

12. ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

13. ASRock XFast LAN provides a faster internet access, which includes

below benefits. LAN Application Prioritization: You can configure your

application priority ideally and/or add new programs. Lower Latency in

Game: After setting online game priority higher, it can lower the latency in

game. Trafc Shaping: You can watch Youtube HD video and download

les simultaneously. Real-Time Analysis of Your Data: With the status

window, you can easily recognize which data streams you are currently

transferring.

Andere Handbücher für H61M-ITX

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK N68-S3 Bedienungsanleitung

ASROCK

ASROCK J3160DC-ITX Bedienungsanleitung

ASROCK

ASROCK Z270M-STX MXM Bedienungsanleitung

ASROCK

ASROCK AD425PV3 Bedienungsanleitung

ASROCK

ASROCK 4CORE1600-GLAN - V1.0 Bedienungsanleitung

ASROCK

ASROCK Fatal1ty Z68 Professional Gen3 Bedienungsanleitung

ASROCK

ASROCK 785GM-GS3 - V1.0 Bedienungsanleitung

ASROCK

ASROCK Fatal1ty B85 Killer Bedienungsanleitung

ASROCK

ASROCK SIS741GX-NB Bedienungsanleitung

ASROCK

ASROCK Fatality X370 Bedienungsanleitung

ASROCK

ASROCK PV530A Bedienungsanleitung

ASROCK

ASROCK FM2A75M-DGS R2.0 Bedienungsanleitung

ASROCK

ASROCK A55M-VS Bedienungsanleitung

ASROCK

ASROCK P55 DELUXE3 - Bedienungsanleitung

ASROCK

ASROCK Z170A-X1/3.1 Bedienungsanleitung

ASROCK

ASROCK Z77 Extreme6 Bedienungsanleitung

ASROCK

ASROCK P4I65PE Bedienungsanleitung

ASROCK

ASROCK Rack E3C224D4M-16RE Bedienungsanleitung

ASROCK

ASROCK IMB-185 Service-Handbuch

ASROCK

ASROCK FM2A78M Pro3+ Bedienungsanleitung

ASROCK

ASROCK Fatal1ty B450 Bedienungsanleitung

ASROCK

ASROCK M3A785GMH/128M Bedienungsanleitung

ASROCK

ASROCK 775VM800 Bedienungsanleitung

ASROCK

ASROCK 939A790GMH Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
