Atlantis Land WebShare A02-RA11 Bedienungsanleitung
Where solutions begin
Company certified ISO 9001:2000
WebShare 111/141
ROUTER ADSL2+
A02-RA111
A02-RA141
MULTILANGUAGE
QUICK START GUIDE
A02-RA11(4)1_GX02
Where solutions begin
Company certified ISO 9001:2000
ITALIANO
Questo prodotto è coperto da garanzia Atlantis Land
Fast Swap della durata di 3 anni. Per maggiori dettagli in
merito o per accedere alla documentazione completa in
Italiano fare riferimento al sito www.atlantis-land.com.
ENGLISH
This product is covered by Atlantis Land 3 years Fast
Swap warranty. For more detailed informations please
refer to the web site www.atlantis-land.com.
For more detailed instructions on configuring and using the
Switch , please refer to the online manual.
FRANCAIS
Ce produit est couvert par une garantie Atlantis Land
Fast Swap de 3 ans. Pour des informations plus
détaillées, référez-vous svp au site Web www.atlantis-
land.com.
DEUTSCH
Dieses Produkt ist durch die Atlantis Land 3 Jahre Fast
Swap Garantie gedeckt. Für weitere Informationen,
beziehen Sie sich bitte auf Web Site www.atlantis-
land.com.
ESPAÑOL
Este producto està cubierto de garantía Atlantis Land Fast
Swap por 3 años. Para una información más detallada, se
refiera por favor al Web site www.atlantis-land.com.
Where solutions begin
Company certified ISO 9001:2000
The award of the information is facultative, but its lack will
prevent ATLANTIS LAND® from starting the Guarantee
process requested.
Copyright
The Atlantis Land logo is a registered trademark of Atlantis
Land SpA. All other names mentioned mat be trademarks
or registered trademarks of their respective owners.
Subject to change without notice. No liability for technical
errors and/or omissions.
R
R
Re
e
eg
g
gi
i
is
s
st
t
te
e
er
r
r
y
y
yo
o
ou
u
ur
r
r
p
p
pr
r
ro
o
od
d
du
u
uc
c
ct
t
t!
!
!
w
w
ww
w
ww
w
w.
.
.a
a
at
t
tl
l
la
a
an
n
nt
t
ti
i
is
s
s-
-
-l
l
la
a
an
n
nd
d
d.
.
.c
c
co
o
om
m
m
Registration on the web site
www.atlantis-land.com within 15 days
from the purchase of the product dismiss
the customer from showing a valid proof of
purchase (Sale Receipt or Invoice) in case
of the request of intervention. For further
information we invite you to look at our web
site at the section WARRANTY.
MULTILANGUAGE QUICK START GUIDE
4
ITALIANO
1.1 Contenuto della confezione ............................... 8
1.2 I LED frontali......................................................... 8
1.3 Le porte posteriori................................................ 9
1.4 Cablaggio............................................................ 10
1.5 Settaggi di Default ............................................. 11
1.6 Configurazione di IE.......................................... 12
1.7 Configurazione del PC...................................... 12
Configurazione del PC in Windows 95/98/ME ........ 12
Configurazione del PC in Windows NT4.0 .............. 13
Configurazione del PC in Windows 2000 ............... 13
Configurazione del PC in Windows XP................... 13
1.8 Configurazione Router...................................... 16
PPPoE/PPPoA............................................................. 19
Static IP Address ......................................................... 21
1.9 Supporto Offerto ................................................ 22
ENGLISH
1.1 Package contents .............................................. 25
1.2 The Front Panel LEDs ...................................... 25
1.3 The Rear Ports................................................... 26
1.4 Cabling ................................................................ 27
1.5 Default Settings.................................................. 28
Before Configuration ................................................... 28
1.6 IE Configuration ................................................. 29
1.7 TCP/IP Configuration ........................................ 29
Configuring PC (Windows 95/98/ME) ...................... 29
Configuring PC (Windows NT4.0) .......................... 30
Configuring PC (Windows 2000).............................. 30
Configuring PC (WindowsXP) ................................. 31
MULTILANGUAGE QUICK START GUIDE
5
1.8 Browser configuration ....................................... 34
PPPoE/PPPoA............................................................. 36
Static IP Address ......................................................... 37
1.9 Product Support ................................................. 39
FRANCAIS
1.1 Contenu de la boîte ........................................... 41
1.2 Face avant .......................................................... 41
1.3 Face arrière ........................................................ 43
1.4 Câblage ............................................................... 44
1.5 Configuration initiale.......................................... 44
1.6 Configuration du TCP/IP................................... 45
Configuration sous Windows 95/98/ME................... 45
Configuration sous Windows NT4.0 ......................... 45
Configuration sous Windows 2000......................... 46
Configuration sous Windows XP ............................ 46
1.7 Vérification .......................................................... 48
1.8 Configuration avec le Browser......................... 49
PPPoE/PPPoA............................................................. 52
Static IP Address ......................................................... 54
1.9 Support................................................................ 55
DEUTSCH
1.1 Inhalt der Verpackung....................................... 56
1.2 Die frontalen LED .............................................. 56
1.3 Die Hinterturen ................................................... 57
1.4 Verdrahtung........................................................ 58
1.5 Einstellung des Default ..................................... 59
1.6 Die IE Konfiguration .......................................... 59
MULTILANGUAGE QUICK START GUIDE
6
1.7 Konfiguration des PC ........................................ 60
Konfiguration des PC in Windows 95/98/ME .......... 60
Konfiguration des PC in Windows NT4.0................. 60
Konfiguration des PC in Windows 2000 ................. 61
Konfiguration des PC in Windows XP ...................... 61
1.8 Konfiguration des Router.................................. 64
PPPoE/ PPPoA............................................................ 66
Static IP Address ......................................................... 67
ESPANOL
1.1 Contenido de la caja ......................................... 70
1.2 Los LED frontales .............................................. 70
1.3 Las puertas posteriores .................................... 71
1.4 Cableado............................................................. 72
1.5 Configuraciones por Defecto ........................... 73
1.6 Configuracciòn de IE......................................... 73
1.7 Configuracciòn del PC ...................................... 74
Configuracciòn del PC en Windows 95/98/ME ....... 74
Configuración del PC en Windows NT4.0 ............... 74
Configuración del PC en Windows 2000 ................ 75
Configuración del PC en Windows XP.................... 75
1.8 Configuración del Router.................................. 77
MULTILANGUAGE QUICK START GUIDE
7
A02-RA11(4)1_GX02(V1.0 December 2005)
ITALIANO
8
Questo manuale è inteso come una guida rapida,
pertanto per ulteriori dettagli sulla configurazione fare
riferimento al manuale esteso o alla guida interattiva
presente sul CD.
1.1 Contenuto della confezione
WebShare Router ADSL2+, CD-Rom contenente il manuale,
Guida di Quick Start, cavo RJ11 ADSL, cavo CAT5 LAN,
Alimentatore.
1.2 I LED frontali
LED INFORMAZIONE
PWR Acceso quando connesso alla rete
elettrica.
ITALIANO
9
SYS
Acceso quando il sistema è pronto.
Lampeggiante durante il caricamento del
firmware.
LAN
Acceso quando connesso ad un
dispositivo Ethernet:
Verde= connessione a 100Mbps
Arancio= connessione a 10Mbps
Lampeggiante quando vi è
trasmissione/ricezione.
ADSL
Acceso quando connesso in modalità
ADSL DSLAM. Lampeggiante durante la
fase di allineamento.
PPP Acceso fisso quando è instaurata una
connessione PPPoA/PPPoE.
1.3 Le porte posteriori
ITALIANO
10
PORTE UTILIZZO
ADSL(RJ11) Connettere il cavo RJ11 a questa
porta per effettuare l’allacciamento
all’ADSL.
LAN(RJ45) Connettere con un cavo UTP.
RESET Dopo che il dispositivo è acceso,
premere per effettuare il reset o il
restore. Le operazioni sono le
seguenti:
•0-3 secondi: per resettare il
dispositivo.
•3-5 secondi: nessuna
azione.
•10 secondi o più: effettua
un ritorno alle condizioni di
default (utilizzare, per
esempio, in caso si
perdesse la password).
POWER (jack) Connettere l’alimentatore a questo
jack.
1.4 Cablaggio
Anzitutto collegare il prodotto alla linea ADSL tramite il cavo
RJ11 fornito in dotazione (nella porta LINE), poi collegare
alla porta RJ45 il PC della Lan oppure eventuali Switch.
Infine collegare l’alimentatore al WebShare Router ADSL2+
e poi presa elettrica. Il WebShare Router ADSL2+ effettuerà
immediatamente una diagnostica (circa 20 secondi).
Terminata questa fase i Led POWER, SYS (eventualmente
anche i Led LAN, se connessi a PC) saranno accesi verdi
Andere Handbücher für WebShare A02-RA11
1
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Atlantis Land Netzwerk-Router Handbücher
Atlantis Land
Atlantis Land A02-F16(24)/M2 Bedienungsanleitung
Atlantis Land
Atlantis Land I-Storm A02-RA3 Betriebsanleitung
Atlantis Land
Atlantis Land Network Router Bedienungsanleitung
Atlantis Land
Atlantis Land Edge-Core A07-ES4612C Bedienungsanleitung
Atlantis Land
Atlantis Land WebShare 144WN Bedienungs- und Wartungshandbuch
Atlantis Land
Atlantis Land Edge-Core A07-ES4612 Betriebsanleitung
Atlantis Land
Atlantis Land A02-RAV211 Bedienungsanleitung
Atlantis Land
Atlantis Land A02-F24-2C Bedienungsanleitung
Atlantis Land
Atlantis Land A02-F5 Bedienungsanleitung
Atlantis Land
Atlantis Land A02-RA241-W54 Bedienungsanleitung
Atlantis Land
Atlantis Land A02-RA ME01 Bedienungsanleitung
Atlantis Land
Atlantis Land A07-ES3526XA Bedienungsanleitung
Atlantis Land
Atlantis Land A02-RA243-W54M Bedienungsanleitung
Atlantis Land
Atlantis Land A02-F8-2C/M2 Bedienungsanleitung
Atlantis Land
Atlantis Land Mistral Lan Router ISDN Montageanleitung
Atlantis Land
Atlantis Land I-Fly A02-WRA-11B Bedienungsanleitung
Atlantis Land
Atlantis Land Edge-Core A07-ES4649 Bedienungsanleitung
Atlantis Land
Atlantis Land Edge-Core A07-ES5508 Bedienungsanleitung
Atlantis Land
Atlantis Land A02-RAV211_GX01 Bedienungsanleitung
Atlantis Land
Atlantis Land A02-RI_M02 Bedienungsanleitung
Beliebte Netzwerk-Router Handbücher anderer Marken
NETGEAR
NETGEAR FS526T - Switch Bedienungsanleitung
Korenix
Korenix JetNet 5710G Series Bedienungsanleitung
Automated Logic
Automated Logic ZN551 Betriebsanleitung
Cisco
Cisco ASR 1000 Series Bedienerhandbuch
EnGenius
EnGenius ESR-9710 Bedienungsanleitung
Cisco
Cisco 805 Series Bedienungs- und Sicherheitshinweise
