ASROCK IMB-192 Bedienungsanleitung

IMB-192

User Manual

Version 1.0

Published July 2017

Version 1.0

Published July 2017

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

CAUTION:

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

1 Introduction ....................................................... 5

1.1 Package Contents ......................................................... 5

1.2 Specications................................................................. 6

1.3 Motherboard Layout....................................................... 8

1.4 I/O Panel........................................................................ 10

2 Installation ......................................................... 11

2.1 Screw Holes................................................................... 11

2.2 Pre-installation Precautions ........................................... 11

2.3 Installation of Memory Modules (SO-DIMM).................. 12

2.4 Expansion Slots ............................................................ 13

2.5 Jumpers Setup............................................................... 14

2.6 Onboard Headers and Connectors................................ 16

3 UEFI SETUP UTILITY......................................... 21

3.1 Introduction .................................................................... 21

3.1.1 UEFI Menu Bar .................................................... 21

3.1.2 Navigation Keys ................................................... 22

3.2 Main Screen................................................................... 22

3.3 Advanced Screen........................................................... 23

3.3.1 CPU Conguration ............................................... 24

3.3.2 Chipset Conguration........................................... 26

3.3.3 Storage Conguration .......................................... 28

3.3.4 Super IO Conguration ........................................ 29

3.3.5 ACPI Conguration............................................... 30

3.3.6 USB Conguration ............................................... 31

3.3.7 Trusted Computing............................................... 32

3.4 Hardware Health Event Monitoring Screen ................... 33

3.5 Security Screen ............................................................. 34

3.6 Boot Screen ................................................................... 35

3.7 Exit Screen .................................................................... 37

4 Software Support .............................................. 38

4.1 Install Operating System................................................ 38

4.2 Support CD Information ................................................. 38

4.2.1 Running Support CD ............................................ 38

4.2.2 Drivers Menu........................................................ 38

4.2.3 Utilities Menu........................................................ 38

4.2.4 Contact Information.............................................. 38

Chapter 1: Introduction

Thank you for purchasing ASRock IMB-192 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock IMB-192 Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock IMB-192 Driver CD

ASRock IMB-192 Jumper setting instruction

1 x I/O Panel Shield

1.2 Specications

Form

Factor Dimensions Mini-ITX (6.7-in x 6.7-in)

Processor

System

CPU Socket LGA1151 for Intel®Core i7 / i5 / i3 /

Pentium®/ Celeron®(Skylake)

Core

Number (By CPU, Max 4)

Max Speed (By CPU)

L3 Cache (By CPU)

Chipset Intel®H110

BIOS UEFI

Expansion

Slot

PCIe 1 x PCI Express 3.0 x 4 Slot

Mini-PCIe 0

mSATA 0

M.2

1 x M.2 Socket (Key E), supports type 2230

WiFi/BT module

1 x M.2 Socket (Key M), supports type

2242/2260 (SATA only)

Memory

Technology Dual Channel DDR4 2133 MHz

Max. 32GB

Socket 2 x SO-DIMM

Graphics

Controller Intel®HD Graphics 510/530

VRAM Shared Memory

VGA Supports max resolution up to 1920x1200 @

60Hz

DVI No

LVDS Supports max resolution up to 1920 x

1200@60Hz @ 60Hz

HDMI Supports max resolution up to 4K x 2K

(4096x2160) @ 24Hz /(3840x2160) @ 30Hz

DisplayPort No

Multi Display Dual

Ethernet

Ethernet 10/100/1000 Mbps

Controller 1 x Intel®I219V

Connector 1 x RJ-45

SATA

Max Data

Transfer

Rate

SATA3 (6.0Gb/s)

Rear I/O

VGA 1

DVI 0

HDMI 1

DisplayPort 0

Ethernet 1

USB 4 x USB 3.0

Audio 2 (Mic-in, Line-out)

Serial 0

PS/2 0

Internal

Connector

USB 5 x USB 2.0 (2 x 2.54 pitch header, 1 x

Type A)

LVDS/

inverter 1/1

VGA 0

Serial 2 x 2.0 pitch header RS-232

SATA 2 x SATA3 (6.0Gb/s)

mPCIe 0

Parallel 0

mSATA 0

IrDA 0

GPIO 8-bit 0

SATA PWR

Output Con 1

Speaker

Header 1

Watchdog

Timer

Output From Super I/O to drag RESETCON#

Interval 256 segments, 0,1,2…255sec/min

Power

Requirements

Input PWR 19V phone jack DC-In

Power On

AT/ATX Supported

AT : Directly PWR on as power input ready

ATX : Press button to PWR on after power

input ready

Environment Temperature 0ºC – 60ºC

1.3 Motherboard Layout

Mic In

BIOS

Chip

USB2_1_2

HD_AUDIO1

CHA_FAN1

PCIE1

DC_JACK1

LVDS1

LPC1

CLRMOS1

USB 3.0

T: USB1

B: USB2

Line Out

TO_UPS1

BLT_CTL1

PANEL1

HDLED RESET

PLED PWRBTN

COM2

COM1

M2_2

SATA3_0 SATA3_1

LAN1

HDMI1

SPEAKER1

Industrial

BUZZ2

VGA1

USB 3.0

T: USB3

B: USB4

MONITOR_SWITCH1

BL1

Bl2

SATA_POW1

PNL_PWR1

BKT_PWR1

PWR_COM1

USB2_4_5

SPDIF1

CI1

CI2

BKT_CON1

CPU_FAN1

PWR_JP1

CLRMOS2

IMB-192

24567810

22 19

PWR_COM2

1 : Clear CMOS Header

2 : 2-pin UPS Module Power Input Connector

3 : M.2 (Key-M)

4 :

USB2.0 Header

(USB2_1_2)

5 :

USB2.0 Port

6 :

4-Pin Chassis FAN Connector (+12V)

7 : SATA3 Connectors (SATA3_0, SATA3_1)

8 : Monitor Switch Header

9 : SATA Power Output Connector

10 : Backlight Control (BLT_CTL1)

11 :

System Panel Header

12 : BL1, BL2

13 :

Panel Power Select (PNL_PWR1)

14 : Backlight Power Select (BKT_PWR1)

15 : LVDS Panel Connector

16 : COM Port Pin9 PWR Setting Jumpers

PWR_COM1 (For COM Port1)

PWR_COM2 (For COM Port2)

17 : COM Port Headers (COM1, COM2) (RS232)

18 :

USB2.0 Header

(USB2_4_5)

19 :

4-Pin CPU FAN Connector (+12V)

20 : Clear CMOS Jumper

21 : LPC Header

22 : ATX/AT Mode Jumper (PWR_JP1)

23 :

Front Panel Audio Header

24 : Buzzer

25 : SPDIF Header

26 : 3W Audio AMP Output Wafer

27 : Chassis Intrusion Headers

(CI1, CI2)

28 : M.2 (Key-E)

29 : Backlight Control Select (BKT_CON1)

1.4 I/O Panel

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

indications.

LAN Port LED Indications

Activity/Link LED SPEED LED

Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

ACT/LINK

LED

SPEED

LED

LAN Port

1 DC Jack

2 D-Sub Port (VGA1)

3 USB 3.0 Ports (USB3_1_2)

4 HDMI Port (HDMI1)

5 LAN RJ-45 Port*

6 USB 3.0 Ports (USB3_3_4)

7 Microphone (Pink)

8 Line out (Lime)

124

358

Andere Handbücher für IMB-192

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK A75 Extreme6 Bedienungsanleitung

ASROCK

ASROCK M3A760GMH Bedienungsanleitung

ASROCK

ASROCK P55 EXTREME Bedienungsanleitung

ASROCK

ASROCK PHANTOM GAMING Z790M PC LIGHTNING/D4 Bedienungsanleitung

ASROCK

ASROCK H470M-HVS R2.0 Bedienungsanleitung

ASROCK

ASROCK Z390 Phantom Gaming 9 Bedienungsanleitung

ASROCK

ASROCK G41MH-LE3 Bedienungsanleitung

ASROCK

ASROCK FM2A88M-DG3+ Bedienungsanleitung

ASROCK

ASROCK M3A790GXH/128M Bedienungsanleitung

ASROCK

ASROCK A520M-HDVP 2.0 Bedienungsanleitung

ASROCK

ASROCK H67DE3 Bedienungsanleitung

ASROCK

ASROCK K7S8X - VERSION 3.1 Bedienungsanleitung

ASROCK

ASROCK WOLFDALE1333-GLAN/M Bedienungsanleitung

ASROCK

ASROCK Z75 Pro3 Bedienerhandbuch

ASROCK

ASROCK Fatal1ty Z87 Killer Series Bedienungsanleitung

ASROCK

ASROCK Fatal1ty X99 Professional Series Bedienungsanleitung

ASROCK

ASROCK Fatal1ty AB350 Gaming K4 Bedienungsanleitung

ASROCK

ASROCK B450M-HDV R4.0 Bedienungsanleitung

ASROCK

ASROCK H61M-GS Bedienungsanleitung

ASROCK

ASROCK X570 PHANTOM GAMING 4 Bedienungsanleitung

ASROCK

ASROCK QC5000M-ITX/PH Bedienungsanleitung

ASROCK

ASROCK Fatal1ty B150 Gaming K4 Bedienungsanleitung

ASROCK

ASROCK CML-HDV/M.2 TPM Bedienungsanleitung

ASROCK

ASROCK IMB-A1000 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
