Asus RT-N14U Bedienungsanleitung
RT-N14U
Wireless-N300 Router
User Guide
2
E7879
First Edition
November 2012
Copyright ©2012 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described
in it, may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK Computer Inc. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired,
modied or altered, unless such repair, modication of alteration is authorized
in writing by ASUS; or (2) the serial number of the product is defaced or
missing.
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS
AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR
PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE
FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE
AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A
COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY
FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent
to infringe.
3
Table of contents
About this guide .......................................................................................... 5
Package contents ........................................................................................ 7
1 Getting to know your router 7
Hardware features....................................................................................... 8
Mounting placement ...............................................................................10
Positioning your router............................................................................11
2 Setting up your wireless network 11
What you need ...........................................................................................12
Setting up your wireless router ............................................................13
Wired connection...............................................................................13
Wireless connection ..........................................................................14
Before you proceed ...........................................................................15
A. Disable any congured proxy servers...............................15
B. Congure TCP/IP settings......................................................17
C. Disable dial-up networking ..................................................19
Logging into the web GUI......................................................................20
3 Network conguration using the web GUI 20
Setting up the Internet connection ....................................................21
Quick Internet Setup (QIS) with auto-detection .....................21
Setting up the wireless security settings ..........................................26
Managing your network clients ...........................................................27
Monitoring your USB device..................................................................27
Creating your Guest Network ...............................................................29
Using the Trac Manager.......................................................................31
Managing QoS (Quality of Service) Bandwidth.......................31
Monitoring Trac ..............................................................................32
4
Using the USB application......................................................................33
Using AiDisk for File Sharing ..........................................................33
Using the Servers Center .................................................................36
Using the Network Place (Samba) Share service ....................37
Using the FTP Share service............................................................39
Using the Miscellaneous setting...................................................42
Conguring Advanced settings............................................................43
Setting up the DHCP Server ...........................................................43
Upgrading the rmware ..................................................................44
Restoring/Saving/Uploading settings ........................................45
Setting up your network printer ..........................................................46
4 Using the utilities 49
Device Discovery .......................................................................................49
Firmware Restoration...............................................................................50
5 Troubleshooting 53
Troubleshooting ........................................................................................53
ASUS DDNS Service ..................................................................................56
Frequently Asked Questions (FAQs) ............................................56
Appendices 59
Notices...........................................................................................................59
ASUS Contact information .....................................................................71
Networks Global Hotline Information................................................72
5
About this guide
This user guide contains information that you need to install and
congure the ASUS Router.
How this guide is organized
This guide contains the following sections:
• Chapter 1: Getting to know your router
This chapter provides information on the package contents,
hardware features, and LED indicators of the ASUS Router.
• Chapter 2: Setting up your wireless network
This chapter details instructions on how to set up a wireless
network.
• Chapter 3: Network conguration using the web GUI
This chapter discusses the steps to configure a wireless network
using the web GUI.
• Chapter 4: Using the utilities
This chapter provides instructions on using the utilities
included with the ASUS router.
• Chapter 5: Troubleshooting
This chapter contains a troubleshooting guide for solving
common problems you may encounter when using the ASUS
Router.
• Appendices
This chapter provides you with the regulatory Notices and
Safety Statements.
6
7
RT-N14UChapter 1: Getting to know your router
1
Getting to know
your router
Package contents
• If any of the items is damaged or missing, contact ASUS for
technical inquiries and support, Refer to the ASUS Support
Hotline list at the back of this user manual.
• Keep the original packaging material in case you would need
future warranty services such as repair or replacement.
RT-N14U Wireless Router
Network cable (RJ-45)
Power adapter
Quick Start Guide
Warranty card
8RT-N14U Chapter 1: Getting to know your router
Hardware features
USB LED
O: Indicates no power or no USB device connected.
On: Indicates a connected USB devices.
LAN LED
O: No power or no connection detected.
On: Indicates a connection to a local area network (LAN).
Wi-Fi LED
O: No wireless signal detected.
On: Indicates that the wireless network is ready.
Flashing: Indicates network activity via wireless connection
WAN LED
O: No power or no connection detected.
On: Indicates a connection to a wide area network (WAN).
Power LED
O: No power.
On: Device ready.
Flashing: Indicates WPS activity.
2
1
3
4
5
Front
5
2
4
1
3
9
RT-N14UChapter 1: Getting to know your router
USB 2.0 port
Insert USB 2.0 devices such as USB hard drives and desktop printers into
this port.
WPS button
Press this button to launch the WPS Wizard to set up wireless security.
LAN 1~4 ports
Connect ethernet cables into these ports to establish a LAN connection.
WAN (Internet) port
Connect a network cable into this port to establish a WAN connection.
Power button
Press the power button to switch the device ON/OFF.
Power (DC-IN) port
Insert the bundled AC adapter into this port.
Reset button
This button resets or restores the system to its factory default settings.
Wall-mount hooks
Use the wall-mount hooks to mount the ASUS router to a wall or raised
surface.
12
6
7
8
9
10
11
13
Rear
6
7
12
6
9
8
11
10
13
10 RT-N14U Chapter 1: Getting to know your router
Mounting placement
• Use only the power adapter that came with your package.
Using other adapters may damage the device.
DC Power adapter DC Output:
+19V with max 1.58A current; +12V
with max 2A current
Operating Temperature 0~40oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
To mount the wireless router onto
its stand:
1. Locate the two mounting holes
at the bottom of the wireless
router.
2. Latch the stand’s two mounting
hooks to the wireless router’s
mounting holes.
3. Slide the wireless router towards
direction of the arrow to secure
it to its stand.
• Operating Specifications:
•
2
