Asus RT-N13 Bedienungsanleitung

RT-N13 SuperSpeed N

Wireless Router

User Manual

No part of this manual, including the products and software described in it, may be

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any

language in any form or by any means, except documentation kept by the purchaser for

backup purposes, without the express written permission of ASUSTeK Computer Inc.

(“ASUS”).





the serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES

OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE

LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES

(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE

OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR

ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED

FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME

WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY

ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR

INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS

AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered





E4206

First Edition

September 2008

3
Table of contents
About this guide .................................................................................... 4
 .............................................................. 4
Conventions used in this guide ......................................................... 5
Chapter 1: Knowing your wireless router
Package contents .................................................................................. 6
System requirements ............................................................................ 6
Before you proceed............................................................................... 6
Hardware features ................................................................................. 7
Front panel ........................................................................................ 7
Rear panel......................................................................................... 8
Chapter 2: Setting up the hardware
Setting up the wireless router .............................................................. 9
Setting up a wired connection........................................................... 9
Setting up a wireless connection..................................................... 10
Conguring the wireless router ......................................................... 10
Using the web GUI.......................................................................... 10
Chapter 3: Conguring the network clients
Accessing the wireless router............................................................ 12
Setting an IP address for wired or wireless client ........................... 12
Chapter 4: Conguring via the web GUI
Conguring via the web GUI............................................................... 19
Using the Network Map....................................................................... 20
Setting up WAN using the Quick Internet Setup (QIS).................... 21
Managing EzQoS bandwidth .............................................................. 22
Conguring the advanced settings.................................................... 23
................................................................... 23
Restoring/Saving/Uploading settings .............................................. 24

4
Table of contents
About this guide

ASUS Wireless Router.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Knowing your wireless router
 This chapter provides information on the package contents, system
requirements, hardware features, and LED indicators of the ASUS Wireless
Router.
• Chapter 2: Setting up the hardware
 
ASUS Wireless Router.
•  Chapter 3: Conguring the network clients
 This chapter provides instructions on setting up the clients in your network to
work with your ASUS Wireless Router.
Chapter 5: Installing the utilities
Installing the utilities........................................................................... 25
Device Discovery ................................................................................. 27
Firmware Restoration.......................................................................... 27
WPS....................................................................................................... 28
Using WPS...................................................................................... 28
Chapter 6: Troubleshooting
Troubleshooting................................................................................... 34
Appendices
Notices.................................................................................................. 37
GNU General Public License .............................................................. 39
ASUS Contact information.................................................................. 45

• Chapter 4: Conguring via the web GUI

 

using its web graphics user interface (web GUI).

• Chapter 5: Installing the utilities

This chapter provides information on the utilities that are available from the

support CD.

• Chapter 6: Troubleshooting

This chapter provides you with a troubleshooting guide for solving common

problems you may encounter when using the ASUS Wireless Router.

• Appendices

This chapter provides you with the regulatory Notices and Safety Statements.

Conventions used in this guide

WARNING: Information to prevent injury to yourself when trying to

complete a task.

CAUTION: Information to prevent damage to the components when

trying to complete a task.

IMPORTANT: Instructions that you MUST follow to complete a task.

NOTE: Tips and additional information to aid in completing a task.

6RT-N13 Chapter 1: Knowing your wireless router

Package contents

Check the following items in your ASUS Wireless Router package.

RT-N13 Wireless Router

Power adapter

Support CD (manual, utilities)

RJ45 cable

Quick Start Guide

Note: If any of the items is damaged or missing, contact your retailer.

System requirements

Before installing the ASUS Wireless Router, ensure that your system/network

meets the following requirements:

• An Ethernet RJ-45 port (10BaseT/100BaseTX/1000BaseTX)

• At least one IEEE 802.11b/g device with wireless capability

• An installed TCP/IP and Internet browser

Before you proceed

Take note of the following guidelines before installing the ASUS Wireless Router:

• The length of the Ethernet cable that connects the device to the network (hub,

ADSL/cable modem, router, wall patch) must not exceed 100 meters.

 

• Keep the device clear from metal obstructions and away from direct sunlight.

 

microwave ovens, refrigerators, and other industrial equipment to prevent

signal loss.

Knowing your

wireless router

Chapter 1: Knowing your wireless router RT-N13

• Install the device in a central area to provide ideal coverage for all wireless

mobile devices.

• Install the device at least 20cms from a person to insure that the product is

operated in accordance with the RF Guidelines for Human Exposure adopted

by the Federal Communications Commission.

Hardware features

Front panel

PWR

AIR

WAN

LAN

Status indicators

LED Status Indication

(Power) Off No power

On System ready

Flashing-slow Firmware upgrade failed

Flashing-quick WPS processing

AIR (Wireless

Network)

Off No power

On Wireless system ready

Flashing Transmitting or receiving data (wireless)

8RT-N13 Chapter 1: Knowing your wireless router

Item Description

WPS Press this button to launch the WPS utility.

Restore 

factory default settings.

LAN1-LAN4 Connect RJ-45 Ethernet cables to these ports to

establish LAN connection.

WAN Connect an RJ-45 Ethernet cable to this port to establish

WAN connection.

DC In Insert the AC adapter into this port to connect your

router to a power source.

WPS

Restore

WAN

LAN

LAN 1-4

WAN

DC In

Restore button

WPS button

Rear panel

LED Status Indication

LAN 1-4

(Local Area

Network)

Off No power or no physical connection

On Has physical connection to an Ethernet

network

Flashing Transmitting or receiving data (through

Ethernet cable)

WAN

(Wide Area

Network)

Off No power or no physical connectio

On Has physical connection to an Ethernet

network

Flashing Transmitting or receiving data (through

Ethernet cable)

Chapter 2: Setting up the hardware RT-N13

WAN

LAN

Setting up the

hardware

Setting up the wireless router

The ASUS Wireless Router meets various working scenarios with proper



as to meet the requirements in your wireless environment. It also provides you with

WPS, a utility that enables you to easily set up a secure wireless network.

Notes:

•  

setup problems due to wireless uncertainty.

• For more details on WPS, refer to the section WPS in Chapter 5 of this user manual.

Setting up a wired connection

The ASUS Wireless Router is supplied with an Ethernet cable in the package. The

wireless router has integrated auto-crossover function, so use either straight-through

or crossover cable for wired connection.

To set up the wired connection:

1. Turn on your router and the modem.

 

 

port.

10 RT-N13 Chapter 2: Setting up the hardware

Setting up a wireless connection

To set up a wireless connection:

1. Turn on your router and the modem.

 

3. Connect an IEEE 802.11b/g/n compatible WLAN card. Refer to your wirelessRefer to your wireless

adapter user manual for wireless connection procedures. By default, the SSID

of ASUS Wireless Router is “default” (in lower case), encryption is disabled and

open system authentication is used.

WAN

Conguring the wireless router

The ASUS Wireless Router includes a web graphics user interface (web GUI)



computer.

Using the web GUI

If your PC connects to the router using a cable, launch a web browser and the





To select the network:

1. Click Start > Control Panel > Network Connections > Wireless Network

Connection.

2. Select a network from the Choose a wireless network window. Wait for it to

connect.

Note: By default, the SSID of the wireless router is default. Connect to this default SSID.
