1
H61MV-ITX
User Manual
Version 1.0
Published November 2012
Copyright©2012 ASRock INC. All rights reserved.
2
Copyright Notice:
No part of this manual may be reproduced, transcribed, transmitted, or translated in
any language, in any form or by any means, except duplication of documentation by
the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this manual may or may not be regis-
tered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specications and information contained in this manual are furnished for informa-
tional use only and subject to change without notice, and should not be constructed
as a commitment by ASRock. ASRock assumes no responsibility for any errors or
omissions that may appear in this manual.
With respect to the contents of this manual, ASRock does not provide warranty of
any kind, either expressed or implied, including but not limited to the implied warran-
ties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock, its directors, ofcers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from
any defect or error in the manual or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic
substance controlled in Perchlorate Best Management Practices (BMP) regulations
passed by the California Legislature. When you discard the Lithium battery in Cali-
fornia, USA, please follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate”
ASRock Website: http://www.asrock.com
3
Contents
1 Introduction ........................................................ 5
1.1 Package Contents ......................................................... 5
1.2 Specications ................................................................. 6
1.3 Unique Features ............................................................ 10
1.4 Motherboard Layout ....................................................... 14
1.5 I/O Panel ...................................................................... 15
2 Installation .......................................................... 16
2.1 Screw Holes ................................................................... 16
2.2 Pre-installation Precautions ......................................... 16
2.3 CPU Installation ............................................................. 17
2.4 Installation of Heatsink and CPU fan ............................. 19
2.5 Installation of Memory Modules (DIMM) ........................ 20
2.6 Expansion Slot (PCI Express Slot) .................................... 21
2.7 Dual Monitor and Surround Display Features ................ 22
2.8 ASRock Smart Remote Installation Guide ..................... 25
2.9 Jumpers Setup .......................................................... 27
2.10 Onboard Headers and Connectors ............................ 28
2.11 Serial ATA (SATA) / Serial ATA2 (SATA2) Hard Disks
Installation .................................................................. 32
2.12 Hot Plug Function for SATA / SATA2 HDDs .................. 32
2.13 SATA / SATA2 HDD Hot Plug Feature and Operation
Guide ......................................................................... 33
2.14 Driver Installation Guide ............................................ 35
2.15 Installing Windows® 8 / 8 64-bit / 7 / 7 64-bit / VistaTM /
VistaTM 64-bit / XP / XP 64-bit Without RAID Functions . 35
2.15.1 Installing Windows® XP / XP 64-bit Without RAID
Functions............................................................ 35
2.15.2 Installing Windows® 8 / 8 64-bit / 7 / 7 64-bit /
VistaTM / VistaTM 64-bit Without RAID Functions . 36
2.16 ASRock XFast 555 ..................................................... 37
2.16.1 ASRock XFast RAM ........................................... 38
2.16.2 ASRock XFast LAN ............................................ 41
2.16.3 ASRock XFast USB............................................ 45
4
3 UEFI SETUP UTILITY .......................................... 47
3.1 Introduction .................................................................... 47
3.1.1 UEFI Menu Bar .................................................... 47
3.1.2 Navigation Keys ................................................... 48
3.2 Main Screen ................................................................... 48
3.3 OC Tweaker Screen ...................................................... 49
3.4 Advanced Screen ........................................................... 53
3.4.1 CPU Conguration ............................................... 54
3.4.2 North Bridge Conguration................................... 56
3.4.3 South Bridge Conguration .................................. 57
3.4.4 Storage Conguration .......................................... 58
3.4.5 Intel(R) Rapid Start Technology ........................... 59
3.4.6 Intel(R) Smart Connect Technology ..................... 60
3.4.7 ACPI Conguration............................................... 61
3.4.8 USB Conguration ............................................... 62
3.5 Tool ................................................................................ 63
3.6 Hardware Health Event Monitoring Screen ................... 65
3.7 Boot Screen ................................................................... 66
3.8 Security Screen ............................................................. 68
3.9 Exit Screen .................................................................... 69
4 Software Support ............................................... 70
4.1 Install Operating System ................................................ 70
4.2 Support CD Information ................................................. 70
4.2.1 Running Support CD ............................................ 70
4.2.2 Drivers Menu ........................................................ 70
4.2.3 Utilities Menu........................................................ 70
4.2.4 Contact Information .............................................. 70
5
Chapter 1: Introduction
Thank you for purchasing ASRock H61MV-ITX motherboard, a reliable motherboard
produced under ASRock’s consistently stringent quality control. It delivers excellent
performance with robust design conforming to ASRock’s commitment to quality and
endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration
guide to BIOS setup and information of the Support CD.
Because the motherboard specications and the BIOS software might be
updated, the content of this manual will be subject to change without no-
tice. In case any modications of this manual occur, the updated version
will be available on ASRock website without further notice. You may nd
the latest VGA cards and CPU support lists on ASRock website as well.
ASRock website http://www.asrock.com
If you require technical support related to this motherboard, please visit
our website for specic information about the model you are using.
www.asrock.com/support/index.asp
1.1 Package Contents
ASRock H61MV-ITX Motherboard (Mini-ITX Form Factor)
ASRock H61MV-ITX Quick Installation Guide
ASRock H61MV-ITX Support CD
2 x Serial ATA (SATA) Data Cables (Optional)
1 x I/O Panel Shield
ASRock Reminds You...
To get better performance in Windows® 8 / 8 64-bit / 7 / 7 64-bit / VistaTM /
VistaTM 64-bit, it is recommended to set the BIOS option in Storage Con-
guration to AHCI mode.
6
1.2 Specications
Platform - Mini-ITX Form Factor
- All Solid Capacitor design
CPU - Supports 3rd and 2nd Generation Intel® CoreTM i7 / i5 / i3 in
LGA1155 Package
- Supports Intel® Turbo Boost 2.0 Technology
- Supports K-Series unlocked CPU
Chipset - Intel® H61
- Supports Intel® Rapid Start Technology and Smart Connect
Technology
Memory - Dual Channel DDR3 Memory Technology
- 2 x DDR3 DIMM slots
- Supports DDR3 1600/1333/1066 non-ECC, un-buffered
memory (DDR3 1600 with Intel® Ivy Bridge CPU, DDR3
1333 with Intel® Sandy Bridge CPU)
- Max. capacity of system memory: 16GB (see CAUTION 1)
- Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2 with
Intel® Ivy Bridge CPU
Expansion Slot - 1 x PCI Express 3.0 x16 slot (PCIE1 @ x16 mode)
* PCIE 3.0 is only supported with Intel® Ivy Bridge CPU. With
Intel® Sandy Bridge CPU, it only supports PCIE 2.0.
Graphics * Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU
integrated.
- Supports Intel® HD Graphics Built-in Visuals: Intel® Quick
Sync Video 2.0, Intel® InTruTM 3D, Intel® Clear Video HD
Technology, Intel® InsiderTM, Intel® HD Graphics 2500/4000
with Intel® Ivy Bridge CPU
- Supports Intel® HD Graphics Built-in Visuals: Intel® Quick
Sync Video, Intel® InTruTM 3D, Intel® Clear Video HD
Technology, Intel® HD Graphics 2000/3000, Intel® Advanced
Vector Extensions (AVX) with Intel® Sandy Bridge CPU
- Pixel Shader 5.0, DirectX 11 with Intel® Ivy Bridge CPU.
Pixel Shader 4.1, DirectX 10.1 with Intel® Sandy Bridge
CPU.
- Max. shared memory 1760MB with Intel® Ivy Bridge CPU.
Max. shared memory 1759MB with Intel® Sandy Bridge
CPU.
- Dual VGA Output: support HDMI and D-Sub ports by
independent display controllers
7
- Supports HDMI 1.4a Technology with max. resolution up to
1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @
75Hz
- Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate
Audio) with HDMI (Compliant HDMI monitor is required)
(see CAUTION 2)
- Supports HDCP function with HDMI port
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
with HDMI port
Audio - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Efcient Ethernet 802.3az
- Supports PXE
Rear Panel I/O I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x D-Sub Port
- 1 x HDMI Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector - 4 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and
Hot Plug functions
- 1 x CIR header
- 1 x HDMI_SPDIF header
- 1 x Chassis Intrusion header
- 1 x CPU Fan connectors (4-pin)
- 1 x Chassis Fan connector (3-pin)
- 24 pin ATX power connector
- 4 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature - 32Mb AMI UEFI Legal BIOS with GUI support
- Supports “Plug and Play”
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
8
- SMBIOS 2.3.1 Support
Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),
CyberLink MediaEspresso 6.5 Trial, Google Chrome
Browser and Toolbar
Hardware - CPU Temperature Sensing
Monitor - Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU Fan Multi-Speed Control
- CASE OPEN detection
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS - Microsoft® Windows® 8 / 8 64-bit / 7 / 7 64-bit / VistaTM /
VistaTM 64-bit / XP / XP 64-bit compliant
Certications - FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
* For detailed product information, please visit our website: http://www.asrock.com
WARNING
Please realize that there is a certain risk involved with overclocking,
including adjusting the setting in the BIOS, applying Untied Overclocking
Technology, or using third-party overclocking tools. Overclocking may
affect your system’s stability, or even cause damage to the components
and devices of your system. It should be done at your own risk and
expense. We are not responsible for possible damage caused by
overclocking.
9
CAUTION!
1. Due to the operating system limitation, the actual memory size
may be less than 4GB for the reservation for system usage
under Windows® 8 / 7 / VistaTM / XP. For Windows® OS with 64-
bit CPU, there is no such limitation. You can use ASRock XFast
RAM to utilize the memory that Windows® cannot use.
2. xvYCC is only supported under Windows® 8 64-bit / 8 / 7 64-bit
/ 7. HBR is supported under Windows® 8 64-bit / 8 / 7 64-bit / 7 /
VistaTM 64-bit / VistaTM.
10
1.3 Unique Features
ASRock Extreme Tuning Utility (AXTU)
ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to
ne-tune different system functions in a user-friendly interface,
which includes Hardware Monitor, Fan Control and XFast RAM.
In Hardware Monitor, it shows the major readings of your sys-
tem. In Fan Control, it shows the fan speed and temperature for
you to adjust. In XFast RAM, it fully utilizes the memory space
that cannot be used under Windows® OS 32-bit CPU.
ASRock Instant Boot
ASRock Instant Boot allows you to turn on your PC in just a few
seconds, provides a much more efcient way to save energy,
time, money, and improves system running speed for your sys-
tem. It leverages the S3 and S4 ACPI features which normally
enable the Sleep/Standby and Hibernation modes in Windows®
to shorten boot up time. By calling S3 and S4 at specic timing
during the shutdown and startup process, Instant Boot allows
you to enter your Windows® desktop in a few seconds.
ASRock Instant Flash
ASRock Instant Flash is a BIOS ash utility embedded in Flash
ROM. This convenient BIOS update tool allows you to update
system BIOS without entering operating systems rst like MS-
DOS or Windows®. With this utility, you can press the <F6> key
during the POST or the <F2> key to enter into the BIOS setup
menu to access ASRock Instant Flash. Just launch this tool and
save the new BIOS le to your USB ash drive, oppy disk or
hard drive, then you can update your BIOS only in a few clicks
without preparing an additional oppy diskette or other compli-
cated ash utility. Please be noted that the USB ash drive or
hard drive must use FAT32/16/12 le system.
Andere Handbücher für H61MV-ITX
1
Inhaltsverzeichnis
Andere ASROCK Hauptplatine Handbücher
ASROCK
ASROCK A55iCafe Bedienungsanleitung
ASROCK
ASROCK G41M-VGS3 Bedienungsanleitung
ASROCK
ASROCK H110M-DS/Hyper Bedienungsanleitung
ASROCK
ASROCK ALIVENF5-VST Bedienungsanleitung
ASROCK
ASROCK E3C240D4U2-2L2T Bedienungsanleitung
ASROCK
ASROCK B550 EXTREME4 Bedienungsanleitung
ASROCK
ASROCK Z97 Anniversary Bedienungsanleitung
ASROCK
ASROCK AD525PV Bedienungsanleitung
ASROCK
ASROCK B760M-HDV/M.2 Bedienungsanleitung
ASROCK
ASROCK FM2A88M+ BTC Bedienungsanleitung
ASROCK
ASROCK H61M-GE Bedienungsanleitung
ASROCK
ASROCK 4X4-4800U Bedienungsanleitung
ASROCK
ASROCK Z77M Bedienungsanleitung
ASROCK
ASROCK Fatal1ty Z68 Professional Gen3 Bedienungsanleitung
ASROCK
ASROCK B150TM-ITX TPM R2.0 Bedienungsanleitung
ASROCK
ASROCK P4I45D Bedienungsanleitung
ASROCK
ASROCK B450M-HDV R4.0 Bedienungsanleitung
ASROCK
ASROCK P43 PRO USB3 Bedienungsanleitung
ASROCK
ASROCK P4I65GV Bedienungsanleitung
ASROCK
ASROCK AM1H-ITX Bedienungsanleitung
Beliebte Hauptplatine Handbücher anderer Marken
Gigabyte
Gigabyte GA-9IVDT Bedienungsanleitung
Texas Instruments
Texas Instruments ADS8372EVM Bedienungsanleitung
Commell
Commell MS-C73 Bedienungsanleitung
IBT Technologies
IBT Technologies MB860 Bedienungsanleitung
Nvidia
Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung
Biostar
Biostar M7VIT Bravo Bedienungs- und Montageanleitung
