ASROCK X99 WS-E Bedienungsanleitung

Version 1.0

Published August 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

English

X99 Extreme6

Motherboard Layout

Intel

X99

ATX12V1

Supe r

I/O

ATXPWR1

USB3_5_ 6

LAN

PCIE1

Top:

Central/Bass

Center:

REAR SPK

Top:

LINE IN

Center:

FRONT

Bottom:

Optical

SPDIF

Bottom:

MIC IN

PCIE3

PLED1

SPEAKER1

HDLED RESET

PLED PWRBTN

PANEL1

USB5_6

USB3_4

COM1

HD_AUDIO1

X99 Extreme6

PCIE5

SSATA3_ 2_ 3

SATA3 _0 _3

SATA3 _1 _4

SATA3 _2 _5

PCIE2

CHA_FAN1

CPU_FAN1

CPU_FAN2

PWR_FAN1

RoHS

273233

CLRC

BTN1

ESATA1

Top:

RJ-45

USB 3.0

T: USB3

B: USB4

SSATA3_ 0_ 1

346

DDR4_A2 (64 bit, 284-pin module)

DDR4_A1 (64 bit, 284-pin module)

DDR4_B2 (64 bit, 284-pin module)

DDR4_B1 (64 bit, 284-pin module)

Purity

Sound 2

Ultra M.2

PCIe Gen3 x4

BIOS_B_LED

128Mb

BIOS

BIOS_B

128Mb

BIOS

BIOS_A

BIOS_A_LED

TPMS1

CMOS

Battery

CLRMOS1

CT2CT3CT4CT5

T BT1

CHA_FAN2

CHA_FAN3

PCIE_PWR1

SATA_PWR_1

CT1

DDR4_D1 (64 bit, 284-pin module)

DDR4_D2 (64 bit, 284-pin module)

DDR4_C1 (64 bit, 284-pin module)

DDR4_C2 (64 bit, 284-pin module)

USB 3.0

T: USB1

B: USB2

2011-3 Socket

Vertical

Type A USB

USB7

USB3_7_ 8

Dr.

Debug

Reset Power

24 23

BIO S_ SEL 1

PCIE4

MINI_PCIE1

USB 2.0

T: USB1

B: USB2

PS2

Keyboard

/Mouse

Top:

RJ-45

USB 3.0

T: USB1

B: USB2

English

No. Description

1 2 x 284-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)

2 2 x 284-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)

3 ATX 12V Power Connector (ATX12V1)

4 CPU Fan Connector (CPU_FAN1)

5 2 x 284-pin DDR4 DIMM Slots (DDR4_D2, DDR4_C2)

6 CPU Fan Connector (CPU_FAN2)

7 2 x 284-pin DDR4 DIMM Slots (DDR4_D1, DDR4_C1)

8 Vertical Type A USB 2.0 (USB7)

9 ATX Power Connector (ATXPWR1)

10 USB 3.0 Header (USB3_7_8)

11 USB 3.0 Header (USB3_5_6)

12 Chassis Fan Connector (CHA_FAN3)

13 SATA3 Connectors (SSATA3_0_1)

14 SATA3 Connectors (SSATA3_2_3)

15 SATA3 Connectors (SATA3_0_3)

16 SATA3 Connectors (SATA3_1_4)

17 SATA3 Connectors (SATA3_2_5)

18 Power LED Header (PLED1)

19 Chassis Speaker Header (SPEAKER1)

20 System Panel Header (PANEL1)

21 Power Switch (PWRBTN1)

22 HDD Saver Connector (SATA_PWR_1)

23 Reset Switch (RSTBTN1)

24 Chassis Fan Connector (CHA_FAN2)

25 Chassis Fan Connector (CHA_FAN1)

26 USB 2.0 Header (USB3_4)

27 USB 2.0 Header (USB5_6)

28 BIOS Selection Switch (BIOS_SEL1)

29 Clear CMOS Jumper (CLRCMOS1)

30 COM Port Header (COM1)

31 underbolt AIC Connector (TBT1)

32 TPM Header (TPMS1)

33 Front Panel Audio Header (HD_AUDIO1)

English

X99 Extreme6

No. Description

34 PCIe Power Connector (PCIE_PWR1)

35 Power Fan Connector (PWR_FAN1)

English

1.4 I/O Panel

No. Description No. Description

1 USB 2.0 Ports (USB12) 9 Optical SPDIF Out Port

2 LAN RJ-45 Port 10 USB 3.0 Ports (USB3_34)

(Qualcomm® Atheros® AR8171)* (ASMedia ASM1074 hub)

3 LAN RJ-45 Port 11 USB 3.0 Ports (USB3_12)

(Intel® I218V)* (ASMedia ASM1074 hub)

4 Central / Bass (Orange) 12 eSATA Connector***

5 Rear Speaker (Black) 13 USB 3.0 Ports (USB31_12)

6 Line In (Light Blue) (ASMedia ASM1042)

7 Front Speaker (Lime)** 14 Clear CMOS Switch

8Microphone (Pink) 15 PS/2 Mouse/Keyboard Port

CAUTION:

For operating system installation, be sure to plug your USB ash drive into the USB 2.0

Ports (USB12).

15 891011121314

32 5

English

X99 Extreme6

* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

** If you use a 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See the table below

for connection details in accordance with the type of speaker you use.

Audio Output

Channels

Front Speaker

(No. 7)

Rear Speaker

(No. 5)

Central / Bass

(No. 4)

Line In

(No. 6)

2V -- -- --

4V V -- --

6V V V --

8V V V V

*** e eSATA connector supports SATA with cables within 1 meters. e SSATA3_3 connector is

shared with the eSATA port

To enable Multi-Streaming, you need to connect a front panel audio cable to the front

panel audio header. Aer restarting your computer, you will nd the “Mixer” tool on your

system. Please select “Mixer ToolBox” , click “Enable playback multi-streaming”, and

click “ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select

“Realtek HDA Primary output” to use the Rear Speaker, Central/Bass, and Front Speaker,

or select “Realtek HDA Audio 2nd output” to use the front panel audio.

ACT/LINK LED

SPEED LED

LAN Port

English

Chapter 1 Introduction

ank you for purchasing ASRock X99 Extreme6 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

1.1 Package Contents

•ASRock X99 Extreme6 Motherboard (ATX Form Factor)

•ASRock X99 Extreme6 Quick Installation Guide

•ASRock X99 Extreme6 Support CD

•1 x I/O Panel Shield

•1 x ASRock SLI_Bridge_2S Card

•1 x ASRock 3-Way SLI-2S1S Bridge Card

•4 x Serial ATA (SATA) Data Cables (Optional)

•1 x HDD Saver Cable

•1 x Screw for Ultra M.2 Socket

•1 x Screw for mini-PCIe Slot

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

English

X99 Extreme6

1.2 Specications

Platform •ATX Form Factor

•2oz Copper PCB

•High Density Glass Fabric PCB

•Multiple Filter Cap (MFC) (Filter dierent noise by 3

dierent capacitors: DIP solid cap, POSCAP and MLCC)

CPU •Supports Intel® CoreTM i7 and Xeon® 18-Core Processors

Family for the LGA 2011-3 Socket

•Digi Power design

•12 Power Phase design

•Supports Intel® Turbo Boost 2.0 Technology

•Supports Untied Overclocking Technology

Chipset •Intel® X99

Memory •Quad Channel DDR4 Memory Technology

•8 x DDR4 DIMM Slots

•Supports DDR4 3000+(OC)*/2933+(OC)/2800(OC)/2400

(OC)/2133/1866/ 1600/1333/1066 non-ECC, un-buered

memory

* Please refer to Memory Support List on ASRock's website for

more information. (http://www.asrock.com/)

•Supports non-ECC RDIMM (Registered DIMM)

•Supports DDR4 ECC, un-buered memory/RDIMM with

Intel® Xeon® processors E5 series in the LGA 2011-3 Socket

•Max. capacity of system memory: 128GB (see CAUTION)

•Supports Intel® Extreme Memory Prole (XMP) 2.0

Expansion

Slot

•3 x PCI Express 3.0 x16 Slots (PCIE1 @ x16 mode; PCIE3 @

x16 mode; PCIE5 @ x8 mode)

* If you install CPU with 28 lanes, PCIE1/PCIE3/PCIE5 will run

at x16/x8/x4.

* If M.2 PCI Express module is installed, PCIE5 will be disabled.

•2 x PCI Express 2.0 x1 Slots

•1 x mini-PCI Express Slot

•Supports AMD Quad CrossFireXTM, 3-Way CrossFireXTM

and CrossFireXTM

•Supports NVIDIA® Quad SLITM, 3-Way SLITM and SLITM

* If you install CPU with 28 lanes, 3-Way SLITM is not supported.

English

Audio •7.1 CH HD Audio with Content Protection (Realtek

ALC1150 Audio Codec)

•Premium Blu-ray Audio support

•Supports Surge Protection (ASRock Full Spike Protection)

•Supports Purity Sound™ 2

- Nichicon Fine Gold Series Audio Caps

- 115dB SNR DAC with Dierential Amplier

- TI® NE5532 Premium Headset Amplier (Supports up to

600 Ohms headsets)

- Direct Drive Technology

- EMI Shielding Cover

- PCB Isolate Shielding

•Supports DTS Connect

LAN •1 x Intel® I218V (Gigabit LAN PHY 10/100/1000 Mb/s)

•1 x Qualcomm® Atheros® AR8171 (PCIE x1 Gigabit LAN

10/100/1000 Mb/s)

•Supports Qualcomm® Atheros® Security Wake On Internet

Technology (on Qualcomm® Atheros® AR8171)

•Supports Wake-On-LAN

•Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

•Supports Energy Ecient Ethernet 802.3az

•Supports PXE

Rear Panel

I/O

•1 x PS/2 Mouse/Keyboard Port

•1 x Optical SPDIF Out Port

•1 x eSATA Connector

•2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

•4 x USB 3.0 Ports (ASMedia ASM1074 hub) (Supports ESD

Protection (ASRock Full Spike Protection))

•2 x USB 3.0 Ports (ASMedia ASM1042) (Supports ESD

Protection (ASRock Full Spike Protection))

•2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED

LED)

•1 x Clear CMOS Switch

•HD Audio Jacks: Rear Speaker / Central / Bass / Line in /

Front Speaker / Microphone

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK IMB-1310 Service-Handbuch

ASROCK

ASROCK H170 Combo Bedienungsanleitung

ASROCK

ASROCK AD2700-ITX Bedienungsanleitung

ASROCK

ASROCK H510M-H2/M2 SE Bedienungsanleitung

ASROCK

ASROCK Z490 Phantom Gaming 4/ac Bedienungsanleitung

ASROCK

ASROCK Super Alloy Z120M-ITX/ac Bedienungsanleitung

ASROCK

ASROCK H67M-GE Bedienungsanleitung

ASROCK

ASROCK B75M R2.0 Bedienungsanleitung

ASROCK

ASROCK 90-MXB150-A0UAYZ Bedienungsanleitung

ASROCK

ASROCK Q1900M Pro3 Bedienungsanleitung

ASROCK

ASROCK X370 KILLER SLI Bedienungsanleitung

ASROCK

ASROCK B365M-HDV Bedienungsanleitung

ASROCK

ASROCK IMB-171-D Bedienungsanleitung

ASROCK

ASROCK A55 Pro3 Bedienungsanleitung

ASROCK

ASROCK H61M-GS Bedienungsanleitung

ASROCK

ASROCK P65iCafe Bedienungsanleitung

ASROCK

ASROCK QC5000-ITX/WiFi Bedienungsanleitung

ASROCK

ASROCK H81M-S1 PLUS Bedienungsanleitung

ASROCK

ASROCK H61M-HG4 Bedienungsanleitung

ASROCK

ASROCK G31M-GS - R2.0 Bedienungsanleitung

ASROCK

ASROCK PV530 Bedienungsanleitung

ASROCK

ASROCK 4CORE1333-GLAN - V1.1 Bedienungsanleitung

ASROCK

ASROCK Z590 PG Velocita Bedienungsanleitung

ASROCK

ASROCK X99M Extreme4 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
