MK221 Series

LCD Monitor

User’s manual

MICARRAY

E3647

First Edition V1

February 2008

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless

such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identification or explanation and to the

owners’ benefit, without intent to infringe.

iii

Contents

Contents ...................................................................................................... iii

Notices......................................................................................................... iv

Safety information ....................................................................................... v

Care & Cleaning ......................................................................................... vi

1.1 Welcome! ....................................................................................... 1

1.2 Package contents............................................................................ 1

1.3 Monitor introduction ....................................................................... 2

1.3.1 Front view .......................................................................... 2

1.3.2 Back view........................................................................... 3

2.1 Assembling the monitor base........................................................ 4

2.2 Adjusting the monitor..................................................................... 4

2.3 Detaching the arm/base.................................................................. 5

(for VESA wall mount)..................................................................... 5

2.4 Connecting the cables.................................................................... 6

2.5 Turning on the monitor................................................................... 6

2.6 Built-in webcam with Mic Array support....................................... 7

2.7 LifeFrame 2 software ...................................................................... 8

3.1 OSD (On-Screen Display) menu ................................................... 9

3.1.1 How to reconfigure............................................................. 9

3.1.2 OSD Function Introduction................................................. 9

3.2 Specications summary............................................................... 12

3.3 Troubleshooting (FAQ) ................................................................. 14

3.4 Supported operating modes ........................................................ 15

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with manufacturer’s

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

The use of shielded cables for connection of the monitor to the graphics card is

required to assure compliance with FCC regulations. Changes or modifications

to this unit not expressly approved by the party responsible for compliance

could void the user’s authority to operate this equipment.

As an Energy Star® Partner, our company has determined that this product meets

the Energy Star® guidelines for energy efficiency.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus set out in the Radio Interference Regulations of the

Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

Safety information

This symbol of the crossed out wheeled bin indicates that the product (electrical,

electronic equipment, and mercury-containing button cell battery) should not

be placed in municipal waste. Please check local regulations for disposal of

electronic products.

• Before setting up the monitor, carefully read all the documentation that came

with the package.

• To prevent fire or shock hazard, never expose the monitor to rain or moisture.

• Never try to open the monitor cabinet. The dangerous high voltages inside the

monitor may result in serious physical injury.

• If the power supply is broken, do not try to fix it by yourself. Contact a qualified

service technician or your retailer.

• Before using the product, make sure all cables are correctly connected and the

power cables are not damaged. If you detect any damage, contact your dealer

immediately.

• Slots and openings on the back or top of the cabinet are provided for

ventilation. Do not block these slots. Never place this product near or over a

radiator or heat source unless proper ventilation is provided.

• The monitor should be operated only from the type of power source indicated

on the label. If you are not sure of the type of power supply to your home,

consult your dealer or local power company.

• Use the appropriate power plug which complies with your local power

standard.

• Do not overload power strips and extention cords. Overloading can result in

fire or electric shock.

• Avoid dust, humidity, and temperature extremes. Do not place the monitor in

any area where it may become wet. Place the monitor on a stable surface.

• Unplug the unit during a lightning storm or if it will not be used for a long period

of time. This will protect the monitor from damage due to power surges.

• Never push objects or spill liquid of any kind into the slots on the monitor

cabinet.

• To ensure satisfactory operation, use the monitor only with UL listed

computers which have appropriate configured receptacles marked between

100-240V AC.

• If you encounter technical problems with the monitor, contact a qualified

service technician or your retailer.

Care & Cleaning

• Before you lift or reposition your monitor, it is better to disconnect the cables

and power cord. Follow the correct lifting techniques when positioning the

monitor. When lifting or carrying the monitor, grasp the edges of the monitor.

Do not lift the display by the stand or the cord.

• Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor

surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed

with a cloth dampened with mild cleaner.

• Avoid using a cleaner containing alcohol or acetone. Use a cleaner intended

for use with the LCD. Never spray cleaner directly on the screen, as it may drip

inside the monitor and cause an electric shock.

The following symptoms are normal with the monitor:

• The screen may flicker during the initial use due to the nature of the fluorescent

light. Turn off the Power Switch and turn it on again to make sure that the

flicker disappears.

• You may find slightly uneven brightness on the screen depending on the

desktop pattern you use.

• When the same image is displayed for hours, an afterimage of the previous

screen may remain after switching the image. The screen will recover slowly or

you can turn off the Power Switch for hours.

• When the screen becomes black or flashes, or cannot work anymore, contact

your dealer or service center to fix it. Do not repair the screen by yourself!

Conventions used in this guide

WARNING: Information to prevent injury to yourself when trying to

complete a task.

CAUTION: Information to prevent damage to the components when trying

to complete a task.

IMPORTANT: Information that you MUST follow to complete a task.

NOTE: Tips and additional information to aid in completing a task.

vii

Where to nd more information

Refer to the following sources for additional information and for product and

software updates.

1. ASUS websites

The ASUS websites worldwide provide updated information on ASUS

hardware and software products. Refer to http://www.asus.com

2. Optional documentation

Your product package may include optional documentation that may have

been added by your dealer. These documents are not part of the standard

package.

viii

1ASUS MK221 Series LCD Monitor

1.1 Welcome!

Thank you for purchasing the ASUS®MK221 Series LCD monitor!

The latest widescreen LCD monitor from ASUS provides a crisper, broader, and

brighter display, plus a host of features that enhance your viewing experience.

Besides, the built-in 1.3 mega-pixel webcam with Mic Array support enhances

image quality and voice clarity. No need for installing additional communication

devices while having a video conference or chatting with friends online!

With these features, you can enjoy the convenience and delightful audio-visual

experience that the MK221 Series brings you!

1.2 Package contents

Check your MK221 Series LCD monitor package for the following items:

• LCD monitor

• Support CD

• Quick start guide

• Power cord x1

• VGA cable x1

• DVI cable x1

• USB 2.0 cable x1

• Audio cable x1

If any of the above items is damaged or missing, contact your retailer

immediately.

2 ASUS MK221 Series LCD Monitor

ME NU

MICARRAY

1.3 Monitor introduction

1.3.1 Front view

Base

1. button:

• Use this hotkey to switch from five video preset modes (Game Mode,

Night View Mode, Scenery Mode, Standard Mode, Theater Mode) with

SPLENDID™ Video Enhancement Technology.

• Exit the OSD menu or go back to the previous menu as the OSD menu

is active.

• Automatically adjust the image to its optimized position, clock, and phase

by pressing this button for 2–3 seconds (MK221H VGA input only).

2. button:

• Press this button to decrease the value of the function selected or move

left/down to the previous function.

• This is also a hotkey for Volume adjustment.

3. MENU button:

• Press this button to enter/select the icon (function) highlighted while the

OSD is activated.

4. button:

• Press this button to increase the value of the function selected or move

right/up to the next function.

• This is also a hotkey for Brightness adjustment.

1 2 3 4 5 67

Control panel

1.3 mega-pixel Webcam Microphone x2

(Mic Array)

Headphone jack Control panel

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Asus Monitor Handbücher

Asus

Asus VB198TL Bedienungsanleitung

Asus

Asus MB168B Bedienungsanleitung

Asus

Asus VW192 Series Bedienungsanleitung

Asus

Asus REPUBLIC OF GAMERS ROG STRIX XG249CM Bedienungsanleitung

Asus

Asus VE198 series Bedienungsanleitung

Asus

Asus ST558 Bedienungsanleitung

Asus

Asus VH192 Series Bedienungsanleitung

Asus

Asus VP247TA Bedienungsanleitung

Asus

Asus PW191A Bedienungsanleitung

Asus

Asus VG279 Series Bedienungsanleitung

Asus

Asus MB19 Series Bedienungsanleitung

Asus

Asus VG255 Series Bedienungsanleitung

Asus

Asus Republic Of Gamers ROG Swift PG32UQX Bedienungsanleitung

Asus

Asus ML239H Bedienungsanleitung

Asus

Asus VX24A series Bedienungsanleitung

Asus

Asus VT207 Series Bedienungsanleitung

Asus

Asus VG32AQA1A Series Bedienungsanleitung

Asus

Asus TUF Gaming VG27V Series Bedienungsanleitung

Asus

Asus ZenScreen MB249C Bedienungsanleitung

Asus

Asus ROG STRIX XG27AQV Bedienungsanleitung

Asus

Asus TUF Gaming VG279QM Series Bedienungsanleitung

Asus

Asus VS229NA series Bedienungsanleitung

Asus

Asus VZ279QG1R Bedienungsanleitung

Asus

Asus VT168HR Series Bedienungsanleitung

Beliebte Monitor Handbücher anderer Marken

Linear Acoustic

Linear Acoustic LQ-1000 Bedienungsanleitung

AOC

AOC I2579V Bedienungsanleitung

Gateway

Gateway FPD1520 Bedienungsanleitung

Furuno

Furuno Mu 120c Bedienungsanleitung

Dell

Dell S2230MX Gebrauchsanweisung

Philips

Philips 107C64 Bedienungsanleitung

Dell

Dell S2409WFP Bedienungsanleitung

EverFocus

EverFocus EN-7517E Bedienungsanleitung

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Bedienungsanleitung

Dell

Dell Precision 7680 Bedienungsanleitung

LG 50PM1M - - 50" Plasma Panel Bedienungsanleitung

Bosch

Bosch DDU 9 Bedienungsanleitung

Acer

Acer A231HL Bedienungsanleitung

Philips

Philips 86BDL4152T Bedienungsanleitung

NEC

NEC AccuSync LCD5V Bedienungsanleitung

Emay

Emay SleepO2 Bedienungsanleitung

IBM

IBM 6360 Montageanleitung

LG M1950D-PZ Bedienungsanleitung
