Asus RT-AX82U Bedienungsanleitung
Quick Start Guide
RT-AX82URT-AX82U
AX5400 Dual Band Wi-Fi RouterAX5400 Dual Band Wi-Fi Router
AX5400 同步双頻無線路由器AX5400 同步双頻無線路由器
¨
Q16456 / Revised Edition v2 / March 2020
Table of contentsTable of contents
Package contents ........................................................................3
A quick look at RT-AX82U.........................................................3
Position your wireless router...................................................4
Preparing your modem.............................................................5
Setting up your RT-AX82U .......................................................6
A. Wired connection .............................................................................6
B. Wireless connection.........................................................................6
FAQ ...................................................................................................8
Networks Global Hotline Information .................................61
This QSG contains these languages:
English
繁體中文
簡體中文
Português do Brasil
Français
Bahasa Indonesia
한국어
Bahasa Malaysia
Português
Español
ไทย
Tiếng Việt
3
English
A quick look at RT-AX82UA quick look at RT-AX82U
Power LED Power switch
2.4GHz LED USB 3.1 Gen 1 port
5GHz LED LAN 1 ~ 4 ports
WAN (Internet) LED WAN (Internet) port
LED on/o button WPS button
Power (DC-IN) port Reset button
Package contentsPackage contents
RT-AX82U Wireless Router AC adapter
Network cable (RJ-45) Quick Start Guide
4
English
Position your wireless routerPosition your wireless router
For optimal wireless transmission between the wireless router and connected
wireless devices, ensure that you:
• Place the wireless router in a centralized area for a maximum wireless coverage
for the network devices.
• Keep the wireless router away from metal obstructions and away from direct
sunlight.
• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi devices,
2.4GHz computer peripherals, Bluetooth devices, cordless phones, transformers,
heavy-duty motors, uorescent lights, microwave ovens, refrigerators, and other
industrial equipment to prevent signal interference or loss.
• Always update to the latest rmware. Visit the ASUS website at
http://www.asus.com to get the latest rmware updates.
• To ensure the best wireless signal, orient the four non-detachable antennas as
shown i n the drawings below.
NOTES:
• Use only the adapter that came with your package. Using other
adapters may damage the device.
• Specications:
DC Power adapter DC Output: +19V with 1.75A current
Operating Temperature 0~40oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
45°45°
5
English
Preparing your modemPreparing your modem
1. Unplug the power cable/DSL modem. If it has a
battery backup, remove the battery.
NOTE: If you are using DSL for Internet, you
will need your username/password from your
Internet Service Provider (ISP) to properly
congure the router.
2. Connect your modem to the router with the
bundled network cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights to ensure
the connection is active.
Unplug
6
English
Setting up your RT-AX82USetting up your RT-AX82U
You can set up your router via wired or
wireless connection.
A. Wired connection
1. Plug your router into a power outlet
and power it on. Connect the network
cable from your computer to a LAN
port on your router.
2. The web GUI launches automatically when you open a web browser. If it does
not auto-launch, enter http://router.asus.com.
3. Set up a password for your router to prevent unauthorized access.
B. Wireless connection
1. Plug your router into a power outlet
and power it on.
Laptop
Tablet
Smart phone
Modem
Wall Power Outlet
LINE LAN RESET PWR
Power
a
WAN
c
b
RT-AX82U
Modem
Wall Power Outlet
LINE LAN RESET PWR
Power
a
WANLAN
d
c
b
Laptop
RT-AX82U
7
English
2. Connect to the network with SSID shown on the product label on the back side
of the router. For better network security, change to a unique SSID and assign
a password.
ASUS router
ASUS_XX
Wi-Fi Name (SSID): ASUS_XX
* XX refers to the last two digits of 2.4GHz
MAC address. You can nd it on the label
on the back of your router.
3. You can choose either the web GUI or ASUS Router app to set up your router.
a. Web GUI Setup
•
Once connected, the web GUI launches automatically when you open a
web browser. If it does not auto-launch, enter http://router.asus.com.
•
Set up a password for your router to prevent unauthorized access.
8
English
b. App Setup
Download ASUS Router App to set up your
router via your mobile devices.
•
Turn on Wi-Fi on your mobile devices
and connect to your router’s network.
•
Follow ASUS Router App setup
instructions to complete the setup.
ASUS Router
ASUS
Router
Remembering your wireless router settings
• Remember your wireless settings as you complete the router setup.
Router Name: Password:
2.4 GHz network SSID: Password:
5GHz network SSID: Password:
FAQFAQ
1. Where can I nd more information about the wireless router?
• Online FAQ site: https://www.asus.com/support/faq
• Technical support site: https://www.asus.com/support
• Customer hotline: refer to the Support Hotline section in this Quick Start
Guide
• You can get the user manual online at https://www.asus.com/support
9
繁體中文
認識您的無線路由器認識您的無線路由器
電源指示燈 電源開關
2.4GHz 指示燈 USB 3.1 Gen 1 連接埠
5GHz 指示燈 LAN 1 ~ 4 網路連接埠
WAN（網際網路）指示燈 WAN （網際網路）連接埠
指示燈開啟 / 關閉按鈕 WPS 按鈕
電源（DC-IN）連接埠 重置按鈕
產品包裝內容產品包裝內容
RT-AX82U 無線路由器 電源變壓器
RJ-45 網路線 快速使用指南
10
繁體中文
放置您的路由器放置您的路由器
為獲得無線路由器與所連線的網路裝置之間傳送最佳無線訊號，請確認以下
幾點：
• 建議將路由器放置在中心區域，以獲得最佳無線訊號覆蓋範圍。
• 請勿將裝置放在靠近金屬物品與陽光直射的地方。
• 請遠離其它 802.11g 或 20MHz Wi-Fi 裝置、2.4GHz 電腦周邊裝置、 藍牙
裝置、無線室內電話、傳送器、重型發動機、日光燈、微波爐、電冰箱與
其他工業裝置，以防止訊號干擾或減損。
• 請經常更新至最新版本韌體。您可以登入華碩官網 https://www.asus.com/
tw/ 獲得最新韌體。
• 請依據下圖所示擺放路由器上的四根非可拆式天線以獲得最佳無線訊號覆
蓋範圍
注意：
• 請僅使用包裝中的變壓器。使用其他種類變壓器可能會造成裝置
損毀。
• 規格：
直流電源變壓器 DC 輸出： +19V，最大電流 1.75A
運作溫度 0~40°C 儲存溫度 0~70°C
運作濕度 50~90% 儲存濕度 20~90%
45°45°
